Description
B00001957 135 bolt PS08811
1 D04-001-800 气缸盖部件 CYLINDER HEAD ASSY 1
2 D04-102-30 进气门座 VALVE SEAT INSERT,INTAKE 6
3 D04-103-30 排气门座 VALVE SEAT INSERT,EXHAUST 6
4 D04-161-01 节流塞 THROTTLE PLUG 1
5 D04-316-01 闷头 PLUG 1
6 D04-132-01 内六角螺塞 HEX SOCKET PIPE PLUG 2
7 B00001374 O形橡胶密封圈 O-RING 1 GB3452.1-14*2.65
8 D02A-169-01 六角头螺塞 HEXAGONAL HEAD SCREW PLUG 1
9 S00021061 气门导管 VALVE GUIDE 12
10 B00000116 圆柱销 PARALLEL PINS 6 GB/T119-A4*8
11 D04-311-01A 定位销 DOWEL PIN 6
12 D04-167-01A 闷头（φ35） PLUG（φ35） 6
13 D04-317-01 闷头 PLUG 6
14 D04-114-30B 气门弹簧上座 VALVE SPRING RETAINER 12
15 D04-115-30A 气门锁夹 VALVE COLLET 24
16 D04-113-30A 气门弹簧 VALVE SPRING 12
17 D04-107-30 排气门杆油封 VALVE STEM SEAL,EXHAUST 12
18 S00014705 气缸盖螺栓(短) BOLT (SHORT), CYLINDER HEAD 6
19 S00014704 气缸盖螺栓(长) BOLT (LONG), CYLINDER HEAD 20
20 D04-110-34 进气门 VALVE,INTAKE 6
21 D04-111-31B 排气门 VALVE,EXHAUST 6
22 D02A-312-01 圆柱销 PARALLEL PINS 2
23 D02A-109-30B 气缸盖垫片【６１１４】 GASKET, CYLINDER HEAD 1
25 B00000833 六角法兰面螺母 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 4 GB/T6177-M10-Y
26 D11-104-01 隔套 SPACER 1
27 B00002024 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M10*70
28 B00002007 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 2 Q/SC622-M10*40
29 B00000516 六角头螺栓 HEXAGON HEAD BOLTS-FULL THREAD 1 GB/T5783-M10*40
30 D00-242-07 活节螺栓 DEFAULT 1
31 B00002054 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M12*35
32 B00002060 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M12*45
33 B00002137 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*25
34 B00002142 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*35
35 D00-149-03 冷气压缩机支架 BRACKET, COMPRESSOR-COOL AIR CONDITIONER 1
36 D00-176-01 撑杆套 ROD SLEEVE 1
37 D00-236-04 前吊环 FRONT LIFTING REAR 1
38 B00002060 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M12*45
39 B00002142 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*35
40 D04-143-30C 后吊环 REAR LIFTING REAR 1
41 B00002047 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 2 Q/SC622-M12*25
42 D24B-131-900 接头 JOINT 1
43 B00001827 铜垫圈 COPPER WASHER 1 Q/SC598-16*20
44 B00001727 六角头螺塞 HEXAGONAL HEAD SCREW PLUG 1 Q/SC587.1-M16*1.5
