Description

W04A-118-01+A gasket

1 D24A-321-01A 过渡接头 JOINT ADAPTER 1
2 D24A-319-01B 除气管 VENT PIPE 1
3 B00002177 铰接螺栓 BANJO BOLT 1 Q/SC642.1-01-M10*1
4 B00001545 复合式密封硬垫圈 RUBBER COATED HARD WASHER 2 Q/SC1294-10
5 D24A-307-01 橡胶弯管 HOSE 1
6 B00001573 喉箍 CLAMP 11 Q/SC1302-40~64
7 D00-137-01 夹箍 CLAMP 2
8 B00001575 喉箍 CLAMP 5 Q/SC1302-52~76
9 D24A-310-01 橡胶弯管 HOSE 1
10 D24A-317-01A 除气管 VENT PIPE 2
11 D24A-318-01A 除气管 VENT PIPE 1
12 D24A-030-01 出水管焊接部件 WATER OULET TUBE ASSY (WELDED) 1
13 D24A-309-01 橡胶弯管 HOSE 1
14 B00001569 喉箍 CLAMP 6 Q/SC1302-21~44
15 D24A-110-30A 出水管 WATER OULET TUBE 1
16 D02A-164-01 内六角螺塞(Z1/2) PLUG 1
17 D24A-116-30 水滤器连接胶管 HOSE, WATER FILTER 2
18 D24A-115-02 直管接头 JOINT 2
19 B00001563 喉箍 CLAMP 4 Q/SC1302-16~25
20 D24A-316-01 连接胶管 HOSE, WATER FILTER 1
21 D22-105-01 套筒销 DOWEL SLEEVE 2
22 D24A-320-01 过渡接头 JOINT ADAPTER 1
23 D24A-107-02A 橡胶进水弯管 WATER INLET ELBOW 1
24 B00002167 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 2 Q/SC622-M8*90-10.9
25 D00-324-01 夹箍 CLAMP 1
26 B00002132 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 1 Q/SC622-M8*16
27 B00000846 六角法兰面螺母 NUT 1 GB/T6177-M8-Y
28 D24A-315-01 连接胶管 HOSE, WATER FILTER 1
29 D24A-301-01 支架 BRACKET 1
30 B00002047 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 1 Q/SC622-M12*25
31 761G-02-105 放水阀 WATER DRAIN COCK 1
32 D24A-005-30 “DCA4”水滤器部件 DCA4 WATER FILTER ASSY 1
33 D24A-006-01 水滤器盖部件 BASE ASSY, WATER FILTER 1
33.1 D24A-118-01 水滤器截流阀 CHECK VALVE, WATER FILTER 2
33.2 S00003519 水滤器盖总成 WATER FILTER COVER ASSY 1
34 D24A-032-01 热交换器出水管焊接部件 WATER OUTLET PIPE ASSY (WELDED), HEAT EXCHANGER 1
35 D24A-112-33 水滤器固定板 MOUNTING PLATE, WATER FILTER 1
36 B00002139 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 4 Q/SC622-M8*30
37 B00002416 橡胶水管 WATER HOSE 1 Q/SC646-51*80
38 B00002130 六角法兰面螺栓 HEX HEAD BOLT (FLANGED) 1 Q/SC622-M8*12
39 D24A-303-01 压板 CLAMP 1
40 B00001383 O型橡胶密封圈 O-RING 1 GB3452.1-28*3.55
41 D24A-033-01 机体出水接头焊接部件 WATER OUTLET JOINT ASSY (WELDED), CYLINDER BLOCK 1
42 D24A-326-01 铰接式接头 JOINT 1
43 D24A-314-01 连接胶管 HOSE, WATER FILTER 1
44 D24A-304-01 橡胶弯管 HOSE 2
45 D00-324-03 夹箍 CLAMP 1
46 B00001708 内六角螺塞 PLUG 1
47 B00001552 复合式密封硬垫圈 RUBBER COATED HARD WASHER 1 Q/SC1294-24
48 D24A-031-01 中冷器出水管焊接部件 WATER OUTLET PIPE ASSY (WELDED), INTERCOOLER 1
49 B000022392 橡胶水管 WATER HOSE 1 Q/SC646-45*120
