Description

B00001104 135 bolt PS08550 4110000036060

1 S00013514 凸轮轴 CAMSHAFT 1
2 D06A-110-01 圆柱销 PARALLEL PIN 1
3 B00000632 六角头螺栓 HEXAGON HEAD BOLT 2 GB/T5783-M8*20-10.9
4 D02A-114-01C 凸轮轴推力板 THRUST PLATE, CAMSHAFT 1
5 S00018001 油尺 OIL DIPSTICK 1
6 D02A-104-41 气缸套 CYLINDER LINER 6
7 D02A-171-30A 缸套封水圈 SEAL, CYLINDER LINER 18
12 B00000301 O形橡胶密封圈 O-RING 2 GB/T3452.1-26.5*2.65
13 D02A-313-801 内六角螺塞 HEX SOCKET PIPE PLUG 1 GB/T3452.1-26.5*2.65
15 D02A-168-01 六角头螺塞 HEXAGONAL SOCKET HEAD PLUG 1
16 B00001378 O形橡胶密封圈 O-RING 1 GB3452.1-16*2.65
17 B00001996 六角法兰面螺栓 HEXAGON BOLTS 2 Q/SC622-M10*20
18 D02A-013-36 油泵固定支架焊接部件 BRACKET ASSY (WELDED), FUEL INJECTION PUMP 1
19 B00001724 六角头螺塞 HEXAGONAL SOCKET HEAD PLUG 1 Q/SC587.1-M10*1
20 B00001545 复合式密封硬垫圈 RUBBER COATED HARD WASHER 1 Q/SC1294-10
21 D02A-166-01 螺塞(Z1/8) SCREW PLUG(Z1/8) 2
22 D02A-030-03 活塞冷却喷嘴部件 ORIFICE ASSY, PISTON COOLING JET 6
23 B00002045 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M12*20
33 气缸套维修组件 CYLINDER LINER SERVICE GROUP
34 缸套封水圈维修组件 CYLINDER LINER SEAL SERVICE GROUP
35 内六角螺塞维修组件 HEXAGONAL SOCKET HEAD PLUG SERVICE GROUP
36 凸轮轴维修组件 CAMSHAFT SERVICE GROUP
37 六角头螺塞维修组件 HEXAGONAL SOCKET HEAD PLUG SERVICE GROUP
38 六角头螺塞维修组件 HEXAGONAL SOCKET HEAD PLUG SERVICE GROUP
