标号

Item

零件代号

Part No

零件名称

Part Name

数量

Q‘ty

备注 Remark

1

4120000370

先导阀总成 DXS-00

MONOLEVER PILOT VALVE DXS–OO

1

2

4011000475

螺栓 GB16674-M10*30EpZn-8.8

BOLT GB16674-M10*30EpZn-8.8

4

3

29120014931

垫圈

WASHER

19

4

4011000344

螺栓 JB999-M14*1.5*32EpZn-35

BOLT JB999-M14*1.5*32-35

3

5

4041000095

直接头 LGB120-02218

STAIGHT JOINT LGB120-02218

2

6

4041000768

O 形圈 LGB168- 11524

O–RING LGB– 11524

2

7

29120010031

先导泵回油管

OIL RETURN PIPE OF PUMP

1

8

29120010301

过渡块

TRANSITION BLOCK

1

9

4011000279

螺栓 GB16674-M10*60EpZn-8.8

BOLT GB16674-M10*60EpZn-8.8

8

10

4041000580

软管 LGB125-004040

SOFT TUBE LGB125-004040

1

11

29120007651

接头

JOINT

1

12

29120010021

支架

BEARER

1

13

4011000474

螺栓 GB16674-M10*25EpZn-8.8

BOLT GB16674-M10*25EpZn-8.8

2

14

29120015671

固定板

MOUNTED PLATE

1

15

4011000137

螺栓 GB16674-M12*20EpZn-8.8

BOLT GB16674-M12*20EpZn-8.8

4

16

29120015661

固定板

MOUNTED PLATE

1

17

4120001964

多路阀 ZL20DYL-03

MULTIPLE UNIT VALVE ZL20DYL-03

1

18

4015000168

垫圈 GB97.1-12EpZn-300HV

WASHER GB97.1-12EpZn-300HV

8

19

4013000011

螺母 GB6170-M12EpZn-8

NUT GB6170-M12 EpZn-8

8

20

4011000467

螺栓 GB16674-M12*45EpZn-8.8

BOLT GB16674-M12*45EpZn-8.8

6

21

4011000479

螺栓 GB16674-M12*30EpZn-8.8

BOLT GB16674-M12*30EpZn-8.8

4

22

4041000598

堵塞 LGB142-01604

PLUG LGB142-01604

2

23

4030000240

O 形圈 GB3452.1-8.00*1.80G

O–RING GB3452.1-8.00*1.80G

6

24

4041000577

直接头 LGB120-03633

STAIGHT JOINT LGB120-03633

1

25

4041000765

O 形圈 LGB168- 12931

O–RING LGB168-12931

1

标号

Item

零件代号

Part No

零件名称

Part Name

数量

Q‘ty

备注 Remark

26

29120010461

组合直角接头

UNIT ANGLE COUPLING

1

27

4030000504

O 形圈 GB3452.1-25.8*1.80G

O–RING GB3452.1-25.8*1.80G

1

28

4041000599

软管 LGB165-014140

SOFT TUBE LGB165-014140

1

29

29120006551

组合直角接头

UNIT ANGLE COUPLING

2

30

4030000501

O 形圈 GB3452.1- 15.0*1.80G

O–RINGGB3452.1- 15.0*1.80G

2

31

4041000582

直接头 LGB120-02630

CONNECTOR LGB120-02630

1

32

4041000756

O 形圈 LGB168-02631

O–RING LGB168-02631

3

33

4041000511

软管 LGB128-012112

PIPE LGB128012112

1

34

29120009971

阀块

VALVE BLOCK

1

35

4041001023

组合接头 LGB143-01608

JOINT LGB143-01608

4

36

29120015701

动臂大腔至选择阀胶管

HOSE

1

37

29120009991

组合直角接头

UNIT ANGLE COUPLING

1

38

4030000242

O 形圈 GB3452.1- 12.5*1.80G

O–RING GB3452.1- 12.5*1.80G

1

39

4041000601

软管 LGB165-006060

SOFT TUBE LGB165-006060

1

40

4120000448

压力选择阀

SF8-C PRESSURE SELECTION VALVE SF8-C

1

41

4041000604

直接头 LGB120-01614

JOINT LGB120-01614

4

42

4041000767

O 形圈 LGB168- 11124

O–RING LGB168-11124

8

43

29120010001

选择阀泄油管

SPILL OIL PIPE OF SELECTOR VALVE

1

44

29120010851

前部先导油管(b2)

FRONT PILOT PTPE (b2)

1

45

29120010011

回油块

RETURN BLOCK

1

46

4041000774

螺塞 LGB135-01422

PLUG LGB13501421

3

47

4041001203

软管 LGB124-004070

HOSE LGB124-004070

1

48

4041000830

直接头 LGB120-01618

JOINT LGB120-01618

1

49

29120015221

垫圈

WASHER

1

标号

Item

零件代号

Part No

零件名称

Part Name

数量

Q‘ty

备注 Remark

50

29120015401

接头

FITTING

11

51

4041001202

软管 LGB124-003058

HOSE LGB124-003058

1

52

4041001047

组合接头 LGB143-01406

CONNECTOR LGB143-01406

2

53

4030000530

O 形圈 GB3452.1-6.00*1.80G

O–RING GB3452.1-6.00*1.80G

3

54

29120015451

软管

SOFT TUBE

1

55

29120015471

软管

SOFT TUBE

1

56

29120009931

多路阀固定板

CLAMPING PLATE OF CONTROL VALVE

1

57

26130001471

螺塞

PLUG SCREW

2

58

4041001223

软管 LGB125-003060

HOSE LGB125-003060

1

59

29120015441

软管

SOFT TUBE

1

60

29120015461

软管

SOFT TUBE

1

61

4011000169

螺栓 GB16674-M8*70EpZn-8.8

BOLT GB16674-M8*70EpZn-8.8

4

62

4013000033

螺母 GB6170-M8EpZn-8

NUT GB6170-M8EpZn-8

4

63

4015000072

垫圈 GB97.1-8EpZn-300HV

WASHER GB97.1-8EpZn-300HV

4

64

29120015361

管夹

PIPE CLIP

2

65

29120015381

板

PLATE

2

66

4041000510

软管 LGB129-012045

PIPE LGB129-012045

1

67

4041000796

直接头 LGB120-02628

CONNECTOR LGB120-02628

1

68

4041000779

O 形圈 LGB168- 12331

O–RING LGB168-12331

1

69

29120007671

管夹

CLAMP

4

70

4011000461

螺栓 GB16674-M8*16EpZn-8.8

BOLT GB16674-M8*16EpZn-8.8

2

71

4041000133

直接头 LGB120-01414

JOINT LGB120-01414

1

72

4041000711

软管 LGB124-004102

HOSE LGB124-004102

1

73

29120010061

三通接头

TEE PIPE COUPLING

1

74

29120006591

回油胶管

RETURN PIPE

1

标号

Item

零件代号

Part No

零件名称

Part Name

数量

Q‘ty

备注 Remark

75

29190008061

压盖

GLAND

1

76

4030000279

O 形圈 GB3452.1-25.0*3.55G

O–RING GB3452.1-25*3.55G

1

77

4011000481

螺栓 GB16674-M8*30EpZn-8.8

BOLT GB16674-M8*30Ep.Zn-8.8

4

78

4011000314

螺栓 GB16674-M10*80EpZn-8.8

BOLT GB16674-M10*80EpZn-8.8

2

79

29120006611

橡胶板

RUBBER PLATE

2

80

29120006601

压板

PRESS PLATE

1

81

4013000007

螺母 GB6170-M10EpZn-8

NUT GB6170-M10EpZn-8

2

82

4015000162

垫圈 GB97.1-10EpZn-300HV

WASHER GB97.1-10EpZn-300HV

4

83

4041000592

软管 LGB125-004055

PIPE LGB125-004055

1

84

29120015081

接头

JOINT

2

85

4030000276

O 形圈 GB3452.1-32.5*2.65G

O–RING GB3452.1-32.5*2.65G

2

86

4120001954

滤油器 PLF–C30*10

STRAINER

1

87

4011000082

螺栓 GB5783-M10*25EpZn-8.8

BOLT GB5783-M10*25EpZn-8.8

2
