Description

B00001730 135 QSC587.1-M22X1.5 PLUG PS08709

1 B00002153 六角法兰面螺栓 HEXAGON BOLTS 3 Q/SC622-M8*55
2 D22-105-01 套筒销 DOWEL SLEEVE 4
3 B00000121 圆柱销 PARALLEL PIN 2 GB/T119-A6*12
4 D22-103-33 垫片 GASKET 1
5 调温器体维修组件 HOUSING, THERMOSTAT SERVICE GROUP 1
D22-101-36 调温器体 HOUSING, THERMOSTAT 1
6 D04-309-01 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 2
7 调温器维修组件 THERMOSTAT SERVICE GROUP 2
D22-102-04 调温器部件 THERMOSTAT ASSY 1
8 D02A-163-01 内六角螺塞(Z3/4) PLUG 1
9 D88A-005-800 水温传感器 SENSOR, WATER TEMPERATURE 1
10 D04-305-01 调温器双头螺栓 STUD, THERMOSTAT 2
11 D04-306-01 调温器双头螺栓 STUD, THERMOSTAT 4
12 D04-304-01 调温器垫片 GASKET, THERMOSTAT 1
13 B00000846 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD 6 GB/T6177-M8-Y
14 D24A-107-02A 橡胶进水弯管 HOSE EBLOW 1
15 B00001535 弹簧卡箍 SPRING CLAMP 1 Q/SC1092-60
16 淡水泵维修组件 WATER PUMP SERVICE GROUP 1
S00013335 淡水泵 WATER PUMP 1
17 S00013391 水泵垫片 GASKET 1
18 B00002147 六角法兰面螺栓 HEXAGON BOLTS 2 Q/SC622-M8*45
19 D00-174-01 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 1
20 出水管维修组件 WATER OUTLET PIPE SERVICE GROUP 1
D24A-110-30A 出水管 WATER OUTLET PIPE 1
21 D02A-164-01 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 1
22 B00001020 弹性圆柱销 PARALLEL PIN 3 GB/T879-12*12
23 B00001811 加大毛垫圈 BIGGER BLACK WASHERS 1 Q/SC597-8*26
24 C00AL-00AL003 取暖水回水接头 JOINT, WARM WATER OUTLET FROM ENGINE 1
25 B00001828 铜垫圈 COPPER WASHER 1 Q/SC598-16*22
27 S00011413 夹箍 CLAMP 1
29 D04-151-30 放气接头 BLEEDING JOINT 1
