Description

15053690G INJECTOR M26.2 BAUDOUIN

SR MODEL PART NO DESCRIPTION
1 J135 J135-01-024A CLUTCH CASING
2 135 135-01-007 THRUST RING AT INPUT END
3 135 135-01-019 OIL DISTRIBUTOR
4 135 135-01-003 BOLT
5 135 135-01-017 KEY
6 135 135-01-015A OIL SEALING
7 135 6317-N BEARING
8 135 1201-0007B OUTER FRICTION PLATE
9 135 1201-0019A INNER FRICTION PLATE
10 135 135-01-020A DISTRIBUTOR SLEEVE
11 135 135-01-012 SUPPORTING RING OF TORSIONAL SHAFT
12 135 135-01-024A CLUTCH CASING
13 135 1201-0018B OUTER FRICTION PLATE SINGLE SINTERED
14 135 135-01-016B THRUST PLATE
15 135 135-01-011A CARRIER OF FRICTIONAL PLATE
16 135 135-01-018A SPRING
17 135 NJ313EM BEARING
18 135 6315N BEARING
19 135 N2313EKM BEARING
20 135A 135A-03A-016A SLEEVE
21 135 22220CA BEARING
22 135 NJ316EM BEARING
23 135 115X140X14 OIL SEAL
24 135 135A-03A-004A OUTPUT COUPLING
25 135 QB21-03-M14B ADAPTOR SCREW
26 135 QB21-03-M14A ADAPTOR SCREW
27 135 GB858-88 24 WASHER
28 135 GB812-88 M 24 NUT
29 135 6207 BEARING
30 135 J135-06-001A OIL PUMP TRANSMISSION GEAR
31 300 300-01-020 EMERGENCY PIN
32 300 QB22-01-007 PLUG(CLUTCH BRACKET)
33 300 QB22-01-010 PLUG(SHAFT)
34 300 300-01-014-1 O RING
35 300 GB/T5783-2000 M 20X45 BOLT
36 300 300-01-012 PISTON RING
37 300 300-01-005/4.5 DRIVE GEAR
38 300 300-01-005/5 DRIVE GEAR
39 300 300-01-014-01 O RING
40 300 300-01-018 SAFETY PIECE
41 300 300-01-016 SEALING RING
42 300 300-01-002 INPUT ADJUSTING RING
43 300 D300-01A-007 WEAR PLATE
44 300 300-01-004-B WEAR PLATE
45 300 300-01-019C AHEAD DRIVE GEAR
46 300 300-01-101 CLUTCH BRACKET
47 300 300-01-007 NUT
48 300 GB/T858-1988 105 LOCK WAHER
49 300 300-01-102 INPUT SHAFT
50 300 300-01-011B PISTON
51 300 300-01-008A THRUST PLATE
52 300 300-01-010A INTERNAL DISC
53 300 300-01-009B EXTERNAL DISC
54 300 300-01-003 COUPLING BRACKET
55 300 QJ222M BEARING
56 300 NJ221EM BEARING
57 300 NJ222EM BEARING
58 300 300-01-006 CLUTCH HOUSING
59 D300 D300-01A-004 CLUTCH HOUSING
60 D300 300-01-005/5 DRIVE GEAR
61 D300 D300-01-002 INPUT ADJUSTING RING
62 D300 D300-01-005 BEARING WASHER
63 300 300-02-004C ASTERN DRIVEN GEAR
64 300 300-02-101B TRANSMISSION SHAFT
65 D300 D300-02A-101B TRANSMISSION SHAFT
66 D300 D300-02-002 BEARING BRACKET
67 300 300-04-013 GASKET
68 300 300-04-017 GASKET
69 300 300-04-007 GASKET
70 300 D300-04-002 GASKET
71 300 PD125X160X15 SEALING
72 300 300-04-200 FILTER FLANGE
73 300 300-04-010 DISTRIBUTOR
74 300 FD300-04-601 FILTER ELEMENT
75 300 300-07-002B BEARING BUSH
76 300 BB-B32A INPUT PIPE ELEMENT
77 300 QB21-04-020 CONNECTING PLATE
78 300 FD300-04-621 OIL PUMP
79 300 FD300-04-631 ADAPTOR
300 OUTPUT PIPE ELEMENT
80 300 QB07-01-000 OUTPUT PIPE ASSEMBLY OF
81 QB07-02-002 OIL GUAGE
82 36A-12-200 GUAGE GROUP
83 Q08-02-00A/300 FILTER CASE
84 COMMON Q26-06-02 TOOTHED RUBBER BLOCK
85 COMMON 10MTR CABLE
