Description
B774ZL-02-003+A 135 gasket B774ZL-02-003+B PS09005
1 高压油管部件(第一缸) TUBE ASSEMBLY, INJECTOR FUEL SUPPLY (NO.1 CYLINDER) D26-001-35+B 1
2 高压油管部件(第二缸) TUBE ASSEMBLY, INJECTOR FUEL SUPPLY (NO.2 CYLINDER) D26-002-35+B 1
3 高压油管部件(第三缸) TUBE ASSEMBLY, INJECTOR FUEL SUPPLY (NO.3 CYLINDER) D26-003-35+B 1
4 上夹片焊接部件 BRACE, FUEL TUBE ASSY (WELDED) D26-034-01+A 3
5 夹片衬垫 ISOLATOR, VIBRATION D26-104-01+A 10
7 上夹片 BRACE, FUEL TUBE D26-105-01+B 5
8 GB/T97.1-5-200HV-Y：平垫圈 WASHER, PLAIN B00001296 11
9 GB/T93-5：弹簧垫圈 STANDARD SPRING WASHER B00001251 11
10 Q/SC622-M5*25：六角法兰面螺栓 BOLT, HEX FLANGE HEAD CAP B00002108 11
11 GB/T5783-M8*20：六角头螺栓 HEXAGON HEAD BOLT B00000631 2
12 GB/T97.1-8-200HV-Y：平垫圈 WASHER, PLAIN B00001299 2
13 油管固定支架焊接部件 TUBE BRACKET ASSY (WELDED) D26-035-01+A 2
14 高压油管部件(第四缸) TUBE ASSEMBLY, INJECTOR FUEL SUPPLY (NO.4 CYLINDER) D26-004-37+B 1
15 高压油管部件(第五缸) TUBE ASSEMBLY, INJECTOR FUEL SUPPLY (NO.5 CYLINDER) D26-005-35+B 1
16 高压油管部件(第六缸) TUBE ASSEMBLY, INJECTOR FUEL SUPPLY (NO.6 CYLINDER) D26-006-35+B 1
17 支承块螺钉 BOLT D26-131-01+A 1
18 Q/SC622-M8*40-ZN.D：六角法兰面螺栓 BOLT, HEX FLANGE HEAD CAP B00002146 1
19 油泵支承架 BRACKET, FUEL INJECTION PUMP D26-129-31A+A 1
20 Q/SC622-M12*20-ZN.D：六角法兰面螺栓 BOLT, HEX FLANGE HEAD CAP B00002046 1
21 油泵支承块 SPACER, FUEL INJECTION PUMP D26-130-01+A 1
22 GB/T6177-M8-Y：六角法兰面螺母 NUT, HEX FLANGE HEAD CAP B00000846 2
23 回油管部件 FUEL RETURN PIPE ASSY D26-008-33B+A 1
24 GB/T5783-M4*12：六角头螺栓 HEXAGON HEAD BOLT B00000582 2
25 GB/T97.1-4-200HV-Y：平垫圈 WASHER, PLAIN B00001293 2
26 夹箍 CLIP D26-117-01+C 2
27 Q/SC1294-12：复合式密封硬垫圈 COMPOSITE HARD SEAL GASKET B00001546 4
28 铰接螺钉 HINGED BOLT D26-121-30+B 1
29 铰接螺钉 HINGED BOLT D26-121-01+A 1
30 Q/SC1294-10：复合式密封硬垫圈 COMPOSITE HARD SEAL GASKET B00001545 1
31 Q/SC587.1-M10*1：六角头螺塞 PLUG, PIPE B00001724 1
32 Q/SC642.1-01-M8*1：铰接螺栓 HINGED BOLT B00002185 1
33 Q/SC1294-8：复合式密封硬垫圈 COMPOSITE HARD SEAL GASKET B00001555 2
34 夹箍 CLIP D26-117-30+D 2
35 Q/SC622-M8*16-ZN.D：六角法兰面螺栓 BOLT, HEX FLANGE HEAD CAP B00002133 5
36 喷油泵进油管部件 FUEL INLET TUBE, FUEL INJECTION PUMP D26-114-30A+C 1
37 夹箍 CLIP D26-117-32+C 1
38 GB/T6177-M5-Y：六角法兰面螺母 NUT, HEX FLANGE HEAD CAP B00000631 1
39 输油泵进油管 INLET PIPE, FUEL SUPPLY PUMP D26-115-31+A 1
40 回油管焊接部件 TUBE WELDING, FUEL RETURN D26-030-02A+F 1
41 Q/SC622-M6*12：六角法兰面螺栓 BOLT, HEX FLANGE HEAD CAP B00002111 1
42 夹箍 CLIP D26-117-31+B 1
43 夹箍 CLIP D26-117-38+D 1
44 上夹片 BRACE, FUEL TUBE D26-105-02+A 2
45 夹片衬垫 ISOLATOR, VIBRATION D26-104-02+A 2
