Description

B00002337 QSC646-25X100 114 rubber hose PS08932

1 D02B-108-01B 齿轮室加油螺盖 SCREW CAP,OIL FILLER-GEAR HOUSING 1
2 D02B-109-03 螺盖密封圈 SEAL RING,SCREW CAP 1
3 D02B-300-01 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 17
4 B00002150 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 9 Q/SC622-M8*50
5 B00002147 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*45
6 D02B-104-02A 曲轴前端油封 FRONT SEAL RING,CRANKSHAFT 1
7 D02B-102-40 齿轮室罩盖 COVER, GEAR HOUSING 1
8 D07-103-800 高压油泵齿轮 GEAR,FUEL INJECTION PUMP 1
9 D07-102-02 凸轮轴齿轮 GEAR,CAMSHAFT 1
10 B00002135 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 3 Q/SC622-M8*20-10.9
11 B00002142 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 1 Q/SC622-M8*35
12 B00002062 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 4 Q/SC622-M12*50
13 S00011529 齿轮室螺塞装配部件 SCREW PLUG ASSEMBLY, GEAR HOUSING 1
14 D04-132-01 内六角螺塞 HEXAGON SOCKET SCREW PLUG 1
15 B00000098 圆柱销 PARALLEL PINS 2 GB/T119-A10*20
16 D02A-129-40 齿轮室垫片 GASKET,GEAR HOUSING 1
17 D02B-106-40 PTO接口垫片 GSKET,PTO 1
18 D02B-105-40 PTO接口盖板 PLATE,PTO 1
19 B00001124 双头螺柱 DOUBLE END STUDS-BM=1.5D 2 GB/T899-GM12-M12*35-8.8-Y
20 B00000836 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD 2 GB/T6177-M12-Y
21 D02B-101-39 齿轮室 HOUSING, GEAR 1
