Zoomlion Rough Terrain Scissor Lift ZS5390RT parts list

Meppon Co., Ltd Posted on by
1040001179Bolt M12×35-8.8GB/T5782-2000
1040300526Washer 12GB/T97.1-2002
1040200507Nut M12-8GB/T889.1-2000
1040200506Nut M6-8GB/T889.1-2000
1040300051Washer 6GB/T97.1-2002
1040100105Screw M6×25-8.8GB/T70.1-2000
00775800110001070Roller mounting plate I
1040100237Screw M6×30-8.8GB/T70.1-2000
775800110002400Stop pin
775800110002300Nylon block
1040200506Nut M6-8GB/T889.1-2000
00775800100001080Pin II
00775800100001070Roller III
1052500006BearingGB/T 276-1994
775800100001200Gasket I
00775800300001010Axle Ⅰ
1040003970Bolt M12×35-8.8GB/T5783-2000
1040300054Washer 12GB/T93-1987
1040300526Washer 12GB/T97.1-2002
00773400200001070Stop pin
1054400367Composite bush
00775800302101030Base
00775800302101020Rib plate
00775800300201030Connecting pipe
00775800302001010Lower sliding block
00775800302101010Baseplate
00775800302001020Upper sliding block
00775800302101040Connecting plate
1040103310Screw M8×45-8.8GB/T70.3-2000
1040300066Washer 8GB/T97.1-2002
1040200503NutGB/T889.1-2000
00775800302101050Lower positioning plate
ZS5390RT Series Accessory
775806300410000Platform control box
1020104178Platform control assembly
ZS5390RT Outrigger Structure
1040000267Bolt M8×20-8.8GB/T5783-2000
1040300063Washer 8GB/T93-1987
1040300066Washer 8GB/T97.1-2002
775802801040000Outrigger hood weld
00775802801001070Transparent veneer II
775802801080000Seal plate weld
1040000116Bolt M10×20-8.8GB/T5783-2016
1040300067Washer 10GB/T93-1987
1040300061Washer 10GB/T97.1-2002
00775802801001060Transparent plate I
00775802801001050Limit plate
1010201637Outrigger cylinder
1040200161Nut M16-8GB/T889-1986
1040300052Washer 16GB/T97.1-2002
00775802801001040Cylinder mounting bolt
775802801060000Stud
1040200503Nut M8-8GB/T889.1-2000
1020521448Limit switch
1040100055Bolt M6×20-8.8GB/T70.1-2000
1040300062Washer 6GB/T93-1987
1040300051Washer 6GB/T97.1-2002
00775802801001030Travel switch mounting plate
1040100127Bolt M6×12-8.8GB/T70.1-2000
00775802801001020Cover plate
1040006219Bolt M20×70-10.9SGB/T1228-2006
1040006220Bolt M20×85-10.9SGB/T1228-2006
1040302502Washer 20GB/T1230-1991
1040202439Nut M20-10GB/T6177.1-2000
00775802800001010Outrigger mounting plate
00775802800001020Outrigger mounting plate
ZS5390RT Front-wheel Steering
1040202297Nut M16×1.5-10GB/T6177.2-2000
1030800838Tire
1040001179Bolt M12×35-8.8GB/T5782-2000
1040300054Washer 12GB/T93-1987
1040300526Washer 12GB/T97.1-2002
00773400200001070Stop pin
00775802800001280Pin III
00773402800001110Steering knuckle gasket
00773400200001020Bearing
1030202175Reducer
775802800400000Steering knuckle I
00773402800001320Steering knuckle upper gasket
00775802800001460Pin II
1054400336Composite bush
00775802800001290Floating cylinder connecting pin II
00775600000001050Articulated pin
1040300066Washer 8GB/T97.1-2002
1040300063Washer 8GB/T93-1987
1040000288Bolt M8×25-8.8GB/T5783-2000
00775802800001270Floating cylinder connecting pin
1010201676Floating cylinder
1040006079Bolt M16×45-8.8GB/T5783-2000
00773400400001250Stop pin
00775802800001260Floating bridge connecting pin
00773402800001070Bearing
ZS5390RT Front-wheel Steering
775802800800000Front axle welds
1030800839Tire
1040000101Bolt M12×40-8.8GB/T5783-2016
1040200507Nut M12-8GB/T889.1-2000
775802801700000Tube support II
1040302492Washer 16GB/T97.1-2002
1040101819Screw M16×40-10.9GB/T70.1-2000
1040000114Bolt M10×25-8.8GB/T5783-2000
1040300067Washer 10GB/T93-1987
1040300061Washer 10GB/T97.1-2002
00775802800001250Stop pin
00775802800001240Pin I
1054400340Composite bush
775802804400000Steering link
1010201636Steering cylinder
1040000018Bolt M8×30-8.8GB/T5783-2000
1040200503Nut M8-8GB/T889.1-2000
00775802800001310Tube pressing plate
1040100055Screw M6×20-8.8GB/T70.1-2000
1040200506Nut M6-8GB/T889.1-2000
00775802800001470Tube clamp
775802801600000Tube support
ZS5390RT Lateral Ladder
00775800300001190Cushion
00775802800001360Level guard
1040100127Screw M6×12-8.8GB/T70.1-2000
1040300062Washer 6GB/T93-1987
1040300051Washer 6GB/T97.1-2002
1040102341Screw M5×12-8.8GB/T70.1-2000
1040000682Bolt M6×40-8.8GB/T5783-2000
1021404523Level
00775802800001330Level spring
00775802800001320Level mounting plate
1040200161Nut M16-8GB/T889-1986
1040300247Washer 16GB/T96.1-2002
775802803100000Ladder
1040006079Bolt M16×45-8.8GB/T5783-2000
1040300093Washer 6GB/T96.1-2002
00775802800001350Door buffer ring
1040200506Nut M6-8GB/T889.1-2000
1040200507Nut M12-8GB/T889.1-2000
1040001179Bolt M12×35-8.8GB/T5782-2000
1029903782Screw M4×12GB/T818-2000
1999905631Hinge
00775802800001380Plate
1040201772Nut M4-A2-70GB/T6170-2000
00771101103201020Sponge bar
1109800044Tongue type lock
775802804200000Left body cover
1101000131Panel lock
1040101212Screw M6×20-8.8GB/T818-2000
ZS5390RT Right Box
1040000198Bolt M16×50-8.8GB/T5783-2016
1040300052Washer 16GB/T97.1-2002
1040200161Nut M16-8GB/T889-1986
775802803400000Tray fixed plate
1040001595Bolt M10×35-8.8GB/T5783-2000
1040300061Washer 10GB/T97.1-2002
1040200504Nut M10-8GB/T889.1-2000
1040100105Screw M6×25-8.8GB/T70.1-2000
00773400830201020Baffle
1040200506M6-8GB/T889.1-2000
1040102717Screw M8×40-8.8GB/T70.3-2000
00775802800001080Tray block
00775802800001150Adjustable gasket
00775802800001430Motor cover plate
773400801400000Tray plug pin
775802804800000Intermediate plate mounting seat
1040001680Bolt M10×30-8.8GB/T5783-2016
1040300093Washer 6GB/T96.1-2002
00775802800001160Battery fixing plate
00775802800001180Battery fixing lever
00775802800001170Battery fixing bracket
1040100237Screw M6×30-8.8GB/T70.1-2000
1040300051Washer 6GB/T97.1-2002
1040000114Bolt M10×25-8.8GB/T5783-2000
1040300067Washer 10GB/T93-1987
ZS5390RT Right Body
773400300001200Stop pin
00775802800001420Tray axis
00775802800001030Friction plate
1101000162Hinges
1040000076Bolt M6×25-8.8GB/T5783-2000
1040300526Washer 12GB/T97.1-2002
1040300054Washer 12GB/T93-1987
1040000069Bolt M12×25-8.8GB/T5783-2016
775802800001400Upper fixed plate of frame II
775802801400000Right body frame
1040000288Bolt M8×25-8.8GB/T5783-2000
1040300066Washer 8GB/T97.1-2002
00775802800001410Oil-filling filter support
1040200503Nut M8-8GB/T889.1-2000
1040100618Screw M4×16-8.8GB/T818-2000
1040300044Washer 4GB/T93-1987
1040301697Washer 4GB/T97.1-2002
1020404906LED Strobe light
1029906206Guard
00775802800001190Fixed plate on the outlet pipe
775802803200000Outlet pipe bracket
ZS5390RT Left Body
1040001680Bolt M10×30-8.8GB/T5783-2016
1040300061Washer 10GB/T97.1-2002
775802803800000Emergency pump bracket
1040200504Nut M10-8GB/T889.1-2000
00775802800001370Cover plate I
1040300051Washer 6GB/T97.1-2002
1040300062Washer 6GB/T93-1987
1040000096Bolt M6×12-8.8GB/T5783-2000
775802803600000Left body frame
00775802800001480Lower cover plate of left body
00775802800001140Fixed plate on the outer frame
1040000018Bolt M8×30-8.8GB/T5783-2000
1040300066Washer 8GB/T97.1-2002
00775802800001340Walking value mounting plate
1040200503Nut M8-8GB/T889.1-2000
00775802800001490Cover plate II
1040000288Bolt M8×25-8.8GB/T5783-2000
1020304979Breaker
1020202167Ground control assembly
00775802800001210Brake floating valve bracket
1040301697Washer 4GB/T97.1-2002
1040300044Washer 4GB/T93-1987
1029804041Screw M4×25-4.8GB/T70.1-2000
1040201860Nut M10QC/T608-2011
775802804000000Control mounting plate
00775606300201030Key switch gasket
1020520943Key switch
1020502039Emergency stop button head
ZS5390RT Power System
00775807100801060Intake hose
1990202290Spiral turbine vortex rod clamp
1000100391Air filter assembly
00775807100801020Intake pipe I
1990202288Spiral turbine vortex rod clamp
00775807100801040Intake steel pipe
00775807100801030Intake pipe II
00775807100601140Plate III
00775807100601120Plate I
00775807100601080Windshield
00775807100601230Mounting plate I
00775807100601150Plate IV
00775807100601111Water tank mounting plate
1000300735Expansion tank
00775807100601160Bending plate VI
00775807100601190Outlet pipe I
1990202287Spiral turbine vortex rod clamp
00773407140601060Joint I
00775807100601180Outlet pipe
00775807100601201Water supply pipe
1990202282Turbo rod clamp
00773407100601130Sponge bar
1000200483Radiator assembly
00773407140601040Backwater pipe I
00773407140601070Joint II
00773407140601050Backwater pipe II
1040200170Nut M12-8GB/T889-1986
1040302821Washer 12GB/T96.1-2002
1040002262Bolt M12×55-10.9GB/T5783-2000
00775807100601070Bending plate III
ZS5390RT Power System
00773407100601140Pad plate
1040302490Washer 12GB/T97.1-2002
00775807101001061Exhaust pipe I
00773407151001060Seal gasket
00775807101001010Silencer
00775807101001080Exhaust pipe
00775807101001070Tail pipe
00775807101001130Thermal baffle
775807101010000Support plate
1009900968Elastic coupling assembly
00773407140201010Coupling cover
1000000867Diesel oil engine
00775807100201040Bending plate IV
1040200161Nut M16-8GB/T889-1986
1009900979Engine damper
00773407100201050Pad plate
1040302492Washer 16GB/T97.1-2002
1040003912Bolt M16×120-10.9-DKLGB/T5783-2000
00775807100201030Bending plate III
1009901074Oil-water separator
00775807100401260Bending plate
1990200692Plastic coating tape
00775807100401010Fuel tank assembly
ZS5390RT Hydraulic System
1140101477Right angle built-up joint
M18×1.5
1140207362End straight coupling
1010601369Re-fill filter
1040300061Washer 10GB/T97.1-2002
1040300067Washer 10GB/T93-1987
1040000116Bolt M10×20-8.8GB/T5783-2016
1010601137High pressure filter
1140101820End straight coupling
1140101478Right angle built-up joint
M22×1.5
1040301515Washer 8GB/T97.1-2002
1040301510Washer 8GB/T93-1987
1040004519Bolt M8×25-8.8GB/T5783-2000
1140108904Joint M30-M30
1140105928End straight coupling
1010400309Heat sink
1040200503Nut M8-8GB/T889.1-2000
1040300066Washer 8GB/T97.1-2002
1040300063Washer 8GB/T93-1987
1040000689Bolt M8×35-8.8GB/T5782-2000
1140101462End straight coupling
G3/8/M18×1.5
1010307105Electromagnetic value
1040102034Screw M8×60-10.9GB/T70.1-2000
1140107801Joint
1140111237End straight coupling
1140113796Combination joint
1010307050Floating balance valve
1140111518Joint
1010601341Return oil filter
775805200210000Oil tank
1010500340Fuel tank air filter
ZS5390RT Hydraulic System
775805200230000Cover assembly
775805200220000Cover plate rubber pad
1019901354Liquid level thermometer
1140101707End straight coupling G3/4/M30×2
1140101941End straight coupling G3/8/M16×1.5
1140101487Three-way combination joint M16×1.5
1140103362End straight coupling G1/M36×2
1140101482Right angle built-up joint M20×1.5
1140101524End straight coupling G1/2/M20×1.5
1010306021travel split-flow valve
1140114899End straight coupling
1019807527Two-speed brake floating block
1140101475Right angle combination join
1019900975Plug
1010307006Lift control valve
1140111291Three-way combination joint
1040301502Washer 10GB/T93-1987
1040100059Screw M10×20-8.8GB/T70.1-2008
1140114187Pressure joints
1140101464End straight coupling G1/2/M22×1.5
1010001903Auxiliary pump
1010307007Lifting cylinder balance valve
1140101534Right angle built-up joint M30×2
1140101523End straight coupling G3/4/M30×2
1140101465End straight coupling G3/8/M22×1.5
1010307008Lifting cylinder balance valve
1140114627End straight coupling
1140112820End straight coupling
1010100908Travel motor
1040301503Washer 12GB/T93-1987
ZS5390RT Hydraulic System
1040006277Bolt M12×30-10.9GB/T16674.1-2004
1140114622Elbow adjustable directional joint
1140101737Right angle built-up joint M36×2
1010001908Gear pump
1140114045Hydraulic pipe joint M22×1.5-G3/4
1140101476Right angle built-up joint M16×1.5
1140114623End straight coupling
1140112828End straight coupling
1140103421End straight coupling
1010002352Closed pump
1140111770End straight coupling
1140105936End straight coupling
1010800165Accumulator
1140103016End straight combination coupling
ZS5390RT Scissor Arm Pin
775800300400000Internal scissor arm I
775800300200000External scissor arm I
775800300600000External scissor arm II
775800300800000Internal scissor arm II
775800301200000Internal scissor arm III
775800301000000External scissor arm III
775800301400000Internal scissor arm IV
775800301800000Internal scissor arm V
775800301600000External scissor arm V
00775800300001180Slot IV
00775800300001170Slot III
775800302200000Link
775800303000000Slot II Weld
775800302800000Slot I Weld
1040003970Bolt 1/2-13UNC-35-8.8GB/T5783-2000
1040300054Washer 12GB/T93-1987
1040300526Washer 12GB/T97.1-2002
00773400200001070Stop pin
00775800300001010Axle I
1054400367Composite bush
1040000689Bolt M8×35-8.8GB/T5782-2000
1040200503Nut M8-8GB/T889.1-2000
00775800300001210Stop pin
00775800300001050Short connecting rod axle
1054400313Composite bush
ZS5390RT Scissor Arm Pin
00775800300001240Axle II
1040303158Retaining ring 58
00775800300001230Gasket
1054400315Composite bush
00775800300001080Spacer
1040000067Bolt M12×45-8.8GB/T5782-2000
1040200507Nut M12-8GB/T889.1-2000
00775800300001030Axle III
1054400363Composite bush
1040000076Bolt M6×25-8.8GB/T5783-2000
1040200506Nut M6-8GB/T889.1-2000
00775800100001140Stop pin
00775800300001060Slot coupling shaft
00775800300001040Long linkage axle
00775800300001160Limit block I
00775800300001220Limit block II
1040300154Bearing 25GB/T894.1-1986
1040200504Nut M10-8GB/T889.1-2000
1040000114Bolt M10×25-8.8GB/T5783-2000
1040300027Washer 10GB/T96.1-2002
1040000068Bolt M10×50-8.8GB/T5782-2000
1040000025Bolt M10×80-8.8GB/T5782-2000
00775800300001150Limit sensor bracket
ZS5390RT Scissor Arm Accessory
1040103310Bolt M8×45-8.8GB/T70.3-2000
1040300066Washer 8GB/T97.1-2002
1040200503Nut M8-8GB/T889.1-2000
00775800302001010Lower sliding block
00775800302001020Upper sliding block
775800302100000Lower sliding connecting seat
1040100024Screw M8×65-8.8GB/T70.1-2000
1040300063Washer 8GB/T93-1987
1010307007Lift cylinder balance valve
1010201639Upper lift cylinder
1010201638Lower lift cylinder
1010307008Lift cylinder balance valve
1040001283Bolt M10×45-8.8GB/T5782-2000
1040300061Washer 10GB/T97.1-2002
1040200504Nut M10-8GB/T889.1-2000
775800300001100Safety arm block
1100400030Swing gate pin
00775800300001090Arcuate connecting plate of safety arm
00775800300001110Arcuate stop block of safety arm
1040000117Bolt M10×90-8.8GB/T5782-2000
00775800300001070Safety arm fastening block
775800302400000Safety arm
00775800300001190Cushion
ZS5390RT Platform
1040200503Nut M8-8GB/T889.1-2000
1040000649Bolt M8×50-8.8GB/T5782-2000
1040502050D pin 8×53
00775800100001170Limit block
1040000464Bolt M8×75-8.8GB/T5782-2000
1040300066Washer 8GB/T97.1-2002
1040200506Nut M6-8GB/T889.1-2000
1040300051Washer 6GB/T97.1-2002
1040000700Bolt M6×60-8.8GB/T5783-2000
1101000163Spring hinge
00775602800001180Coil II
775800103000000Upper slide rail
1040001179Bolt M12×35-8.8GB/T5782-2000
1040200507Nut M12-8GB/T889.1-2000
1040300526Washer 12GB/T97.1-2002
775800103400000Linkage bracket of scissor arm
1040300061Washer 10GB/T97.1-2002
1040300067Washer 10GB/T93-1987
1040001595Bolt M10×35-8.8GB/T5783-2000
775800100200000Lower components
ZS5390RT Platform
775800104600000Guard rails IV
775800104000000Guard rails I
775800104400000Guard rails III
775800104200000Guard rails II
775800104800000Platform gate
775800105000000Bending rack
1040300062Washer 6GB/T93-1987
1040000076Bolt M6×25-8.8GB/T5783-2000
00775800100001050Trolley mounting plate I
1040100237Screw M6×30-8.8GB/T70.1-2000
00775800100001130Nylon block
00775800100001140Stop pin
775800100001200Gasket I
1052500006Bearing 6004-2RSGB/T 276-1994
00775800100001070Trolley III
00775800100001080Pin II
1040100105Screw M6×25-8.8GB/T70.1-2000
1040502051D pin 8×70
ZS5390RT Platform Gate
775800104810000Platform Gate Weldment
00775600101801020Spring
00775600101801010Key cylinder
1040000469Bolt M8×55GB/T5783-2000
1040200503Nut M8-8GB/T889.1-2000
1040300066Washer 8GB/T97.1-2002
ZS5390RT Platform Pulley
00775800103601010Roller II
1052500006Bearing 6004-2RSGB/T 276-1994
1040300002Bearing 42GB/T893.1-1986
ZS5390RT Extension Deck
1040502050D pin 8×53
00775800100001170Limit block
1040000649Bolt M8×50-8.8GB/T5782-2000
1040200503Nut M8-8GB/T889.1-2000
00775800100001190Square plug
775800101800000Guard rails II
775800102000000Guard rails III
775800101600000Guard rails I
1040502051D pin 8×70
1999904986Storage box
1040102341Screw M5×12-8.8GB/T70.1-2000
1040300048Washer 5GB/T97.1-2002
1040200867Nut M5-8GB/T889.1-2000
1040000137Bolt M8×65-8.8GB/T5782-2000
1040300066Washer 8GB/T97.1-2002
1040100024Screw M8×65-8.8GB/T70.1-2000
00775800100001030Clamp
775800102400000Tension grip
775800102800000Tie rod
775800100400000Lower components
ZS5390RT Extension Deck
1040000464Bolt M8×75-8.8GB/T5782-2000
00775800102601030Nylon spacer
775800100001200Gasket I
1040300167Washer 20GB/T894.1-1986
775800102610000Trolley bracket weldment
00775800102601020Trolley I
1052500006Bearing 6004-2RSGB/T 276-1994
00775800102601040Pin III
1040200504Nut M10-8GB/T889.1-2000
1040300061Washer 10GB/T97.1-2002
1040001680Bolt M10×30-8.8GB/T5783-2016
00775800100001090Side guard of extension deck
00775800100001110Rubber spacer
1040201674Nut M8-8GB/T13681-1992
1040000018Bolt M8×30-8.8GB/T5783-2000
00775800103801020Bending plate I
00775800103801030Bending plate II
00775800103801010Tooth block
1040102717Screw M8×40-8.8GB/T70.3-2000
ZS5390RT Series Decal Installation
00775307080402040Label- Store the Operation and Safety Manual
00775307010402010Label- Safety Rules
00775207010403070Danger- Tip-over Hazard
00775307080202090Label- Lanyard Anchorage Point
00775307080402030Label- Read the Instructions
775807010401100Danger- Crushing Hazard、Guardrail
00775307040401040Danger- Crushing Hazard
00775307040401050Label- Safety Arm
00775807010201080Label-Stay Away From Outriggers
00775807010201070Label-Outriggers Load
00775807010201120Label-Heading
00775807010401140Label- Wheels Load
00775807010201170Forbidden Trample
00775807010401110Label-Maintenance of Compartment
00775807000201160Label-4×4
00775307080202010Label- Tie-down and Lifting
00775807010201130Label-Rated Load
00775307080402120Danger- Crushing Hazard
00775307080402170Label- Max Manual Force
00775307080402110Main Power Switch
ZS5390RT Series Decal Installation
00775807010401060Danger-Scalding
00775307080402130Pre-operation Inspection
00775807000201060Label-Key Switch
00775807000201170Label-Insurance
775807000401200Label-Low Temperature Start
00775807010401040Forbidden on Water
00775807010401190Danger- Explosion HazardⅠ
00775807010401030Hydraulic Oil Tank
00775407000201110Label-Liquid Level
00775807010401010Diesel Tank
00775807010201020Fill up as Instructed
00775307080402060Danger- Explosion and Fire Hazard
00775807010401160Forbidden Touch
00775807010401050Disconnecting Battery

Comments are closed.

↑
