Description
B00000836 114 nut PS08508 4110000997022 4110000036051
1 D00-109-05 风扇传动轴 SHAFT, FAN DRIVE 1
2 D00-002-01A 风扇连接盘橡胶硫化部件 RUBBER VULCANIZED COUPLING PLATE, FAN 1
3 B00001240 弹簧垫圈 SINGLE COIL SPRING LOCK WASHERS, NORMAL TYPE 4 GB/T93-12-Zn.D
4 B00004836 六角头螺栓 HEXAGON HEAD BOLTS 4 GB/T5786-M12*1.25*25-ZN.D
5 B00001279 平垫圈 PLAIN WASHER 4 GB/T97.1-12-200HV-ZN.D
6 D00-110-01 压板 CLAMP 1
7 D00-147-01 风扇螺帽 NUT, FAN 1
8 B00002001 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M10*30
9 B00002003 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M10*30-ZN.D
10 B00001276 平垫圈 PLAIN WASHER 2 GB/T97.1-10-200HV-ZN.D
11 S00022056 空调压缩机支架 BRACKET, AIR CONDITIONER COMPRESSOR 1
12 B00000834 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD 13 GB/T6177-M10-Zn.D
13 D00-242-07 活节螺栓 BOLT 1
14 D00-176-01 撑杆套 ROD SLEEVE 1
15 B00002026 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 1 Q/SC622-M10*70-ZN.D
16 D11-104-01 隔套 SPACER 1
17 B00002136 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M8*20-ZN.D
18 B00002000 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M10*25-ZN.D
19 D00-296-04 铰接螺栓 HINGE BOLT 1
20 B00002196 垫圈 WASHER 3 Q/SC642.1-03-18
21 D00-160-64 空压机排气接头 JOINT, AIR OUTLET PIPE-AIR COMPRESSOR 1
22 D00-140-18 垫块 SPACER 1
23 D00-037-901 油尺及油尺接管部件 OIL DIPSTICK AND TUBE ADAPTER ASSY 1
24 B00001238 弹簧垫圈 SINGLE COIL SPRING LOCK WASHERS, NORMAL TYPE 7 GB/T93-10-Zn.D
25 D13-103-01 双头螺栓 STUD 6
26 D13-304-01 增压器接口螺母 NUT, FLANGE-TURBOCHARGER 6
27 D00-119-900 增压器排气接管 EXHAUST PIPE, TURBOCHARGER 1
28 B00002049 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M12*25-ZN.D
29 B00001799 加大毛垫圈 BIGGER BLACK WASHERS 4 Q/SC597-12*30
30 D13-001-01 夹箍部件 ASSEMBLY 1
31 D00-143-900 排气接管支架 EXHAUST PIPE ADAPTER BRACKET 1
32 T04-151-01 放气接头 BLEEDING JOINT 1
33 D00-219-01 水温传感器过渡接头 JOINT ADAPTER, WATER TEMPERATURE SENSOR 1
34 D00-163-08 取暖水接头 JOINT, WARM WATER OUTLET FROM ENGINE 1
35 D00-169-50 油压传感器过渡接头 JOINT ADAPTER, OIL PRESSURE SENSOR 1
36 D88A-008-800 机油压力传感器 SENSOR, OIL PRESSURE 1
37 D02A-163-01 内六角螺塞(Z3/4) HEXAGONAL SOCKET HEAD PLUG 1
38 S00000509 空压机进油管弯管接头 AIR COMPRESSOR OIL INLET ELBOW CONNECTOR 1
39 D31-106-30 机油压力传感器 SENSOR, OIL PRESSURE 1
40 D00-106-02A 空压机进油管 OIL INLET PIPE, AIR COMPRESSOR 1
41 B00001996 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M10*20
42 D00-101-40A 空压泵支架 BRACKET, AIR COMPRESSOR 1
43 D02B-115-01A 转向泵垫片 GASKET, STEERING PUMP 1
45 B00002282 橡胶水管 RUBBER HOSE, WATER 1 Q/SC646-102*100
46 B00001532 弹簧卡箍 SPRING CLAMP 2 Q/SC1092-110
47 D00-034-901 油水分离器部件 WATER/FUEL SEPARATOR ASSY 1
47.1 D00-305-02 油水分离器滤芯 FILTER, WATER/FUEL SEPARATOR 1
47.2 S00004489 放水阀及水位感应接头部件 WATER DRAIN COCK AND WATER LEVEL SENSOR CONNECTOR ASSY 1
48 D87-023-900 环境温度传感器安装盒 AMBIENT TEMPERATURE SENSOR BOX 1
49 D11-115-02 起动继电器支架 STARTING RELAY 1
50 D11-116-01A 起动继电器 BRACKET, STARTING RELAY 1
51 B00002118 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M6*20
52 B00000843 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD 2 GB/T6177-M6-Y
54 B00000398 六角头螺栓 HEXAGON HEAD BOLTS 1 GB/T5782-M10*50-ZN.D
S00022039 增压器隔热套 HEAT SHIELD, TURBOCHARGER 1
