Description

250200046 860103792 9339393-A ZL40A.30.5-13A 9339393 XCMG LW521F LW541F LW500F WHEEL LOADER

1 4005080 螺栓 M14X35 Bolt 8 GB5783-86
2 4401010 弹簧垫圈 14 Washer 8 GB93-87
3 9309500 中盖 Medium Cover 1
4 9309467 一档油缸 1 st Forward Cylinder 1
5 9309511 固定板 Fixing Plate 1
6 9310472 矩型密封圈 Rectangular Seal Ring 1
7 9310069 外密封环 Outside Seal Ring 2
8 9310070 内密封环 Inside Seal Ring 1
9 9309468 一档活塞 1 st Forward Piston 1
10 9310474 一档内齿圈 Inner Gear Ring Ass. 1
11 9310469 倒档一档主动片 Reverse-1 st Driving Plate 8
12 9310475 倒档一档从动片 Reverse-1 st Feiction Plate 8
13 4005054 螺栓 M10×30 Bolt 4 GB5783-86
14 4401008 弹簧垫圈 10 Washer 4 GB93-87
15 9309727 直接档连接盘 Dircet Forward Connecting Flange 1
16 4412055 挡圈 90 Snap Ring 2 GB894.1-86
17 4745025 轴承 6210N Bearing 1 GB/T276-94
18 9318682 太阳轮 Sun Gear 1
19 9309503 止动盘 Lock Plate 1
20 9309504 一档行星架 1 st Forward Planetary Carrier 1
21 9309505 挡圈 Snap Ring 1
22 9310473 倒档内齿圈 Reversr Inner Gear Ring 1
23 9310074 摩擦片隔离架总成 Clutch Anchor Ass. 1
24 9309729 倒档行星架 Reverse Planetary Carrier 1
25 9309507 止动垫圈 Lock Washer 4
26 4401009 弹簧垫圈 12 Washer 4 GB93-87
27 4005305 螺栓 M8X12 Bolt 4 GB5783-86

28 9310078 内密封环 Inner Seal Ring 1
29 9309469 倒档活塞体 Reverse Piston 1
30 4745002 轴承 6010 Bear 1 GB/T276-94
31 9309496 一档行星轴 1 st forward Planetary Shaft 4
32 9309506 垫片 Washer 16
33 9309513 隔离套 Spacer 16
34 4724001 滚针Φ4X35 Needle Roller 176 GB309-84
35 9339393 行星轮 Planetary Gear 8
36 9309508 弹簧销轴 Guide Pin 15
37 9310080 弹簧 Spring 15
38 9309495 倒档行星轴 Revere Planetary Shaft 4
