Description

B00002132 QSC622-M8X16 114 Bolt,Hex Flange Head Cap PS08883 4110000997095 4110000036103

1 B00002178 铰接螺栓 HINGE BOLT 1 Q/SC642.1-01-M12*1.25
2 B00002193 垫圈 WASHER 2 Q/SC642.1-03-12
3 D19-110-05B 增压器进油管 OIL INLET PIPE,TURBOCHARGER 1
4 D19-118-01 接头 JOINT 1
5 S00024622 增压器部件 TURBOCHARGER ASSY 1
6 D19-113-02 垫片 GASKET 1
7 B00001999 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 2 Q/SC622-M10*25
8 S00000546 增压器回油管焊接部件 OIL RETURN PIPE ASSY (WELDED), TURBOCHARGER 1
9 D02A-171-80 O型橡胶密封圈 O-RING 2
10 D13-304-01 增压器接口螺母 NUT, FLANGE-TURBOCHARGER 4
11 D13-103-01 双头螺栓 STUD 4
12 D13-102-30B 涡轮进口垫片 GASKET,INLET-TURBINE 1
13 S00024641 增压器隔热套 HEAT SHIELD, TURBOCHARGER 1
14 D13-113-01 涡轮出口盖板垫片 GASKET,OUTLET-TURBINE COVER 1
15 D13-114-30 涡轮出口盖板 COVER,OUTLET TURBINE 1
16 D13-001-01 夹箍部件 CLAMP 1
17 D13-303-01 双头螺栓 STUD 6
18 D13-108-50 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FULL THREAD 6
