Description

CONVERTER CORE ASSEMBLY 402200 LG853.02.01-001 60980002380 402000-1 LG853.02.01 36301000000 Cassette mechanism assembly 145TEETH

1 402223 螺塞 Z3/4″ Plug Z3/4″ 1 LG853.02.01-011
2 402222 导轮座 Idler wheel seat 1 LG853.02.01-003
3 GB/T1235-76 O型密封圈 Ф135×3.1 O-ring Ф135×3.1 1
4 402216A 壳体 Torque converter shell 1 LG853.02.01-002
5 402215A 衬垫 Pad 1 LG853.02.01-012
6 402214A 观察盖 Viewer cover 1 LG853.02.01-013
7 GB/T67 螺钉 M8×18 Screw M8×18 4
8 GB/T93 垫圈 8 Washer 8 4
9 402221 密封环 Sealing ring 1
10 402220 分动齿轮 Transfer Gear 1
11 GB/T276 轴承 117（130×85×22） Bearing 117(130×85×22) 2
12 GB/T5784 螺钉 M8×35 Screw M8×35 24
13 402227 泵轮 Pump wheel 1
14 402224 调整垫片 Shims 1
15 402218 放松垫片 Lock washer 6
16 GB/T6171 螺母 M10×1 Nut M10×1 12
17 GB/T93 垫圈 10 Washer 10 20
18 402237 双头螺栓 Stud 12 LG853.02-001
19 402210 圆垫板 Round pad 1
20 402201 垫片 Gasket 6
21 402202 弹性板 δ=1.0 Elastic plateδ=1.0 2
22 GB/T93 垫圈 12 Washer 12 36
23 GB/T5780 螺栓 M12×30 Bolt M12×30 6
24 402211 变矩器垫片 Torque converter pad 1
25 402208 弹性销 Elastic pin 9
26 GB/T93 垫圈 8 Washer8 36
27 GB/T6170 螺母AM8 Nut AM8 24

28 402203 罩轮 Housing wheel 1
29 402236 O型密封圈 O-ring 1
30 GB/T276 轴承210（90×50×20） Bearing 210(90×50×20) 1
31 402207 一级涡轮罩 First stage turbine hood 1
32 402206 一级涡轮壳 First stage turbine housing 1
33 GB/T869 沉头铆钉 Rivet 12
34 GB/T276 轴承113（100×65×18） Bearing 113(100×65×18) 1
35 GB/T893.1 孔用挡圈 50 Hole ring 50 1
36 402212-13 二级涡轮 Second stage turbine 1
37 402209 一级涡轮 First stage turbine 1
38 GB/T894.1 轴用挡圈 80 Shaft retainer 80 1
39 402217 导轮 Idler wheel 1
40 402226 压板 Press plate 1
41 GB/T5780 螺栓 M12×45 Bolt M12×45 12
42 402229 弹簧 Spring 1 LG853.02.01-007
43 402204 回油接头 Oil return connector 1 LG853.02.01-014
44 402232 垫片 Pad 2
45 402231A 弹簧 Spring 1 LG853.02.01-010
46 402230A 盖板 Cover board 1 LG853.02.01-009
47 402233 进口阀杆 Inlet valve stem 2 LG853.02.01-008
48 402228A 阀盖 Valve cap 1 LG853.02.01-006
49 GB/T5780 螺栓 M10×28 Bolt M10×28 8
50 402111A 接头 Connector 2 LG853.02.01-005
51 402106 铜垫圈 Copper washer 2 LG853.02.01-004
52 402238 花键垫片 Spline washer 1
53 402234 出口阀芯 Outlet spool 1 LG853.02.01-015
