Description

B00001136 bolt 135 PS08563 4110000036061

1 D04-001-800 气缸盖部件 CYLINDER HEAD ASSY 1
2 D04-102-30 进气门座 VALVE SEAT INSERT,INTAKE 6
3 D04-103-30 排气门座 VALVE SEAT INSERT,EXHAUST 6
4 D04-161-01 节流塞 THROTTLE PLUG 1
5 D04-316-01 闷头 PLUG 1
6 D04-132-01 内六角螺塞 HEX SOCKET PIPE PLUG 2
7 B00001374 O形橡胶密封圈 O-RING 1 GB3452.1-14*2.65
8 D02A-169-01 六角头螺塞 HEXAGONAL HEAD SCREW PLUG 1
9 S00021061 气门导管 VALVE GUIDE 12
10 B00000116 圆柱销 PARALLEL PINS 6 GB/T119-A4*8
11 D04-311-01A 定位销 DOWEL PIN 6
12 D04-167-01A 闷头（φ35） PLUG（φ35） 6
13 D04-317-01 闷头 PLUG 6
14 D04-114-30B 气门弹簧上座 VALVE SPRING RETAINER 12
15 D04-115-30A 气门锁夹 VALVE COLLET 24
16 D04-113-30A 气门弹簧 VALVE SPRING 12
17 D04-107-30 排气门杆油封 VALVE STEM SEAL,EXHAUST 12
18 S00014705 气缸盖螺栓(短) BOLT (SHORT), CYLINDER HEAD 6
19 S00014704 气缸盖螺栓(长) BOLT (LONG), CYLINDER HEAD 20
20 D04-110-34 进气门 VALVE,INTAKE 6
21 D04-111-31B 排气门 VALVE,EXHAUST 6
22 D02A-312-01 圆柱销 PARALLEL PINS 2
23 D02A-109-30B 气缸盖垫片【d6114】 GASKET, CYLINDER HEAD(6144) 1
24 D04-308-01 闷头 PLUG 5
25 气缸盖维修组件 CYLINDER HEAD SERVICE GROUP
