03B0050 BS305-31 NUT

1 05B0024 000 螺柱 STUD 4
2 03B0173 000 螺母 NUT 4
3 06B0008 000 垫圈 WASHER 4
4 06B0020 000 垫圈 WASHER 4
5 80A0010 001 密封垫片 GASKET 1
6 00A3383 000 接头 CONNECTOR 1
7 06B0293 000 垫圈 WASHER 1
8 11C0700 000 变速泵
VARIABLE-SPEED
PUMP
1
9 00B0064 000 螺栓 BOLT 6
10 06B0002 000 垫圈 WASHER 8
11 01B0033 000 螺栓 BOLT 2

1 80A0013 000 密封垫片 GASKET 1
2 21B0005 000 球轴承 6012 BALL BEARING 1
3 21B0006 000 球轴承 6311 BALL BEARING 1
4 80A0014 001 密封圈 GASKET 1
5 00B0002 000 螺栓 BOLT 26
6 06B0002 000 垫圈 WASHER 56
7 21B0023 002 日本 NSK6210NR BALL BEARING 2
8 26B0002 000 推力球轴承 51111 BALL BEARING 1
9 21B0007 000 球轴承 6016 BALL BEARING 1
10 80A0015 000 油封环 SEAR RING 1
11 40A0004 003 输入一级齿轮 GEAR 1
12 40A0005 002 输入二级齿轮 GEAR 1
13 80A0016 000 油封环 SEAL RING 1
14 52C0071 000 超越离合器
OVERRUN
CLUTCH
1 Z
15 07B0011 000 挡圈 SNAP RING 1
16 42C0094 001 倒档行星架组件
PLANET
CARRIER AS
1 Z
17 42C0092 001 一档行星架组件
PLANET
CARRIER AS
1 Z
18 42C0013 000 倒挡活塞总成 PISTON AS 1
19 75A0009 000 弹簧 SPRING 15
20 60A0036 000 弹簧销轴 GUIDE PIN 15
21 07B0009 000 挡圈 SNAP RING 2
22 13B0169 000 油封 OIL SEAL 2
23 12B0105 000 O 形圈 O-RING 2
24 55A0061 002 隔套 SPACER 2
25 71A0117 002 油封座 SEAL SEAT 2
26 56A0027 000 垫圈 WASHER 2
27 21B0008 000 球轴承 6312 BALL BEARING 3
28 55A1094 001 轴套 SPACER 1
29 62A0011 003 输出轴 OUTPUT SHAFT 1
30 41A0044 004 输出轴齿轮
OUTPUT SHAFT
GEAR
1
31 01A0014 001 泄油管 DRAIN TUBE 1
32 53A0027 000 挡油盖 OIL RETAINER 1

33 03B0050 000 带槽螺母 NUT 2
34 08B0032 000 销 PIN 2
35 12B0034 000 O 形圈 O-RING 4
36 00B0025 000 螺栓 BOLT 4
37 06B0013 000 垫圈 WASHER 4
38 80A0098 000 密封垫 GASKET 1
39 53A0171 003 端盖 END COVER 1
40 00B0121 000 螺栓 BOLT 8
41 06B0008 000 垫圈 WASHER 8
42 53A0029 000 中盖 COVER 1
43 42C0102 001 直接档组件
DIRECT DRIVE
GP
1 Z
44 00B0019 000 螺栓 BOLT 8
45 41A0013 005 一档内齿圈 1ST RING GEAR 1
46 42C0011 000 一挡油缸总成
1ST CYLINDER
AS
1
47 42C0012 000 一档活塞总成
1ST CLUTCH
PISTON AS
1
48 52C0147 000 箱体 HOUSING 1
49 56A0030 002 倒档一档从动片 DRIVEN DISK 8
50 37C0002 003
倒挡一档主动片总
成
DRIVE DISK 8
51 52C0005 000 摩擦片隔离架总成
SPACER
ASSEMBLY
1
52 41A0009 003 太阳轮 GEAR 1
53 28C0089 002 调整垫组件
ADJUSTING SHIM
SET
2
84 55A0060 001 间隔套 SPACER 1
85 28C0102 000 调整垫圈 ADJUSTING SHIM 1
86 28C0103 000 调整垫圈 ADJUSTING SHIM 1

5 00B0002 000 螺栓 BOLT 26
6 06B0002 000 垫圈 WASHER 56
7 21B0023 002 日本 NSK6210NR BALL BEARING 2
54 60A0037 000 圆柱销 PIN 2
55 42C0014 000 透气盖总成
BREATHER CAP
AS
1 Z
56 10D0023 000 透气管 BREATHER TUBE 1
57 04B0087 000 螺钉 SCREW 2
58 05A0008 001 堵头 PLUG 2
59 12B0379 000 O 形密封圈 O-RING 2
60 60A0038 001 圆柱堵塞
CYLINDRICAL
PLUG
1
61 03A0019 000 管接头 CONNECTOR 2
62 12B0144 000 O 形密封圈 O-RING 2
63 00B0018 000 螺栓 BOLT 15
64 01B0028 000 螺栓 BOLT 3
65 82A0025 001 密封垫 GASKET 1
66 60A0040 000 圆柱销 PIN 1
67 10A0065 002 固定板 PLATE 1
68 43B0006 000 放水塞 PLUG 2
69 00B0020 000 螺栓 BOLT 6
70 06B0006 000 垫圈 WASHER 6
71 43B0003 001 磁铁 MAGNET 1
72 07B0012 000 挡圈 SNAP RING 1
73 53A0930 000 密封压盖 PACKING GLAND 1
74 56A0032 000 垫片 GASKET 2
75 53C0027 000 滤油器 OIL FILTER 1
76 21B0013 000 球轴承 6010 BALL BEARING 1
77 04B0022 000 螺钉 SCREW 4
78 55A0063 000 隔圈 SPACER 1
79 12B0035 000 O 形圈 O-RING 1
80 03B0080 000 螺塞 PLUG 1
81 12B0351 000 O 形密封圈 O-RING 1
82 74A4010 000 铭牌 NAMEPLATE 1
83 09B0002 000 铆钉 RIVET 4
87 00A3383 000 接头 CONNECTOR 1
88 06B0293 000 垫圈 WASHER 1

1 00A0114 001 接头 CONNECTOR 2
2 06B0189 000 垫圈 WASHER 4
3 09C0354 000 管夹总成 CLAMP 1
4 00C0001 000 弯管 ELBOW 1
5 53C0085 001 滤油器 OIL FILTER 1
6 07C0558 000 变矩器至散热器软管 HOSE 1
7 52C0062 005 变矩器总成
TORQUE
CONVERTER
1
8 07C0185 000 变速箱至滤油器软管 HOSE 1
9 00C0002 000 变速泵进油管 PIPE 1 Z
10 00B0011 000 螺栓 BOLT 2
11 06B0008 000 垫圈 WASHER 8
12 61A0351 000 轴 SHAFT 1
13 01B0142 000 螺栓 BOLT 6
14 07C0836 000 变矩器至散热器软管 HOSE 1
15 12B0271 000 O 形圈 O-RING 2
16 03A0019 000 管接头 CONNECTOR 2

1 00B0007 000 螺栓 BOLT 8
2 06B0006 000 垫圈 WASHER 8
3 11A0011 001 垫板 PLATE 1
4 82A0004 000 衬垫 GASKET 1
5 70A0001 004 壳体
CONVERTER
HOUSING
1
6 42C0042 000 变矩器 CONVERTER 1
7 00B0012 000 螺栓 BOLT 9
8 06B0002 000 垫圈 WASHER 21
9 03A0019 000 管接头 CONNECTOR 2
10 12B0144 000 O 形密封圈 O-RING 2
11 65A0001 000 阀杆 VALVE STEM 1
12 10B0002 000 弹簧 SPRING 1
13 13A0011 000 压板 PLATE 1
14 10B0001 000 弹簧 SPRING 1
15 21A0005 000 阀盖 COVER 1
16 65A0002 001 阀杆 VALVE STEM 1
17 12B0291 000 O 形密封圈 O-RING 1
18 03B0051 000 螺塞 PLUG 1
19 28C0093 001 调整垫组件
ADJUSTING SHIM
SET
1
20 00B0058 000 螺栓 BOLT 12
21 06B0008 000 垫圈 WASHER 12
22 81A0005 000 衬垫 GASKET 1
23 10A0010 000 弹性板 PLATE 1
24 12D0002 000 弹性板总成 PLATE AS 1 Z
25 05B0004 000 螺柱 STUD 12
26 03B0053 000 螺母 NUT 12
29 09B0002 000 铆钉 RIVET 4
30 74A1168 000 变矩器铭牌 NAMEPLATE 1
31 05A0008 001 堵头 PLUG 1
32 12B0379 000 O 形密封圈 O-RING 1
33 12B0339 000 O 形密封圈 O-RING 1
34 00A0170 000 油温表接头 JOINT 1

1 10A0010 000 弹性板 PLATE 1
2 56A0008 000 垫片 SHIM 6
