Description

F/A05-3L 135 PISTON RING 860113238 PS12895

1 D04-167-01A 碗形闷头 PLUG 1
2 D02A-163-01 螺塞Z3/4 PIPE PLUG 2
3 D04-308-01 碗形闷头 PLUG 9
4 S00018740 闷头 PLUG 5
5 S00004918 螺塞 PIPE PLUG 1
6 S00004986 O形圈 O-RING 1
7 D02A-164-01 螺塞Z1/2 PIPE PLUG 2
8 S00008872 气门杆油封 STEM SEAL, INTAKE VALVE 16
9 S00002889 气门弹簧 VALVE SPRING 16
10 S00002890 气门锁夹 VALVE COLLET 32
11 S00004345 气门弹簧上座 VALVE SPRING RETAINER 16
12 S00002897 气门桥 VALVE BRIDGE 8
13 B00000122 圆柱销 DOWEL 8 GB/T119-A6*18
14 D02A-310-01 碗形闷头 PLUG 7
15 S00024299 气缸盖螺栓 BOLT, CYLINDER HEAD 18
16 S00000844 气缸盖垫片 GASKET, CYLINDER HEAD 1
17 S00002888 排气门座圈 VALVE SEAT INSERT, EXHAUST 8
18 S00002887 进气门座圈 VALVE SEAT INERT, INTAKE 8
19 S00002886 排气门 VALVE, EXHAUST 8
20 S00002885 进气门 VALVE, INTAKE 8
21 T04-151-01 放气接头 BLEEDING JOINT 1
22 S00004163 气缸盖机加工部件 CYLINDER HEAD ASSY (MACHINED) 1
23 B00001708 内六角头螺塞 HEXAGON COUNTERSUNK PIPE PLUG 1 Q/SC584.2-M24*1.5
24 S00010416 O型橡胶密封圈 O-RING 1
25 B00001704 螺塞 PIPE PLUG 1 Q/SC584.2-M16*1.5
26 B00002471 O型橡胶密封圈 O-RING 1 Q/SC648-13.8*2.4

1 S00005036 发动机前吊环 ENGINE LIFTING EYE, FRONT 1
2 B00004880 六角法兰面螺栓 HEXAGON BOLTS 4 GB/T16674.1-M10*25-10.9-F
4 S00003087 调温器部件 THERMOSTAT ASSY 1
5 S00011790 气缸盖出水管 OUTLET TUBE 1
6 B00002118 六角法兰面螺栓 HEXAGON BOLTS 3 Q/SC622-M6*20
7 S00002892 气门推杆 PUSH ROD 8
9 S00004415 垫片 GASKET 4
13 B00002048 六角法兰面螺栓 HEXAGON BOLTS 2 Q/SC622-M12*25-10.9
14 S00005005 发动机后吊环 REAR ENGINE LIFTING EYE 1
15 S00004703 进气摇臂总成 ROCKER ARM ASSY 4
16 S00004583 摇臂轴 ROCKER SHAFT 8
17 S00002894 摇臂座 ROCKER SEAT 8
18 S00027101 螺栓 HEXAGON BOLTS 8
19 S00002895 进气摇臂部件 INTAKE ROCKER ARM ASSY 4
20 S00008491 气门间隙调整螺栓 BOLT 8
21 S00008495 气门间隙调整螺母 NUT 8
22 S00002896 排气摇臂部件 EXHAUST ROCKER ARM ASSY 4
23 S00004704 排气摇臂总成 ROCKER ARM ASSY 4
