Description

T89-002-05+A 114 SPARK PLUG PS13801 860125505

1 S00021245 排气尾管部件 EXHAUST TAILPIPE ASSY 1
2 S00021429 活塞环 PISTON RING 8
3 S00021304 排气接管 EXHAUST PIPE 2
4 S00021668 夹箍 CLAMP 2
5 S00020938 增压器部件 TURBOCHARGER ASSY 1
6 B00002181 铰接螺栓 HINGE BOLT 2 Q/SC642.1-01-M18*1.5
7 B00002050 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 6 Q/SC622-M12*30
8 S00021808 夹箍 CLAMP 2
9 S00025259 增压器进油管 OIL INLET PIPE, TURBOCHARGER 1
10 B00001824 铜垫圈 COPPER WASHER 4 Q/SC598-14*20
11 B00002179 铰接螺栓 HINGE BOLT 2 Q/SC642.1-01-M14*1.5
12 W19B-102-01 增压器回油垫片 OIL RETURN PIPE GASKET, TURBOCHARGER 2
13 B00001996 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 8 Q/SC622-M10*20
14 B00002114 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M6*16
15 D19-003-01A 夹箍 CLAMP 4
16 B00000843 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 2 GB/T6177-M6-Y
17 S00025260 增压器回油管 OIL RETURN PIPE, TURBOCHARGER 1
18 B00001833 铜垫圈 COPPER WASHER 4 Q/SC598-18*28
19 S00023269 垫片 GASKET 2
22 S00022346 垫块 SPACER 4
23 B00002021 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M10*65-10.9
24 S00021622 排气尾管隔热罩部件 EXHAUST TAILPIPE HEAT-SHIELD ASSEMBLY 1
25 B00001994 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 2 Q/SC622-M10*16
26 B00002028 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M10*75-10.9
27 S00022345 垫块 SPACER 2
28 B00001246 弹簧垫圈 SINGLE COIL SPRING LOCK WASHERS, NORMAL TYPE 16 GB/T93-20
29 B00000781 I型六角螺母 HEXAGON NUTS, STYLE 1 16 GB/T6170-M20-ZN.D
30 S00021657 排气尾管支架焊接部件 EXHAUST TAIL PIPE BRACKET 1
31 B00002057 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M12*40
32 S00021658 排气尾管支架焊接部件 EXHAUST TAIL PIPE BRACKET 1
33 B00000836 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 4 GB/T6177-M12-Y
34 S00020937 增压器部件 TURBOCHARGER ASSY 1
37 S00025257 增压器进油管 OIL INLET PIPE, TURBOCHARGER 1
38 S00025258 增压器回油管 OIL RETURN PIPE, TURBOCHARGER 1
39 W00A-156-01 波形膨胀节 EXPANSION CONNECTOR 1
40 B00001287 平垫圈 PLAIN WASHER 16 GB/T97.1-20-200HV-ZN.D
41 B00000466 六角头螺栓 HEXAGON HEAD BOLTS 16 GB/T5782-M20*70
42 S00026157 消声器焊接部件 MUFFLER ASSY (WELDED) 1

1 S00021712 夹箍 CLAMP 2
2 S00021488 增压器出气管 AIR OUTLET PIPE TURBO CHARGER 1
3 B00001533 弹簧卡箍 SPRING CLAMP 6 Q/SC1092-135
4 S00021625 中冷器进气橡胶管 AIR INLET HOSE, INTERCOOLER 3
5 S00021386 三通气管 T-TYPE AIR PIPE 1
6 B00001999 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 4 Q/SC622-M10*25
7 S00021788 增压器出气管支架 AIR OUTLET PIPE BRACKET,TURBOCHARGER 1
8 W12B-111-01 连接板 JUNCTION PLATE 3
9 B00001994 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 6 Q/SC622-M10*16
10 S00021632 夹箍 CLAMP 2
11 B00000833 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 12 GB/T6177-M10-Y
12 B00001562 喉箍 CLAMP 4 Q/SC1302-143~165
13 S00021387 增压器进气连接管 COMPRESSOR INLET PIPE 2
14 S00021493 增压器进气管 AIR INLET PIPE, TURBOCHARGER 1
15 B00002137 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 10 Q/SC622-M8*25
16 S00021482 增压器进气管支架 AIR INLET PIPE BRACKET,TURBOCHARGER 2
17 B00000846 六角法兰面螺母 HEXAGON NUTS WITH FLANGE 10 GB/T6177-M8-Y
18 S00021633 夹箍 CLAMP 4
19 B00001996 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE 8 Q/SC622-M10*20
20 W14A-000-01 空气滤清器组件 AIR FILTER GROUP 2
21 S00021481 空滤器支架 AIR FILTER BRACKET 2
22 S00021494 增压器进气管 AIR INLET PIPE, TURBOCHARGER 1
23 S00021487 增压器出气管 AIR OUTLET PIPE OF TURBO CHARGER. 1
