Description
4030000537 GB9877.1-FB60X85X8D LIP-TYPE PACKING SDLG SPARE PARTS
1 4110000217083 螺栓01010-51225 M12*25 BOLT01010-51225 M1*25 Y 6
2 4110000011108 垫圈12 01602-11236 WASHER 01602-11236 12 Y 1
3 4110000011116 圆垫板YB315Z5-04 RING PALLET YB315Z5-04 Y 1
4 4110000217071 弹性板YJ265-00002 ELASTIC PLATE YJ265-00002 Y 1
5 4110000217072 弹性板总成YJ265-10000 ELASTIC PLATE ASSEMBLY YJ265-10000 Y 1
6 4110000217039 罩轮1YJ280-1C-00005 COVER WHEEL 1YJ280-1C-00005 Y 1
7 4110000217079 螺母01580-10809 M8 NUT 01580-10809 M8 Y 18
8 4110000011087 垫圈801602-10825 WASHER 801602-10825 Y 1
9 4030000616 O形圈GB3452.1-300*3.55G O-RING GB3452.1-290*3.55G Y 1
10 4110000217073 挡圈04064-05020 50 SNAP RING 04064-05020 50 Y 1
11 4021000011 滚动轴承GB276-6010 BALL BEARIN GB276-6010 Y 1
12 4110000217005 涡轮组件YJ2804A10000 TURBINE UNITS YJ2804A10000 Y 1
13 4110000217074 挡圈04064-05520 55 WASHER 04064-05520 55 Y 1
14 4110000217075 导轮YJ280-4A-00005 LEADING WHEEL YJ280-4A-00005 Y 1
15 4015000241 挡圈GB893.1-110-65Mn SNAPP RING GB893.1-110-65Mn N 1
16 4021000113 滚动轴承GB276-6212 BALL BEARIN GB276-6212 Y 1
17 4110000217042 泵轮1YJ280-4A-00006(4) PUMP PULLEY 1YJ280-4A-00006(4) Y 1
18 4110000217082 螺栓01010-50835 M8*32 BOLT 01010-50835 M8*32 Y 18
19 4030000010 O形圈GB1235-130*3.1 O-RING GB1235-130*3.1 Y 1
20 4110000217022 泵轮座YJ2804A00015 PUMP PULLEY SEAT YJ280-4A-00015 Y 1
21 4110000011087 垫圈801602-10825 WASHER 801602-10825 Y 1
22 4110000217081 螺栓01010-50822 M8*22 BOLT 01010-50822 M8*22 Y 8
23 4110000217054 盖板1YJ280-4A-00007 COVER PLATE 1YJ280-4A-00007 Y 2
24 4110000011086 螺栓M8*16 01010-50816 BOLT M8*16 01010-50816 Y 1
25 4110000011087 垫圈801602-10825 WASHER 801602-10825 Y 1
26 4110000217052 骨架油封ZL30D-11-54 100*120*13 FRAMEWORK OIL SEAL 0ZL30D-11-54 Y 1
27 4110000217040 中节1YJ280-4A-00001 MEDIUM KNOT 1YJ280-4A-00001 Y 1
28 4011000794 螺栓GB21-M10*30EpZn-10.9 BOLT GB21-M10*30EpZn-10.9 N 12
29 4110000011097 垫圈10 01602-11030 WASHER 10 01602-11030 Y 1
30 4110000217084 密封垫YJ280-4A-00016 SEALING PLATE YJ280-4A-00016 Y 1
31 4110000217045 齿轮1YJ280-4DL-00001 DRIVE GEAR WHEEL 1YJ280-4DL-00001 Y 1
32 4110000217061 挡圈04064-01030 100 WASHER 04064-01030 100 Y 1
33 4110000217063 挡圈04064-05020 50 WASHER 04064-05020 50 Y 2
34 4110000217046 齿轮1YJ280-4DL-00002 GEAR 1YJ280-4DL-00002 Y 2
35 4021000011 滚动轴承GB276-6010 BALL BEARIN GB276-6010 Y 4
36 4110000217085 轴套YJ2804A00009 BOSS YJ2804A00009 Y 2
37 4110000217024 油泵轴YJ2804A00017 OIL PUMP SHAFT YJ2804A00017 Y 2
38 4110000217065 挡圈04064-08025 80 WASHER 04064-08025 80 Y 2
39 4110000217019 齿轮箱YJ2801C00001 GEAR CASE YJ2801C00001 Y 1
40 4110000217067 吊环螺钉04530-11222 M12×22 HANDLING SCREW 04530-11222 M12*22 Y 1
41 4110000217049 呼吸器1YJ320-20000① BREATHING IMPLEMENT 1YJ320-20000① Y 1
42 4030000010 O形圈GB1235-130*3.1 O-RING GB1235-130*3.1 Y 1
43 4110000217028 油封座YJ2801C00003 OIL SEAL SEAT YJ2801C00003 Y 1
44 4110000011097 垫圈10 01602-11030 WASHER 10 01602-11030 Y 1
45 4011000794 螺栓GB21-M10*30EpZn-10.9 BOLT GB21-M10*30EpZn-10.9 N 3
46 4110000217027 骨架油封0701220055 FRAMEWORK OIL SEAL 0701220055 Y 1
47 4110000217047 输出法兰1YJ315D-00020B OUTPUT FLANGE 1YJ315D-00020B Y 1
48 4110000217048 垫片1YJ315D-00021B SHIM 1YJ315D-00021B Y 1
49 4110000217036 O形圈0YJ315D-00022B O-RING 0YJ315D-00022B Y 1
50 4110000217038 垫片1YJ280-1C-00004 SHIM 1YJ280-1C-00004 Y 1
51 4110000011108 垫圈12 01602-11236 WASHER 01602-11236 12 Y 1
52 4110000217058 螺栓01010-51235 M12×35 BOLT 01010-51235 M12*35 Y 1
53 4110000217064 挡圈04064-05520 55 SNAP RING 04064-05520 55 Y 1
54 4110000217051 密封环0ZL30D-11-19 PACKING RING 0ZL30D-11-19 Y 2
55 4110000217020 导轮座YJ2804A00014 GUIDE PULLEY YJ2804A00014 Y 1
56 4011000794 螺栓GB21-M10*30EpZn-10.9 BOLT GB21-M10*30EpZn-10.9 N 6
57 4110000011097 垫圈10 01602-11030 WASHER 10 01602-11030 Y 1
58 4015000122 垫圈JB982-24 WASHER JB982-24 N 4
59 4110000217034 螺塞07044-12412A PLUG SCREW 07044-12412A Y 1
60 4110000217018 接头YJ2804C00007 JOINT YJ2804C00007 Y 1
61 4110000217001 减压阀YJ320-10000 REDUCING VALVE YJ320-10000 Y 1
62 4110000011097 垫圈10 01602-11030 WASHER 10 01602-11030 Y 1
63 4110000217056 螺栓01010-51025 M10*25 BOLT 01010-51025 M10*25 Y 4
64 4110000217037 纸垫1YJ265-00012 PAPER WASHER 1YJ265-00012 Y 1
65 4110000217023 回油阀YJ26540000 OIL RETURN VALVE YJ26540000 Y 1
66 4110000217057 螺栓01010-51095 M10*95 BOLT 01010-51095 M10*95 Y 4
67 4110000011097 垫圈10 01602-11030 WASHER 10 01602-11030 Y 1
68 4110000217062 挡圈04064-03818 38 WASHER 04064-03818 38 Y 1
69 4110000217006 涡轮轴YJ2801C00002 TURBOSHAFT YJ2801C00002 Y 1
70 4110000217069 密封环YJ265-00014 PACKING RING YJ265-00014 Y 1
71 4021000021 滚动轴承GB276-6308 ROLLING BEARING GB276-6308 Y 1
72 4110000217066 挡圈04065-09030 90 SNAP RING 04065-09030 90 Y 1
73 7200000842 分油套YJ280-4A-00011 OIL-SEPARATING BARGE COWL YJ280-4A-00011 Y 1
74 4110000217043 油泵轴1YJ280-4A-00010X① OIL PUMP SHAFT 1YJ280-4A-00010X① Y 1
75 4110000084064 定位销1ZL30D-11-22 SET PIN Y 4
76 4110000217033 螺塞07043-00312 PLUP SCREW 07043-00312 Y 2
77 4110000217086 标牌YJ280-1DL-BP BRAND N 1
78 7200000846 铆钉3*6 04418-03060 RIVET 3*6 04418-03060 N 4
79 4110000217087 变速泵CB-FA25-FL-X SHIFT PUMP CB-FA25-FL-X Y 1
80 4110000217050 垫1YJ380Q-00021 CUSHION 1YJ380Q-00021 Y 1
81 4110000217088 接头ZL15C-00004L POINT ZL15C-00004L Y 1
82 4110000218081 螺母ZL15A-00013 NUT ZL15A-00013 Y 1
83 4110000218071 接头ZL15C-30000 JOINT ZL15C-30000 Y 1
84 4110000218069 接管ZL15C-00005 PIPING ZL15C-00005 Y 1
85 4110000218066 管接头ZL15A-00015 PIPE JOINT ZL15A-00015 Y 1
