ZOOMLION ZLJ5500V3 TRUCK CRANE PARTS LIST Z
1130000215 Driver’s cab
671554900000000 Driver’s cab installation
672303400000000 Steering system
672300900000000 Intercooling system
672301300000000 Cooling system
672307600000000 Air conditioning
672301000000000 Engine and suspension system
672305100000000 Engine housing assy.
672305800000000 Wall panel and its installation
00672302800000001 Chassis frame assy.
672307900000000 Guard rail (top)
00672303500000002 Air brake system
00672301100000001 Fuel supply system
672305500000000 Spare tire installation
672306300000000 Electrical system, chassis frame
672309400000000 Toolbox assy.
672305600000000 Platform assy.
672303100000000 Wheel assy.
672302400000000 Drive axle pre-assembled, non-steered
672302900000000 Suspension system
672302500000000 Drive axle pre-assembled, non-steered
672302200000000 Drive shaft arrangment
672303000000000 Front axle assy.
672301400000000 Air intake system
672301600000000 Clutch installation and its controls
672301700000000 Transmission installation and its controls
672306100000000 Undercarriage electrics
672301200000000 Exhaust system
671407700000000 Heater
672302700000000 Auxiliary element installation, chassis frame
631320300000000 Boom support
1011200023 Central revolving joint
631323000000000 Hydraulic oil tank
631255810000000 Outrigger operating mechanism
00631321700000002 “Pipe layout – undercarriage hydraulic system,import pump”
631321710000000 Pipe layout – undercarriage hydraulic system, variable capacity pump
00631323900000001 Oil pump drive device, import pump
631323910000000 Oil pump drive device, variable capacity pump
631321100000000 The 5th outrigger and its installation
1000500003 Intercooler
1990200524 Clamp for intercooler 155-165 9199-0165
00671820900001010 Air intake pipe of intercooler
00671820900001020 Intercooler air outlet pipe
1040000098 Bolt
1040300063 Seal ring
1040300066 Seal ring
671821000200000 Engine front seat
1040000119 Bolt
1040200112 Baffle
1040300068 Seal ring
1040300055 Seal ring
1000000182 Diesel engine 13027587(EU II)
1040000110 Bolt
1040200192 Baffle
1040300063 Seal ring
1040300066 Seal ring
1001500000 Engine front bearing
00676601000001020 Rear bearing for engine (left)
1040000215 Bolt
00676601000001010 Rear bearing for engine (right)
1040000069 Bolt
1040300054 Seal ring
1040300041 Seal ring
1040000127 Bolt
1001500003 Wedge support assy.
204100001 Diesel oil CH-4
00672301100001010 Oil delivery hose
1990200518 Wrom clamp
00672301100001020 Oil delivery hose
1990200044 Pipe clamp
00633160000000015 Fittingbolt
1081000017 O ring
671551100200000 Corrugated union
671601100200000 Tightening belt
1040200096 Baffle
00676601110001010 Fuel tank bracket
1990300002 Rubber pad
00671521100200001 Fuel tank (300L)
1040000082 Bolt
1040300065 Seal ring
1040200110 Baffle
1040500108 Pin
1040500075 Pin
1040300041 Seal ring
00676601100001030 Cushion strap
00671551100001010 Blanking plug
00671621130001030 Fitting
00672301100001030 Oil delivery hose
671441100200000 Fuel coarse filter pre-assembled
1990200008 Nylon strap
202230000 Epoxy resin
1000400104 Drain filter assy., water 6
1040000072 Bolt
1040300067 Seal ring
1040300061 Seal ring
1040200113 Baffle
1040000237 Bolt
1009800841 Oil tank cover
1009800844 Screw
1009800840 Filter screen
1009800843 Oil drain bolt with copper shim
1990200539 T type clamp(without spring)
1000100159 Air intake pipe
1990201278 T type clamp φ122-φ129 P148344
1040000069 Bolt
1040300054 Seal ring
1040200096 Baffle
670401410600000 Tightening belt
671821400200000 Air filter bracket
1000100000 Air filter KLQ-107F
1040300041 Seal ring
1990300002 Rubber pad
671821200400000 Silencer housing
1000200030 Silencer assy.
671701210200000 Rainproof cap assy.
1040000018 Bolt
1040200192 Baffle
1040300063 Seal ring
00671821200001010 Gasket
00672301200200001 Pipe welded 6160-121020-0000
1040000432 Bolt
1040300066 Seal ring
1040000090 Bolt
1040300067 Seal ring
1040000101 Bolt
1040200096 Baffle
1040300054 Seal ring
00671821200001020 Gasket
671701210210000 Cap assy.
1040500161 Pin
1040300066 Seal ring
1040500080 Pin
671701210220000 Clamp assy.
1000300019 Radiator assy.
1990200527 Wrom clamp
1990200579 T type clamp(without spring)
00672301300001010 Water tank hose
1990200548 Wrom clamp
1040000114 Bolt
1040200113 Baffle
1040300067 Seal ring
00672301300001020 Water tank hose
00672301300001040 Water inlet pipe of water tank 6150-130000-1010
00672301300001030 Water tank hose
672301300200000 Bracket
1040200192 Baffle
1040300063 Seal ring
1040300066 Seal ring
1000300312 Expansion tank
672301300600000 Bracket assy.
1040000018 Bolt
672301300400000 Bracket
1040000104 Bolt
00671801300001050 Seal ring
00671821300001070 Seal ring
00671821300001060 Pad
1990200546 T type clamp(without spring)
00671821300001011 Drain pipe for water tank
671821300200000 Air deflector assy.
1990300007 Seal strip blackrubber 7988
1040000267 Bolt
1990200006 Nylon strap
202270028 Antifreeze fluid
1990300008 Rubber strip, U-type
1990200508 T type clamp(without spring)
1140202041 Hose assy.
1030500086 Clutch assy.
1010200010 102 type clutch booster cylinder
1040200148 Baffle
1140100961 Fitting body 35
1140100934 Cutting sleeve
1040000288 Bolt
1040300063 Seal ring
202990042 T3 brake fluid
1990200008 Nylon strap
1009800897 Release bearing assy.
P10300001353 Snap ring assy.
1039803807 Pressure disc, clutch
1039803808 Clutch cover assy.
P10300000599 430 driven disc assy.(used for RTX-16710B clutch friction plate)
102 type clutch booster cylinder
672301700200000 Support
1040200152 Baffle
00671801710001010 Rubberprotecting jacket
1040000288 Bolt
1040200192 Baffle
1040300063 Seal ring
1031700049 Flexible shaft control mechanism assy. 194- 001-001
1030300100 Transmission
1040000114 Bolt
1040300067 Seal ring
00672301700001010 Bracket
00672301700001030 Selector rocker arm
1040000110 Bolt
1040000077 Bolt
00672301700001020 Bracket
1031300004 Flexible shaft assy. 183-256-150
00672301700001040 Rod
1001500000 Engine front bearing
1040000069 Bolt
1040300054 Seal ring
1040300081 Seal ring
00676601700220001 Crossbeam assy.
1040300094 Seal ring
00676601700201010 Stud
1040300064 Seal ring
1040200110 Baffle
1040200098 Baffle
204110014 Lithium base grease
202230016 Loctite glue
204050005 Gear oil for heavy duty vehicle
00671401710001010 Warning sign
1990200008 Nylon strap
1039803857 Bearing cover
1039801337 Skeleton oil seal assy.
1040201397 Hex locking nut
1050000399 Knuckle bearing
1039803858 Release yoke bracket
1030500013 Release fork
1039803859 Release yoke spindle
1039803860 Lubricating pipe assy., release bearing
1039803861 Pipe fitting
1039803862 Lubricating grease cup seat
1039803863 Lubricating grease cup cover
1039803864 Clutch housing assy.
1039800803 Cover
1040201398 Hex nut
1039803865 Cover
1039803866 Sliding sleeve, axle 2
1039800810 Gear pad, axle 2
1039800778 Gear spline, axle 2
1039803867 Gear of overdrive gear, axle 2
1039800779 Stop ring
1039803868 2nd gear, axle 2
1039803869 1st gear, axle 2
1039803870 Gear of low gear, axle 2
1039803871 Reverse gear, axle 2
1039801457 Elastic cylindrical pin
1039803872 Hex spindle, axle 2
1039803873 Axle 2
1040003420 Hex bolt
1039800826 Bearing baffle, intermediate shaft
1039800945 Bearing
1039801308 Stop ring
1039800823 Stop ring, intermediate shaft
1039803874 Drive gear, intermediate shaft
1039801309 Spacer sleeve
1039803875 Power take wheel
1039803876 Gear of overdrive gear,intermediate axle
1039803877 2nd gear, intermediate shaft
1039803878 Gear of 1st gear,intermediate axle
1039803879 Square spline, intermediate shaft
1039800686 Semicircular key
1039803880 Intermediate shaft
1039800752 Cylindrical roller bearing
1039800771 Stop ring
1039800779 Stop ring
1039803881 Steel wire woven retaining ring
1039801307 Stop ring
1039800790 Eccentric ball bearing 900033
1039800802 Gear pad
1039803882 Gear, axle 1
1039803883 Axle 1
1039900164 Guide sleeve, axle 2
1039800769 Reverse gear washer, intermediate shaft
1039800768 Reverse gear, thrust washer
1039800770 Needle bearing
1039803884 Reverse gear, intermediate gear
1039803885 Reverse gear washer
1039800801 Reverse gear, intermediate shaft
1039803886 Guide block, 3rd and 4th gears
1039803887 Fork
1039803888 Yoke spindle, 4th and 5th gears
1039800905 Locking screw
1039800807 Rod
1039803889 Cover
1039800800 Pin, yoke spindle
1039800793 Pin, switch
1039803890 Pressure switch
1039800815 Steel ball
1039800761 Steel ball
1039801177 Pressure switch
1040201399 Hex nut
1039800757 Yoke assy. of reverse gear, low
1039800776 Guide block, 1st and 2nd gears
1039803891 Yoke spindle, 1st reverse gear
1039803892 Yoke spindle, 2rd and 3rd gears
1039803893 Yoke, 3rd and 4th gears
1039803894 Supporting pin
1039803895 Swing shifting block
1039803896 LRC schaltarm
1040000215 Bolt
1040300067 Seal ring
1040200199 Baffle
1039801340 Oil seal
1039803897 Shifting block
1040101918 Screw
1039800791 Ventilation plug
1039801360 O ring
1039803898 Air filter and threaded plug assy.
1039800806 Stop ring
1039801311 Retaining ring
1039800804 Stop ring
1039800957 Bearing with stop groove
1039801306 Stop ring
1039803899 Positioning disc of bearing, auxiiary tank
1039803900 Drive gear
1039803901 Main shaft, auxiliary tank
1039803902 Synchronizer assy., high and low gears
1039803903 Pressure plate of main shaft gear, auxiliary tank
1039803904 Shim
1039803905 Main shaft reducer gear, auxiliary tank
1039803906 Bushing, odometer
1140103366 Flange nut
1039800946 Cylindrical roller bearing
1039803907 Intermediate shaft welded assy., auxiliary tank
1039803908 Intermediate shaft welded assy., auxiliary tank
1039803909 Cylindrical roller bearing
1040300067 Seal ring
1039801360 O ring
1039803910 Housing, rear cover
1039803911 Cover
1040102118 Hex bolt
1040003422 Hex bolt
1040003423 Hex bolt
1039803912 Tapered roller bearing
1039803913 Cover
1039803914 Pad
1040003424 Hex bolt
1039801063 Driven gear shaft sleeve, odometer
1040002869 Hex bolt
1039801338 Odometer fitting
1039803915 Output flange disc
1039801345 Dust cover
1039801310 Bearing cover oil seal
1039800822 Oil seal
1039801431 Drive gear, odometer
1039801432 Driven gear, odometer
1040300067 Seal ring
1039803916 Yoke, auxiliary tank
1040003425 Hex bolt
1081003781 O ring
1039803918 O ring
1081003782 O ring
1039801478 Flange
1039803920 PTO housing
1039803921 Fork
1040000443 Bolt
1040200498 Baffle TB/T3019-2001 BY M14×1.5F-10
672302200200000 Drive shaft section
1040300122 Seal ring
671532230400000 Drive shaft section 2 assy.
676602230600000 Drive shaft section 3 assy.
204110014 Lithium base grease
1039803810 Flange fork
1039800687 Snap ring
1039803812 Cross shaft assy.
1039803811 Universal knuckle fork
1039803809 Spindle shaft head
1039803815 Intermediate shaft bearing assy.
1080000206 Oil cup
1039803821 Intermediate flange
1039803816 Baffle
1039803810 Flange fork
1039800687 Snap ring
1039803812 Cross shaft assy.
1039803813 Spindle shaft fork
1080000237 Oil cup
1039803805 Protecting jacket pipe with oil seal assy.
1039803814 Spline hub
1039803811 Universal knuckle fork
1039800787 Flange fork
1039800687 Snap ring
1039800688 Cross shaft assy.
1039800786 Shaft fork
1039803749 Protecting jacket pipe with oil seal assy.
1080000252 Oil cup
1039800789 Spline hub
1039800788 Universal knuckle fork
1030100752 Non-driven axle (steered)
204110013 Lithium base grease
1040002381 Bolt
1040300068 Seal ring
1040300266 Seal ring
00672303000201010 Bracket
1039803833 Hex bolt
1139801137 Springwasher
1039802901 End cover, front axle
1039803835 Cross-recessed flat-head screw
P10300001812 Brake hub 72011028
