1

1452-62-03000

工作阀回油接头 Oil return joint of working valve

1

2

GB898-AM12X35

螺柱 AM12X35 Double-screw bolt

2

3

1457-62-10000

多路阀进油块 Oil inlet block

1

4

GB16674.1-M10X50

GB16674.1-M10X55

螺栓M10X50

螺栓M10X55

Bolt

Bolt

2

2

5

03031-5AB551880

软管

Pipe

1

6

03018-AB662330

软管

Pipe

1

7

1457-62-00004

U型板

Plate

2

8

1457-62-00005

橡胶管夹 Rubber clamp

4

9

1457-62-00003

板

Plate

1

10

1457-62-00006

支架

Bracket

1

11

1457-62-00007

支架

Bracket

1

12

1457-62-00009

橡胶管夹 Rubber clamp

2

13

1457-62-00008

U型板

Plate

1

14

1457-62-11000

吸油软管 Oil suction pipe

1

15

1457-62-00010

工作泵出油块 Working pump oil outlet block

1

16

1457-62-01000

工作泵

Working pump

1

17

1457-62-04000

吸油硬管 Oil suction tube

1

18

07008-13560

O 型圈 56X3.55 O-ring

1

19

GB16674.1-M10X90

螺栓 M10X90 Bolt

1

20

GB93-12

弹簧垫圈 12 Washer

10

21

GB6170-M12

螺母 M12

Nut

6

22

1457-62-00015

螺栓 M12X190 Bolt

2

23

GB1235-50X3.1

O 型圈

O-ring

1

24

07010-24047

O 型圈 47.22X3.53 O-ring

2

25

07371-31465

法兰

Flange

4

26

GB16674.1-M12X35

螺栓 M12X35 Bolt

8

27

07008-13375

O 型圈 37.5X3.55 O-ring

1

28

GB16674.1-M10X80

螺栓 M10X80 Bolt

4

29

07371-31255

法兰

Flange

4

30

GB16674.1-M10X30

螺栓 M10X30 Bolt

4

31

GB16674.1-M10X90

螺栓 M10X90 Bolt

2

32

GB6170-M10

螺母 M10

Nut

6

33

GB5783-M12X25

螺栓M12X25 Bolt

2

34

GB16674.1-M10X100

螺栓M10X100 Bolt

4

35

GB16674.1-M10X20

螺栓M10X20 Bolt

2

36

07010-24038

O型圈37.69X3.53 O-ring

2

37

07280-09832

T型喉箍

T-clamp

2

38

07280-08029

T型喉箍

T-clamp

2

39

GB898-AM12X35

螺柱AM12X35 Double-screw bolt

4
