Description

T88-306-01+A 114 CABLE PS15521

1 S00022715 缸盖机加工部件 CYLINDER HEAD ASSY (MACHINED) 6
2 W04B-105-01 气门锁夹 VALVE COLLET 48
3 W04B-001-01 旋转机构部件 VALVE ROTOCOLL ASSY 24
4 W04B-103-01 气门大弹簧 VALVE SPRING 24
5 W04B-104-01 气门小弹簧 VALVE SPRING 24
6 W04B-120-01 弹簧下座 VALVE SPRING GUIDE 24
7 B00001733 六角头螺塞 HEXAGON PLUG SCREW 6 Q/SC587.1-M8*1
8 B00001854 铜垫圈 COPPER WASHER 6 Q/SC598-8*12
9 B00001815 铜垫圈 COPPER WASHER 6 Q/SC598-10*18
10 B00001724 六角头螺塞 HEXAGON PLUG SCREW 6 Q/SC587.1-M10*1
11 W04B-102-01 排气门 VALVE, EXHAUST 12
12 W04B-101-01 进气门 VALVE, INTAKE 12
13 B00002066 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 12 Q/SC622-M12*55
14 B00001547 复合式密封硬垫圈 COMPOSITE HARD SEAL GASKET 12 Q/SC1294-14
15 W04A-119-01 缸盖罩壳 VALVE COVER 6
16 W04A-120-01 气缸盖罩壳密封圈 VALVE COVER RING 6
17 W04A-125-01 摇臂座螺母 NUT, ROCKER ARM PEDESTAL 12
18 B00001278 平垫圈 PLAIN WASHER 12 GB/T97.1-12-200HV-Y
19 B00004177 双头螺柱 STUD 12 GB/T899-GM12-M12*60-8.8-Y
20 B00000836 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 12 GB/T6177-M12-Y
21 B00001131 双头螺柱 STUD 12 GB/T899-GM12-M12*90-8.8-Y
22 W04A-003-01 摇臂座(左)机械加工部件 ROCKER ARM PEDESTAL ASSY (MACHINED) 6
23 W04B-119-01 螺母 NUT 24
24 W04B-003-01 排气门摇臂装配部件 EXHAUST ROCKER ARM ASSEMBLY 6
25 W04B-004-01 调节螺钉装配部件 ADJUSTING SCREW ASSEMBLY 24
26 W04B-002-01 进气门摇臂装配部件 ROCKER ARM ASSEMBLY, INTAKE 6
27 W04A-002-01 摇臂座(右)机械加工部件 ROCKER ARM PEDESTAL ASSY (MACHINED) 6

1 W09A-104-01 六角头螺栓 HEXAGON HEAD BOLTS 6
2 W09A-001-01 凸轮轴装配部件 CAMSHAFT ASSY (ASSEMBLED) 1
3 W09A-109-01 定位销 DOWEL PIN 1
4 D02A-159-01A 闷头(φ30) PLUG 2
5 B00004189 小六角头头部带孔螺栓 SMALL HEX HEAD BOLT WITH WIRE HOLE ON HEAD 6 Q/SC611.3-M8*28
6 G02-134-01 定位销 DOWEL PIN 1
7 W09A-106-01 短定位环 LOCATING RING 6
8 W09A-002-01 滚轮摇臂部件 ROLLER ROCKER ARM ASSY 12
9 W09A-105-01 长定位环 LOCATING RING 6
10 W09A-114-01 堵塞 PIN PLUG 6
11 W09A-103-01 摇臂轴 SHAFT, ROCKER ARM 3
12 W04B-005-01 进气挺杆部件 INTAKE PUSH ROD ASSEMBLY 6
13 W04B-006-01 排气挺杆部件 EXHAUST PUSH ROD ASSEMBLY 6
