Description

D02A-104-41+A 114 CYLINDER LINER PS10671 860123890 4110000999003

1 C20AB-20AB601 水泵部件 PUMP AS. 1
2 U641A-5F3106 O型密封圈 SEAL 1
3 B00000374 六角头螺栓 BOLT 2 GB/T5782-M10*(110)-10.9
4 B00001237 垫圈 WASHER 2 GB/T93-10

1 C22AL-1118010 调温器 THERMOSTAT 1
2 C22AL-M7N0944 垫片 GASKET 1
3 S00022172+01 出水管 WATER OULET TUBE 1
4 B00002002 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES 4 Q/SC622-M10*30-10.9
5 C22AB-8N4485 放气阀部件 AIR BLEED VALVE 1

1 旁通水管路部件 LINES GP
1.1 C24AL-M7N0172 分水弯头 JIONT ELBOW 1
1.2 U562A-M3J5390 六角锥管螺塞 PLUG 1
1.3 U562A-M5M6213 六角锥管螺塞 PLUG 2
1.4 U561C-1B5174 内方头锥管螺塞 PLUG 3
6 C24AL-2P6132 旁通管垫片 GASKET 1
7 C24AL-7N0200 垫片 GASKET 1
8 C24AL-9L1794 连接胶管 HOSE 1
9 B00001537 喉箍 CLAMP 2 Q/SC1092-65
10 B00000397 六角头螺栓 BOLT 1 GB/T5782-M10*50-10.9
11 B00000413 六角头螺栓 BOLT 1 GB/T5782-M10*90-10.9
12 B00000410 六角头螺栓 BOLT 2 GB/T5782-M10*80-10.9
13 B00001275 平垫圈 WASHER 2 GB/T97.1-10-200HV-Y
14 B00001237 弹簧垫圈 WASHER 2 GB/T93-10
