Description

B00001737 135 QSC588-5X19 KEY PS08714

1 D02B-108-01B 齿轮室加油螺盖 SCREW CAP, OIL FILLER-GEAR HOUSING 1
2 D02B-109-03 螺盖密封圈 SEAL RING,SCREW CAP 1
3 D02B-300-01 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 17
4 B00002147 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*45
5 B00002150 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 9 Q/SC622-M8*50
6 D02B-104-02A 曲轴前端油封 FRONT SEAL,CRANKSHAFT 1
7 D02B-102-40 齿轮室罩盖 COVER, GEAR HOUSING 1
8 D07-104-40 空压机齿轮 GEAR,AIR COMPRESSOR 1
9 D07-102-02 凸轮轴齿轮 CAMSHAFT GEAR 1
10 D07-103-800 高压油泵齿轮 GEAR，FUEL INJECTION PUMP 1
11 B00002135 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 3 Q/SC622-M8*20-10.9
12 B00002142 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*35
13 B00002062 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 4 Q/SC622-M12*50
14 S00023791 齿轮室螺塞装配部件 SCREW PLUG ASSEMBLY, GEAR HOUSING 1
15 D04-132-01 内六角螺塞 HEXAGON SOCKET PIPE PLUG 1
16 B00000833 六角法兰面螺母 HEXAGON NUTS 4 GB/T6177-M10-Y
17 D02A-129-40 齿轮室垫片 GASKET,GEAR HOUSING 1
18 齿轮室维修组件 GEAR HOUSING,SERVICE GROUP
19 D02B-108-04C 加油弯管 PIPE ELBOW, OIL FILLER 1
20 D02A-006-01A 加油盖部件 OIL FILLER,GEAR HOUSING 1
21 B00001100 双头螺柱 STUD 4 GB/T899-GM10-M10*30-8.8-Y
