Description

B00002282 135 QSC646-102X100 rubber hose 4110000186461 PS08922 W014202540

1 S00013391 水泵垫片 GASKET 1
2 S00013335 淡水泵部件 WATER PUMP ASSY 1
3 B00002147 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 2 Q/SC622-M8*45
4 B00002153 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 3 Q/SC622-M8*55
5 B00001811 加大毛垫圈 BIGGER BLACK WASHERS 1 Q/SC597-8*26
6 B00001020 弹性圆柱销 SPRING-TYPE STRAIGHT PINS-SLOTTED,HEAVY DUTY 3 GB/T879-12*12
7 B00001575 喉箍 CLAMP 2 Q/SC1302-52~76
8 D24A-107-02A 橡胶进水弯管 HOSE ELBOW,WATER INLET 1
9 D22-105-01 套筒销 SLEEVE PIN 2
10 D00-174-01 内六角螺塞(z1/4) HEXAGON SOCKET SCREW PIPE PLUG（Z1/4) 1
11 D02A-164-01 内六角螺塞(Z1/2) HEXAGON SOCKET SCREW PIPE PLUG (Z1/2) 1
12 D24A-110-32 出水管 WATER OUTLET PIPE 1
13 D04-167-01A 闷头（φ35） PLUG 1
14 D04-306-01 调温器双头螺栓 STUD,THERMOSTAT 4
15 B00000846 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD 6 GB/T6177-M8-Y
16 D04-305-01 调温器双头螺栓 STUD,THERMOSTAT 2
17 D22-102-04 调温器 THERMOSTAT 2
18 D22-103-33 垫片 GASKET 1
19 D22-105-01 套筒销 SLEEVE PIN 2
20 D22-101-36 调温器体 THERMOSTAT HOUSING 1
21 D04-309-01 内六角螺塞(Z3/8) HEXAGON SOCKET SCREW PIPE PLUG 1
22 D02A-163-01 内六角螺塞(Z3/4) HEXAGON SOCKET SCREW PIPE PLUG 1
23 D04-304-01 调温器垫片 GASKET,THERMOSTAT 1
24 B00000121 圆柱销 PARALLEL PIN 2 GB/T119-A6*12
25 D00-163-04 过渡接头 ADAPTER JOINT 1
26 D00-290-01 放气接头 AIR OUTLET JOINT 1
27 B00001828 铜垫圈 COPPER WASHER 1 Q/SC598-16*22
28 D88A-005-800 水温传感器 WATER TEMPERATURE SENSOR 1
29 D00-219-01 水温传感器过渡接头 JOINT ADAPTER,WATER TEMPERATURE SENSOR 1
30 D00-219-08 接头 JOINT 1
