Description

S00015359+02 water pipe

1 2 761G-07-042+A 惰齿轮固定螺钉 BOLT 2
2 2 761G-07-043+A 压紧垫片 GASKET 2
3 2 B00000214 滚动轴承 BALL BEARING 6
4 2 S00015236+01 传动惰齿轮 IDLER GEAR, DRIVE PUMP 1
5 2 B00001063 轴用弹性挡圈 A型 AXES RETAINER FOR HOLE (TYPE A) 1
6 2 771-07-026+A 孔用弹性挡圈 RING RETAINER FOR HOLE (TYPE A) 1
7 2 S00010308+03 左淡水泵传动齿轮 GEAR, WATER PUMP（LEFT） 1
8 2 771-07-004A+B 左凸轮轴传动齿轮 GEAR, LEFT CAMSHAFT 1
9 2 B00000634 六角头螺栓 HEXAGON HEAD BOLT 10
10 2 B00001882 六角头头部带孔螺栓 HEX HEAD BOLT WITH WIRE HOLE ON HEAD 2
11 2 761-07-024A+A 锁紧垫片 GASKET 4
12 2 S00010309+03 右淡水泵传动齿轮 GEAR, WATER PUMP(RIGHT) 1
13 2 DXTS+A 镀锌铁丝 WIRE 2
14 2 B00001871 六角头头部带孔螺栓 HEX HEAD BOLT WITH WIRE HOLE ON HEAD 2
15 2 771-07-029+A 压板 CLAMP 2
16 2 771-07-005A+B 右凸轮轴传动齿轮 GEAR, RIGHT CAMSHAFT 1
17 2 B00000926 圆螺母 ROUND NUT 1
18 2 B00001674 全齿形止退垫圈 FULL TOOTH LOCK WASHER 1
19 2 761G-07-035A+A 甩油圈 OIL SLINGER 1
20 F/1401 主动齿轮维修组件 DRIVE GEAR SERVICE GROUP 1
2 771-07-006+A 主动齿轮 1
21 2 B00000136 圆柱销 PIN 1
22 2 761-07-019B+A 推力板 THRUST PLATE 1
23 2 S00010310+03 惰齿轮压紧螺栓 BOLT 1
24 2 S00010520+02 垫片 GASKET 1
25 2 771-07-008+A 惰齿轮 IDLER GEAR 1
26 2 761-07-009A+A 隔圈 SPACER 2
27 2 B00001045 孔用弹性挡圈-A型 RING RETAINER FOR HOLE (TYPE A) 2
28 2 S00015237+01 定时惰齿轮 TIMING IDLER GEAR 1
29 2 B774ZL-07-005+A 喷油螺栓 BOLT, INJECTOR 2
30 2 B00002230 铰接螺栓 BANJO BOLT 1
31 F/1401 进油管维修组件 FUEL INLET PIPE SERVICE GROUP 1
2 B774ZL-07-030+A 进油管焊接部件 1
3 B774ZL-07-003+A 管接头体 1
3 B774ZL-07-004+A 油管 1
3 B774ZL-07-006+A 铰接式管接头体 2
3 B774ZL-07-007+A 油管 1
32 F/1401 进油管维修组件 FUEL INLET PIPE SERVICE GROUP
2 S00011663+01 进油管焊接部件 1
3 B00002235 管接头体 2
3 S00011663-01+01 进油管 1
33 F/1401 进油管维修组件 FUEL INLET PIPE SERVICE GROUP
2 S00011686+01 进油管焊接部件(右) 1
3 S00011686-01+01 进油管焊接部件 1
3 B00002235 管接头体 2
34 2 B00001824 铜垫圈 COPPER WASHER 6
35 2 G18-113-01+A 调整铜垫圈 WASHER 2
36 2 S00005021+01 喷油泵齿轮固紧螺钉 INJECTION PUMP GEAR SCREW 1
37 2 761G-07-032B+A 垫圈 WASHER 1
38 2 S00000105+01 喷油泵传动齿轮 FUEL INJECTION PUMP GEAR 1
39 2 B00002047 六角法兰面螺栓 BOLT 3
40 2 S00000128+02 喷油泵传动轴部件 FUEL INJECTION PUMP SHAFT ASSY 1
41 F/1401 喷油泵传动轴维修组件 FUEL INJECTION PUMP SHAFT SERVICE GROUP 1
3 S00000037+02 喷油泵传动轴 1
42 3 B00000059 半圆键 WOODRUFF KEY 1
43 3 B00001050 孔用弹性挡圈-A型 RING RETAINER FOR HOLE (TYPE A) 1
44 3 B00005077 滚动轴承 BALL BEARING 2
45 F/1401 喷油泵传动轴承座维修组件 FUEL INJECTION PUMP BEARING HOUSING SERVICE GROUP 1
3 S00000034+03 喷油泵传动轴承座 1
46 3 B00001450 骨架油封 FRAMED STRUCTURE OIL SEAL 1
47 2 761G-07-039+A 垫片 GASKET 1
48 3 S00000153+05 六角头螺栓 HEXAGON HEAD BOLT 1
49 2 S00000160+05 联轴节装配部件 COUPLING ASSY (ASSEMBLED) 1
3 S00000150+02 连接抓 1
3 S00000158+02 传动钢片装配部件 1
4 S00000107+02 传动钢片 6
4 S00000108+02 传动钢片 2
4 W25A-109-01+A 衬套 4
4 W25A-105-01+A 垫圈 4
3 S00000159+02 传动钢片装配部件 1
4 S00000107+02 传动钢片 6
4 S00000108+02 传动钢片 2
4 W25A-109-01+A 衬套 2
4 W25A-105-01+A 垫圈 2
4 S00000113+01 定位圈 2
4 S00000109+01 定位圈 2
3 S00000152+03 高压油泵接合器接盘 1
50 3 B00002058 六角法兰面螺栓 BOLT 2
51 3 B00002051 六角法兰面螺栓 BOLT 4
52 3 B00000836 六角法兰面螺母 NUT 2
53 3 B00002055 六角法兰面螺栓 BOLT 2
54 2 B00002001 六角法兰面螺栓 BOLT 1
55 2 B00001999 六角法兰面螺栓 BOLT 9
56 2 S00010616+01 传动机构盖板装配部件 COVER ASSY, DRIVE MECHANISM 1
57 3 761-07-022C+A 前端推力轴承 THRUST BEARING, FRONT END 1
58 3 B774ZL-07-008+B 传动机构盖板 COVER, DRIVE MECHANISM 1
59 3 B00001237 弹簧垫圈 SPRING WASHER 3
60 3 761G-07-051+A 六角头圆柱端紧定螺钉 BOLT 3
61 3 771-07-025+A 后端推力轴承 THRUST BEARING, REAR END 1
62 3 761-07-034+A 保险垫片 LOCK WASHER 6
63 3 B00000603 六角头螺栓 HEXAGON HEAD BOLT 12
64 3 A771Z-07-007+A 惰齿轮轴 IDLER GEAR 1
65 3 A771Z-07-006+A 惰齿轮轴 IDLER GEAR 1
66 3 S00010521+01 凸轮轴惰齿轮轴 CAMSHAFT IDLER GEAR SHAFT 1
