Description

B00000102 114 GBT119-A12X24 pin 4110000186421 PS08375 4110000997003 4110000036041

1 水泵组件 WATER PUMP GROUP D20-000-32+C 1
1 GB/T119-A6*12:圆柱销 DOWEL, PIN B00000121 2
2 Q/SC585-R1/2:方头锥形螺塞 PLUG B00001716 1
3 调温器体 HOUSING, THERMOSTAT D22-101-32A+B 1
4 调温器 THERMOSTAT D22-102-06+D 1
4.1 调温器 THERMOSTAT D22-102-05+D 1
5 垫片 GASKET D22-103-30A+C 1
6 套筒销 DOWEL, SLEEVE D22-105-01+A 2
1 出水管 OUTLET WATER PIPE D24A-110-30A+A 1
2 内六角螺塞(Z1/2) PLUG, PIPE (Z1/2) D02A-164-01+B 1
3 内六角螺塞(z1/4) PLUG, PIPE (Z1/4) D00-174-01+A 1
4 闷头（φ35） DEFAULT D04-167-01A+A 1
5 套筒销 DOWEL, SLEEVE D22-105-01+A 2
6 橡胶进水弯管 RUBBER INLET BAND PIPE D24A-107-02A+B 1
7 Q/SC1302-52~76:喉箍 THROAT HOOP B00001575 2
