Description
D38-000-650+B 114 TD07S turbocharger PS12567
| 1 | U311A-5S7383 | 六角头螺栓 | BOLT | 2 |
| 2 | C11BL-11BL001 | 发电机支架 | BRACKET | 1 |
| 3 | U311A-7X0338 | 六角头螺栓 | BOLT | 1 |
| 4 | U382A-7X0574 | 平垫圈 | WASHER-HARD | 3 |
| 5 | C11BB-9S1240 | 螺母部件 | NUT AS. | 1 |
| 6 | C11BL-11BL002 | 隔圈 | SPACER | 1 |
| 7 | U311A-5P2566 | 六角头螺栓 | BOLT | 1 |
| 8 | C11BL-8S4183 | 撑条 | ROD-ALTERNATOR | 1 |
| 9 | U311A-0V0375 | 六角头螺栓 | BOLT | 1 |
| 10 | C11BB-11BB007 | 充电发电机部件 | ALTERNATOR GP.-CHARGING(BASIC) 24V-50A) | 1 |
| 11 | U311A-8T4835 | 六角头螺栓 | BOLT | 1 |
| 1 | C12AL-9S9736 | 高温用软接管 | HOSE-AIR | 1 | |
| 2 | B00001542 | 弹簧卡箍 | SPRING CLAMP | 2 | Q/SC1092-85 |
| 3 | C12AL-8N8195 | 压气机出气弯管 | AIR OUTLET PIPE ELBOW, COMPRESSOR | 1 | |
| 4 | U311A-1A2029 | 六角头螺栓 | BOLT | 4 | |
| 5 | U311A-4L9337 | 六角头螺栓 | BOLT | 2 | |
| 6 | C12AL-1H7666 | 垫片 | GASKET | 1 | |
| 7 | C12AL-12AL029 | 进气弯管 | AIR INTAKE PIPE ELBOW | 1 | |
| 8 | B00001724 | 六角头螺塞 | PLUG-PIPE | 1 | Q/SC587.1-M10*1 |
| 9 | B00001814 | 垫圈 | WASHER | 1 | Q/SC598-10*16 |
| 10 | B00001706 | 六角头螺塞 | PLUG-PIPE | 1 | Q/SC584.2-M20*1.5 |
| 11 | U562A-5M6214 | 六角锥管螺塞 | PLUG-PIPE | 1 | |
| 12 | U311A-0S1591 | 六角法兰面螺栓 | BOLT | 2 | |
| 13 | C04BL-5S6735 | 垫片 | GASKET | 1 | |
| 14 | C12AL-1S4295 | 涡轮垫片 | GASKET-TURBOCHAGER | 1 | |
| 15 | C38AL-7L3195 | 耐热螺栓 | BOLT-HIGH TEMP | 4 | |
| 16 | C13BL-2N2766 | 锁紧螺母 | LOCKNUT | 4 | |
| 17 | C12AL-8N8196 | 涡轮进气弯管 | ADAPTER-EXHAUST MANIFOLD | 1 |
