Description

D638-000-40+A 114 fuel filter assy

1 C00AL-00AL004 水温表接头 JOINT, WATER THERMOMETER 1
2 C00AL-00AL006 空压泵排气口接头 JOINT, AIR OUTLET PIPE-AIR COMPRESSOR 1
3 U512C-5P4479 37°扩口90°弯管接头 FLARED TYPE (37°) JOINT ELBOW ASSY (90°) 1
4 C11BL-1W4972 发电机支架 ALTERNATOR BRACKET 1
5 U311A-8T9378 六角头螺栓 HEXAGON HEAD BOLT 3
6 U382A-8T4896 平垫圈 PLAIN WASHER 4
7 U331A-1D4717 六角螺母 NUT 4
8 U311A-8T7008 六角头螺栓 HEXAGON HEAD BOLT 1
9 C00AL-00AL003 取暖水回水接头 JOINT, WARM WATER OUTLET FROM ENGINE 1
10 C00AB-00AB201 限烟器管路部件 LINES ASSY 1
11 U382A-9M1974 平垫圈 PLAIN WASHER 1
12 U311A-2H3755 六角头螺栓 HEXAGON HEAD BOLT 1
13 C12AL-2B2404 管夹 CLAMP 2
14 C00AL-00AL203A 软轴支架 BRACKET 1
15 U311A-0S1617 六角头螺栓 HEXAGON HEAD BOLT 2
16 U382A-5P4116 平垫圈 PLAIN WASHER 2
17 D00-241-01 燃油回油管 FUEL RETURN PIPE 1
18 B00005015 铰接螺栓 BANJO BOLT 2 Q/SC642.1-01-M14*1.5-ZN.D
19 B00001547 复合式密封硬垫圈 RUBBER COATED HARD WASHER 4 Q/SC1294-14
20 C00AL-00AL121 低压油管 FUEL PIPE, LOW PRESSURE 1
21 D00-277-05 操纵软轴 SOFT SHAFT 1
22 C00AL-00AL020 机油压力表接头 JOINT, OIL MANOMETER 1
23 C00AL-00AL002 取暖水进水接头 JOINT, WARM WATER OUTLET FROM ENGINE 1
