S00009382-02 WATER PUMP
| 1 | 机体装配部件 | CYLINDER BLOCK ASSEMBLY | D02A-001-30B+F | 1 |
| 1.0 | 机体机械加工部件 | CYLINDER BLOCK MACHINED ASSEMBLY | D02A-002-31+E | 1 |
| 1.01 | 机体 | CYLINDER BLOCK | D02A-101-31+E | 1 |
| 1.02 | 主轴承盖螺栓 | BOLT, MAIN BEARING CAP | D02A-106-30+A | 14 |
| 1.03 | 主轴承盖 | MAIN BEARING CAP | D02A-105-31+A | 6 |
| 1.03 | 主轴承盖 | MAIN BEARING CAP | D02A-105-40+A | 1 |
| 1.04 | 定位套筒 | PIN, MAIN BEARING CAP | D02A-322-40+B | 2 |
| 1.05 | O型圈 | SEAL, O RING | D28-107-01+A | 1 |
| 1.06 | O型橡胶密封圈 | SEAL, O RING | D02A-171-80+B | 2 |
| 1.12 | 油尺管 | TUBE, DIPSTICK | D02A-142-05+B | 1 |
| 1.13 | 凸轮轴轴承 | BUSHING, CAMSHAFT | D02A-113-01B+B | 7 |
| 凸轮轴闷头 | PLUG, EXPANSION | D02A-162-40+B | 1 | |
| O型圈 | SEAL, O RING | D02A-324-40+A | 1 | |
| 1.14 | 圆柱闷头 | PLUG, EXPANSION | D02A-309-01+B | 1 |
| 1.15 | 闷头（φ20） | PLUG, EXPANSION | D02A-161-01+A | 1 |
| 1.15 | 闷头(φ20) | PLUG, EXPANSION | D02A-161-31+B | 2 |
| 1.16 | 闷头（φ28） | PLUG, EXPANSION | D04-166-01A+A | 2 |
| 1.18 | 回油管 | TUBE, OIL RETURN | D02A-139-03A+C | 1 |
| 1.19 | 螺塞 | PLUG, EXPANSION | D02A-170-01+A | 1 |
| 1.22 | 闷头（φ20） | PLUG, EXPANSION | D02A-310-01+A | 1 |
| 1.23 | 闷头（φ35） | PLUG, EXPANSION | D04-167-01A+A | 8 |
| 2 | 加油口部件 | CAP ASSEMBLY, OIL FILLER | D02A-004-01+B | 1 |
| 6 | 管接螺母 | NUT | D02A-179-01+A | 1 |
| 7 | Q/SC1294-12:复合式密封硬垫圈 | COMPOSITE HARD SEAL GASKET | B00001546 | 2 |
| 8 | 六角头螺塞 | PLUG, THREADED | D02A-168-01+A | 1 |
| 9 | Q/SC622-M8*80:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002165 | 4 |
| 11 | Q/SC622-M8*25:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002137 | 2 |
| 12 | 油泵托架 | SUPPORT, FUEL INJECTION PUMP | D02A-173-40+C | 1 |
| 12 | 油泵支架 | BRACKET, FUEL INJECTION PUMP | D02A-174-40+C | 1 |
| 15 | 螺塞(Z1/8) | PLUG（Z1/8）,PIPE | D02A-166-01+C | 2 |
| 16 | 活塞冷却喷嘴部件 | NOZZLE ASSEMBLY, PISTON COOLING | D02A-030-01+A | 6 |
| 17 | 曲轴推力轴承(上) | THRUST BEARING, CRANKSHAFT（UP） | D02A-111-30+B | 1 |
| 18 | 主轴承下瓦 | MAIN BEARING (LOWER) | D02A-112-01+A | 6 |
| 19 | 主轴承上瓦 | MAIN BEARING (UPPER) | D02A-110-01A+A | 6 |
| 20 | 凸轮轴推力板 | THRUST PLATE, CAMSHAFT | D02A-114-01C+A | 1 |
| 21 | GB/T5783-M8*20:六角头螺栓 | HEXAGON HEAD BOLT | B00000631 | 2 |
| 22 | 齿轮室垫片 | GASKET, GEAR HOUSING | D02A-129-30A+D | 1 |
| 23 | Q/SC622-M12*50:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002062 | 4 |
| 24 | GB/T119-A10*20:圆柱销 | DOWEL, PIN | B00000098 | 2 |
| 25 | Q/SC622-M8*35:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002142 | 4 |
| 26 | Q/SC622-M8*45:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002147 | 2 |
| 28 | GB/T879-12*12:弹性圆柱销 | ELASTIC DOWEL PIN | B00001020 | 3 |
| 29 | 垫片 | GASKET | D02A-307-01+C | 1 |
| 30 | 气缸盖垫片 | GASKET, CYLINDER HEAD | D02A-109-30B+A | 1 |
| 31 | 气缸盖长螺栓 | BOLT (LONG), CYLINDER HEAD | D02A-107-40+A | 20 |
| 32 | 气缸盖短螺栓 | BOLT (SHORT), CYLINDER HEAD | D02A-108-40+A | 6 |
| 33 | 气缸套 | CYLINDER LINER | D02A-104-30A+C | 6 |
| 34 | 缸套封水圈 | SEAL, CYLINDER LINER | D02A-171-30A+A | 18 |
| 35 | 圆柱销 | DOWEL, PIN | D02A-312-01+A | 2 |
| 36 | Q/SC1294-10:复合式密封硬垫圈 | COMPOSITE HARD SEAL GASKET | B00001545 | 2 |
| 37 | Q/SC622-M8*40:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002145 | 2 |
| 37 | Q/SC587.1-M10*1:六角头螺塞 | PLUG, PIPE | B00001724 | 2 |
| 38 | 机油冷却器垫片 | GASKET, OIL COOLER | D02A-133-30A+C | 1 |
| 39 | 六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | D02A-311-01+A | 2 |
| 40 | 六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | D02A-306-01A+A | 4 |
| 45 | 内六角螺塞(Z3/4) | BOLT（Z3/4）,PIPE | D02A-163-01+C | 1 |
| 46 | GB/T119-A12*24:圆柱销 | DOWEL, PIN | B00000102 | 2 |
| 47 | 后盖板垫片 | GASKET, REAR COVER | D02A-121-01A+C | 1 |
| 48 | 后盖板 | REAR COVER | D02A-115-01B+B | 1 |
| 49 | 后盖板O型密封圈 | REAR COVER SEAL, O RING | D02A-116-01+B | 1 |
| 50 | 曲轴后油封 | REAR CRANKSHAFT SEAL | D02A-118-02B+B | 1 |
| 51 | Q/SC622-M6*16:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002114 | 8 |
| 52 | Q/SC622-M12*40:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002058 | 12 |
| 54 | 曲轴推力轴承下瓦 | THRUST BEARING, CRANKSHAFT（DOWN） | D02A-323-01+A | 1 |
| 55 | Q/SC622-M8*55:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002153 | 7 |
| 56 | Q/SC597-8*26:加大毛垫圈 | GASKET | B00001811 | 1 |
| 57 | GB3452.1-16*2.65:O形橡胶密封圈 | SEAL, O RING | B00001378 | 1 |
| Q/SC622-M10*90:六角法兰面螺栓 | BOLT, HEX FLANGE HEAD CAP | B00002032 | 2 |
