D28-101-01+A 114 joint PS12393 SP111418

*1 风扇支架加工部件 FAN SHAFT BRACKET AS. C16AB-16AB001+A 1
(2) 风扇轴 SHAFT-FAN C16AL-1P9946+A 1
(3) 风扇轴支架 BRACKER-FAN C16AL-16AL003+A 1
(4) GB/T119-B10*18:圆柱销 CYLINDRICAL PIN B00000132 1
5 风扇法兰 HUB-FAN PULLEY C16AL-M1W4407+A 1
6 GB/T276-6307:深沟球轴承 BALL BEARING B00000241 1
7 GB/T276-6207:深沟球轴承 BALL BEARING B00000216 1
8 HG4-692-SG50*72*12:骨架式橡胶油封 RUBBER OIL SEAL B00001456 1
9 隔圈 SPACER C16AL-16AL002+A 1
10 隔圈 SPACER C16AL-8N5305+A 1
11 压紧垫圈 WASHER-RETAINING C16AL-5S7264+A 1
12 GB/T1152-M10*1:直通式压注油环 OIL WREATH B00000064 1
13 调节垫块 SPACER C16AL-16AL004+A 1
14 六角头螺栓 BOLT U311A-1A1460+A 8
15 六角头螺栓 BOLT U311A-6V4626+A 2
1 发电机皮带轮 FAN PULLEY C16BL-16BL019+A 1
2 风扇联轴节部件 FAN ADAPTER AS. C16BB-16BB006+A 1
3 O型密封圈 FAN ADAPTER U641A-9F4446+A 6
4 六角头螺栓 PLUG U311A-2H5330+A 6
5 平垫圈 CHART TENSION U382A-8T4896+A 6
6 六角螺母 SEAL-O-RING U331A-6V8801+A 1
7 风扇皮带轮部件 PULLEY FOR ALTERNATOR C16BB-16BB026+A 1
8 三角带部件 V-BELT C16BB-16BB001+A 1
1 风扇铆接部件(吹风式) SPIDER AS.-FAN(BLOWER) C16DB-16DB022+A 1
2 六角头螺栓 BOLT U311A-5S7382+A 6
3 平垫圈 WASHER-HARD U382A-8T4896+A 6
