Description

32A0003 SUCTION HOSE LIUGONG CLG856 WHEEL LOADER

1 44C0279 001 方向机安装总成
STEERING COLUMN
MOUNTING
1 Z
2 06C0092 000 软管总成 HOSE AS 1
3 00C0255 000 转向器进油管路 METERING PUMP LINES 1 Z
4 09C0092 000 管夹 CLAMP 2
5 17B0014 000 管夹 CLAMP 2
6 10A0177 000 板 PLATE 1
7 00B0004 000 螺栓 BOLT 2
8 06B0002 000 垫圈 WASHER 22
9 15D0051 000 接头 CONNECTOR 1
10 12B0285 000 O形圈 O-RING 2
11 12B0355 000 O形圈 O-RING 1
12 03B0093 002 螺塞 PLUG 1
13 12B0199 000 O形圈 O-RING 1
14 54A0071 000 压板 PLATE 1
15 00B0085 000 螺栓 BOLT 4
16 06B0006 000 垫圈 WASHER 16
17 72A0010 002 压板 SPLIT FLANGE 3
18 00B0017 000 螺栓 BOLT 16
19 06B0008 000 垫圈 WASHER 22
20 00A0309 000 管接头 CONNECTOR 1
21 12B0144 000 O形密封圈 O-RING 1
22 12B0292 000 O形圈 O-RING 9
23 15D0052 000 接头 CONNECTOR 1
24 12B0287 000 O形圈 O-RING 3
25 10D1380 000 钢管总成 PIPE AS 1
26 12B0251 000 O形圈 O-RING 3
27 72A0027 001 压板 PLATE 3
28 00B0019 000 螺栓 BOLT 20
29 11C0191 000 齿轮泵 GEAR PUMP 1
30 82A0092 000 密封垫 GASKET 1
31 00C0047 000 散热器进出油管路 RADIATOR LINES 1 Z
32 72A0003 000 压板 SPLIT FLANGE 1
33 10D1306 000 回油钢管 PIPE 1
34 12B0302 000 O形圈 O-RING 1
35 32A0003 000 吸油软管 SUCTION HOSE 1
36 15B0027 000 双钢丝式环箍 CLAMP 2
37 06B0098 000 垫圈 WASHER 1
38 31C0022 000 可调接头 CONNECTOR 2 Z
39 07C0057 001 软管总成 HOSE AS 1
40 06C0405 000 软管总成 HOSE AS 1

41 12C1047 004 流量放大阀
FLOW AMPLIFYING
VALVE
1 Z S/N 153703-UP
42 01B0283 000 螺栓 BOLT 3
43 03B0003 000 螺母 NUT 3
44 06C0404 000 软管总成 HOSE AS 1
45 06C0101 000 软管总成 HOSE AS 1
46 10C0030 000 右转向油缸
STEERING
CYLINDER-RH
1 Z
47 04B0049 000 螺钉 SCREW 8
48 10D0615 000 钢管总成 PIPE AS 1
49 12B0066 000 O形圈 O-RING 2
50 12B0370 000 O形圈 O-RING 8
51 27A0055 001 管夹 CLAMP 2
52 00B0007 000 螺栓 BOLT 4
53 06B0005 000 垫圈 WASHER 4
54 06C0102 000 软管总成 HOSE AS 2
55 06C0103 000 软管总成 HOSE AS 2
56 10D0613 000 钢管总成 PIPE AS 1
57 12B0271 000 O形圈 O-RING 2
58 10D0614 000 钢管总成 PIPE AS 1
59 10D0616 001 钢管总成 PIPE AS 1
60 15D0057 000 接头块 BLOCK 1
61 01B0036 000 螺栓 BOLT 3
62 10C0031 000 左转向油缸
STEERING
CYLINDER-LH
1 Z
63 24A0078 001 支承轨 SUPPORT RAIL 1
64 15D0060 000 接头 CONNECTOR 1
65 07C0060 001 软管总成 HOSE AS 1
