Description

F548-000 114 FUEL DELIVERY PUMP

1 D04-145-30A 排气管螺栓 BOLT EXHAUST MANIFOLD 8
2 S00003833 排气管螺栓垫块 EXHAUST PIPE BOLT SPACER 8
3 S00011279 排气管 EXHAUST MANIFOLD 1
4 S00003834 排气管垫片 GASKET, EXHAUST MANIFOLD 4
5 S00012169 排气管隔热罩 HEAT SHIELD, EXHAUST MANIFOLD 1
6 S00012168 排气管隔热罩 HEAT SHIELD, EXHAUST MANIFOLD 1
7 D13-318-02 隔热板螺栓 BOLT 2
8 D13-318-04 隔热板螺栓 BOLT 2
9 B00001729 六角头螺塞 HEXAGON PIPE PLUG 1 Q/SC587.1-M20*1.5
10 B00001550 复合式密封硬垫圈 RUBBER COATED HARD WASHER 1 Q/SC1294-20
11 S00015127 进气管盖板 COVER, AIR INTAKE PIPE 1
12 B00001724 六角头螺塞 HEXAGON PIPE PLUG 1 Q/SC587.1-M10*1
13 B00001545 复合式密封硬垫圈 RUBBER COATED HARD WASHER 1 Q/SC1294-10
14 S00005856 六角法兰面螺栓 HEX HEAD BOLT 12
15 B00001542 弹簧卡箍 SPRING CLAMP 4 Q/SC1092-85
16 B00001627 橡胶软管 HOSE 2 Q/SC1372-76*100
17 S00015180 进气接管 INTAKE TUBE EXTENSION 1
18 S00015177 压气机出气弯管 COMPRESSOR OUTLET ELBOW 1
19 S00006095 夹箍 CLAMP 1

1 B00002178 增压器进油铰接螺栓 BOLT 1 Q/SC642.1-01-M12*1.25
2 S00011472 增压器进油管 TURBOCHARGER OIL INLET PIPE 1
3 B00001818 铜垫圈 COPPER WASHER 2 Q/SC598-12*16
4 S00003939 接头 CONNECTOR 1
5 S00005682 O型橡胶密封圈 O-RING 1
6 D13-108-50 增压器自锁螺母 TURBOCHARGER SELF-LOCKING NUT 4
7 S00003525 双头螺柱 STUD 4
8 S00014383 增压器 TURBOCHARGER 1
9 D13-103-52 涡轮出口垫片 GASKET, OUTLET-TURBINE 1
10 S00003835 涡轮进口垫片 GASKET, INLET-TURBINE 1
11 S00011473 增压器回油管 TURBOCHARGER OIL RETURN PIPE 1
12 S00003929 增压器回油管垫片 TURBOCHARGER OIL RETURN TUBE GASKET 1
13 B00004893 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 GB/T16674.1-M6*20-10.9-F
14 D02A-171-80 O形圈 O-RING 2
15 S00000146 膨胀节 EXPANSION CONNECTOR 1
16 B00002003 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M10*30-ZN.D
17 S00012192 排气弯管 EXHAUST PIPE ELBOW 1
18 B00001138 “双头螺栓
” STUD 5 GB/T899-GM8-M8*30-8.8-Y
19 B00000793 “I型六角螺母
” HEXAGON NUT (TYPE 1) 5 GB/T6170-M8-Y
20 S00012191 排气弯管支架 BRACKET, EXHAUST PIPE ELBOW 1
21 B00002000 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M10*25-ZN.D
22 S00011235 夹箍 CLAMP 2
23 B00002110 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 1 Q/SC622-M6*10
24 B00000790 I型六角螺母 HEXAGON NUT (TYPE 1) 1 GB/T6170-M6-Y
25 A745DC-13-001 消声器垫片 GASKET, MUFFLER 1
S00012650 增压器隔热罩部件 HEAT SHIELD, TURBOCHARGER 1
