Description

D02B-115-01A+A 114 STEERING PUMP GASKET PS10846 4110001300034

1 B00005628 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 11 GB/T6177-M10-DAC
2 B00005594 六角头螺栓 全螺纹 HEXAGON HEAD BOLTS-FULL THREAD 2 GB/T5783-M10*50-DAC
3 B00005639 平垫圈 A级 PLAIN WASHERS-PRODUCT GRADE A 2 GB/T97.1-10-200HV-DAC
4 C08AL-M2P7806 夹箍 CLAMP 1
5 B00005511 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 1 GB/T16674.1-M10*30-DAC
6 C08AL-M08AL009 排气管支架 BRACKET,EXHAUST MANIFOLD 1
7 C08AL-M8S6783 夹箍 CLAMP 1
8 排气管焊接部件 EXHAUST PIPE ASSY (WELDED)
8.1 C08AL-08AL015 排气管 EXHAUST MANIFOLD 1
8.2 C08AL-08AL021 接管 CONNECTING PIPE 1
8.3 C08AL-M8S6883 夹箍 CLAMP 1
8.4 B00005616 1型六角螺母 HEXAGON NUTS,STYLE I 1 GB/T6180-M10-DAC
8.5 B00005639 平垫圈 A级 PLAIN WASHERS-PRODUCT GRADE A 2 GB/T98.1-10-200HV-DAC
8.6 B00005594 六角头螺栓 全螺纹 HEXAGON HEAD BOLTS-FULL THREAD 1 GB/T5883-M10*50-DAC
9 B00005519 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 GB/T16674.1-M10*55-DAC
10 C08AL-M7N2450 消声器固定箍 FIXING CLAMP,MUFFLER 1
11 B00005513 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 GB/T16674.1-M10*35-DAC
12 B00005629 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 4 GB/T6177-M12-DAC
13 B00005537 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 GB/T16674.1-M12*50-10.9-DAC
14 C08AB-08AB016 消声器部件 MUFFLER ASSY 1
15 C08AB-4W1667 消声器支架焊接部件 BRACKET ASSY (WELDED), MUFFLER 1
16 B00005516 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 GB/T16674.1-M10*45-DAC
17 C08AB-M08AB009A 支架焊接部件 BRACKET ASSY (WELDED) 1
