Description

T88-271-50+A 114 CONNECTOR PS13765

1 W02A-001-01 机体机加工部件 CYLINDER BLOCK ASSY (MACHINED) 1
2 G02-134-01 定位销 DOWEL PIN 1
3 W02A-118-01 曲轴推力轴承 THRUST BEARING, CRANKSHAFT 4
4 B00000118 圆柱销 PARALLEL PINS 4 GB/T119-A5*14
5 W02A-140-01 垫圈 WASHER 2
6 B00001712 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 2 Q/SC584.2-M42*1.5
7 W02A-139-01 垫圈 WASHER 1
8 B00004185 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 1 Q/SC584.2-M48*1.5
9 W02A-113-01 凸轮轴中间轴承 INTERMEDIATE MAIN BEARING HOUSING,CAMSHAFT 5
10 W02A-127-01 定位销 DOWEL PIN 5
11 W02A-126-01 滚轮轴座圈 SEAT INSERT, ROLLER SHAFT 5
12 W02A-112-01 凸轮轴后端轴承 REAR BEARING, CAMSHAFT 1
13 W02A-124-01 滚轮轴后座 REAR HOUSING, ROLLER SHAFT 1
14 W02A-138-01 凸轮轴止推片 THRUST PLATE,CAMSHAFT 1
15 B00004158 圆柱销 PARALLEL PINS 2 GB/T119-A4*10
16 W02A-130-01 凸轮轴止推板 THRUST PLATE, CAMSHAFT 1
17 B00002054 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 17 Q/SC622-M12*35
18 B00001835 铜垫圈 COPPER WASHER 2 Q/SC598-20*26
19 B00001706 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 2 Q/SC584.2-M20*1.5
20 B00001827 铜垫圈 COPPER WASHER 5 Q/SC598-16*20
21 B00001704 内六角螺塞 HEXAGONAL SOCKET HEAD PLUG 5 Q/SC584.2-M16*1.5
22 W02A-151-02 推杆孔导向套 GUIDE SLEEVE, TAPPET HOLE 12
23 W02A-153-02 推杆孔封油圈 SEALING RING, TAPPET HOLE 12
24 W02A-151-01 通油管 OIL PIPE 6
25 W02A-154-01 推杆孔橡皮圈 RUBBER RING, TAPPET HOLE 6
26 B00001818 铜垫圈 COPPER WASHER 1 Q/SC598-12*16
27 B00004610 内六角头螺塞 HEXAGON COUNTERSUNK PLUG SCREW 1 Q/SC584.2-M12*1.25
28 W02A-117-01 缸套封水圈 SEAL, CYLINDER LINER 18
29 W02A-102-01 缸套 CYLINDER LINER 6
30 W02A-107-01 气缸盖垫片【１８０】 GASKET, CYLINDER HEAD 6
31 B00000121 圆柱销 PARALLEL PINS 12 GB/T119-A6*12
32 W02A-108-01 气缸盖螺柱 BOLT, CYLINDER HEAD 48
33 W02A-109-01 气缸盖螺母 NUT, CYLINDER HEAD 48
34 W02A-125-01 滚轮轴前座 FRONT HOUSING, ROLLER SHAFT 1
35 W02A-111-01 凸轮轴前端轴承 FRONT BEARING, CAMSHAFT 1
36 W02A-131-01 滚轮轴前螺塞铜垫圈 COPPER WASHER, ROLLER SHAFT PLUG 1
37 W02A-129-01 滚轮轴前螺塞 PLUG, ROLLER SHAFT 1
38 W02A-150-01 凸轮轴孔前端盖板垫片 GASKET, CAMSHAFT BORE FRONT COVER 1
39 W02A-149-01 凸轮轴孔前端盖板 FRONT COVER, CAMSHAFT BORE 1
40 B00002134 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 6 Q/SC622-M8*20
41 S00010180 主轴瓦（上） MAIN BEARING, UPPER 7
42 S00010280 主轴瓦（下） MAIN BEARING, LOWER 7
43 W02A-116-01 进水道闷头垫圈 WASHER, WATER INLET PLUG 6
44 W02A-115-02 接头 CONNECTOR 1
45 B00001699 内六角锥形螺塞 HEXAGON COUNTERSUNK CONE PLUG SCREW 1 Q/SC584.1-R3/4
46 W02A-115-01 进水道闷头 PLUG, WATER INLET 5
47 S00000661 变速器输出轴轴承支座定位套 TRANSMISSION AXIS BEARING SUPPORT LOCATING SLEEVE 2
