Description
4110001012 HYDRAULIC OIL RADIATOR LG952 LG953L WHEEL LOADER
4110000768 Engine WD10G220E13（G0160） 1 4110001014 Engine WD10G220E23（G0309） 1 Replace Non-interchangeable
4120002039 Metal tubeLG09-JSRG-800 1 4120002043 Metal tubeLG09-JSRG-600 1 Replace Non-interchangeable
4090000191 Hose HG2491-B16*2150 2 4030000196 Hose JB8406-B16*2150 2 Replace Non-interchangeable
2901000103 Bracket of air dyer 1 2901002133 Bracket of air dyer 1 Replace Non-interchangeable
Engine
system
4011000461 Bolt GB16674-M8*16EpZn-8.8 2 Delete Non-interchangeable
4120002021 Hydraulic oil radiator 1 4110001012 Hydraulic oil radiator LG953L 1 Replace Non-interchangeable
4110000771 Radiator assembly LY-LG952-3 1 4110001022 Radiator assembly LY-LG952H-2 1 Replace Non-interchangeable
2903001018 Hose 1 2903001279 Hose 1 Replace Non-interchangeable
Radiator
assembly
2903001019 Hose 1 2903001280 Hose 1 Replace Non-interchangeable
2010900299 Cable shaft 1 2901002036 Cable shaft 1 Replace Non-interchangeable
2901000109 Mounting plate 1 Delete Non-interchangeable
Parking
control
system 4011000461 Bolt GB16674-M8*16EpZn-8.8 3 4011000461 Bolt GB16674-M8*16EpZn-8.8 2 Qty change Interchangeable
Transmission
system
2905001705 Oil pipe 1 Delete Non-interchangeable
4190000020 Clip LG13-ZS4*250 60 4190000020 Clip LG13-ZS4*250 64 Qty change Interchangeable
2937001656 Rear frame wiring harness 1 2937001760 Rear frame wiring harness 1 Replace Non-interchangeable
2637000192 Pipe nip 2 Add Non-interchangeable
4013000046 NutGB6172.1-M12EpZn-05 2 Add Non-interchangeable
4011000488 BoltGB16674-M10*16EpZn-8.8 2 Add Non-interchangeable
4130000412 Pressure switch PS31-FS0.8BARR 1 4130001078 Oil Pressure switch YK208B 1 Replace Non-interchangeable
2637001771 Bearer 2 Add Non-interchangeable
2637000121 Pipe nip 3 Add Non-interchangeable
4190001834 Clip LG13-ZS8*370 2 Add Non-interchangeable
2904000890 Joint body NPT1/8 1 Add Non-interchangeable
4130000910 Pressure switch YK210B 1 Add Non-interchangeable
4130000208 Starting switch 08086－10000 1 Add Non-interchangeable
2937001284 Panel ZL2-235A5 1 2937001604 Panel ZL2-235M 1 Replace Non-interchangeable
4130000912 Main switch of power source 024-1H2T-80A 2 4130000912 Main switch of power source 024-1H2T-80A 3 Qty change Interchangeable
Electric
System
2937000803 Panel harness 1 2937001706 Panel harness 1 Replace Non-interchangeable
Rear
frame
2926001531 Rear frame 1 2926001531 Rear frame 1
Add the air dyer
assembly hole
Non-interchangeable
