Description
F/4135-DP 4135 repair kits PS12867 860109146
1 S00003958 喷油器压板垫块 SPACER, INJECTOR CLAMP 3
2 S00009518 喷油器压板 CLAMP, INJECTOR 4
3 B00000973 球面垫圈 WASHER WITH BALL FACE 4 GB/T849-8
4 D03-112-01 螺栓 BOLT 4
5 S00014184 喷油器部件 INJECTOR ASSY 4
6 B00005415 O形橡胶密封圈 O-RING SEAL 1 GB/T3452.1-6.7*2.65
8 S00014239 喷油器进油接管 INJECTOR CONNECTOR 4
9 S00004602 喷油器进油接管螺母 NUT 4
10 B00002122 六角法兰面螺栓 BOLT 2 Q/SC622-M6*25-ZN.D
11 D26-105-02 夹片 CLAMP 2
12 D26-104-02 夹片衬垫 CLAMP LINER 4
13 D26C-130-903 高压油管焊接部件夹片 CLAMP 2
14 S00015111 第一缸高压油管 HIGH PRESSURE FUEL TUBE ASSY (NO.1 CYLINDER) 1
15 S00015112 第二缸高压油管 HIGH PRESSURE FUEL TUBE ASSY (NO.2 CYLINDER) 1
16 S00015113 第三缸高压油管 HIGH PRESSURE FUEL TUBE ASSY (NO.3 CYLINDER) 1
17 S00015114 第四缸高压油管 HIGH PRESSURE FUEL TUBE ASSY (NO.4 CYLINDER) 1
18 B00004880 六角法兰面螺栓 BOLT 2 GB/T16674.1-M10*25-10.9-F
19 S00012543 电子调速器执行部件 ACTUATOR ASSY, ELECTRONIC GOVERNOR 1
20 S00000285 喷油泵部件 FUEL INJECTION PUMP 1
21 B00001472 铰接式衬管接头 BANJO CONNECTOR 1 JB/T6015-14.2
22 B00000833 螺母 NUT 4 GB/T6177-M10-Y
23 B00001163 双头螺柱 STUD 4 GB/T900-AM10*30-8.8-Y
24 B00004902 六角法兰面螺栓 BOLT 6 GB/T16674.1-M10*40-10.9-F
25 S00011480 喷油泵过渡法兰 FUEL INJECTION PUMP FLANGE ADAPTER 1
26 B00001386 O型橡胶密封圈 O-RING 1
27 S00010030 O型橡胶密封圈 O-RING 1
28 S00012000 喷油泵支架 FUEL INJECTION PUMP BRACKET 1
29 S00010189 喷油泵支架 FUEL INJECTION PUMP BRACKET 1
30 B00002011 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M10*45-10.9
31 B00002058 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M12*40-10.9
32 D26-007-01 喷油泵回油管焊接部件 FUEL INJECTION PUMP FUEL RETURN TUBE ASSY (WELDED) 1
33 S00012022 燃油回油管 FUEL RETURN PIPE 1
34 B00001546 橡胶复合垫圏 WASHER 6 Q/SC1294-12
35 B00002178 铰接螺栓 BANJO BOLT 3 Q/SC642.1-01-M12*1.25
36 S00006746 燃油管路夹箍 CLAMP 1
38 S00015110 滤清器到高压油泵进油管部件 FUEL FILTER OUTLET LINE ASSY 1
39 S00015109 输油泵到滤清器进油管部件 FUEL SUPPLY PUMP OUTLET TUBE ASSY 1
40 B00002137 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M8*25
41 D638-000-02 燃油精滤器及座部件 FINE FUEL FILTER & BASE ASSY 1
42 B00004362 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 GB/T16674.1-M12*30
43 S00012890 燃滤支架 FINE FUEL FILTER BRACKET 1
44 S00013050 夹箍 CLAMP 1
