Description

S00003617+01 r ALTERNATOR

1 S00004864 机油冷却器垫片 GASKET, OIL COOLER 1
2 S00003083 机油冷却器芯子焊接部件 CORE ASSY (WELDED), OIL COOLER 1
3 S00004865 机油冷却器垫片 GASKET, OIL COOLER 1
4 S00004867 机油冷却器盖装配部件 COVER ASSY, OIL COOLER 1
5 B00004449 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 15
6 S00012368 机油滤清器部件 OIL FILTER ASSY 1

1 S00013393 垫块 SPACER 1
2 S00013436 吸油管焊接部件 OIL SUCTION PIPE ASSY 1
3 S00005011 吸油管法兰垫片 GASKET, PIPE FLANGE-OIL SUCTION PUMP 1
4 B00004880 六角法兰面螺栓 HEX HEAD BOLT 1
5 B00004885 六角法兰面螺栓 HEX HEAD BOLT 2
6 S00012860 油底壳装配部件 OIL PAN ASSY 1
7 B00001707 内六角螺塞 HEX SOCKET PIPE PLUG 1
8 B00001551 复合式密封硬垫圈 RUBBER COATED HARD WASHER 1
9 S00011730 油底壳压条 CLAMPING BAR – OIL SUMP 1
10 S00011731 油底壳压条 CLAMPING BAR – OIL SUMP 1
11 B00002132 六角法兰面螺栓 HEX HEAD BOLT 18
12 B00002134 六角法兰面螺栓 HEX HEAD BOLT 6
