Description
Z620030141 SEM MOTOR GRADER WHEEL LOADER SPARE PARTS
1 BOLT M12×50 B040811250 GB/T5782-2000
18
2 BOLT M16×85 B040811685 GB/T5782-2000
4
3 BOLT M30X140 B040880003 GB5782-2000
8
4 BOLT M10×25 B040911025 GB/T5783-2000
6
5 BOLT M12×20 B040911220 GB/T5783-2000
3
6 BOLT M14×1.5×40 B041111440 GB/T5786-2000
10
7 BOLT M16×25 B040911625 GB/T5783-2000
1
8 BOLT M10×1×25 B041200002 JB999-77
4
9 NUT M30 B050263024 GB/T889.1-2000
8
10 WASHER10 B060411002 GB/T97.1-2002
6
11 WASHER12 B060411203 GB/T97.1-2002
18
12 WASHER14 B060411403 GB/T97.1-2002
10
13 WASHER16 B060411603 GB/T97.1-2002
4
14 WASHERA 10 B060811002 JB982-77
8
15 COTTER PIN6.3×30 B080210016 GB/T91-2000
2
16 OIL CUPM10×1 B150101000 JB/T7940.1-1995
5
17 PIN Z310020020 ZL30D-2-17
2
18 SAFETY ROD Z320020010 ZL30F.2-1
1
19 WASHER Z520020890
1
20 SUPPORT PAD Z520030010 ZL50F.3-1
2
21 STEERING CYLINDER REAR PIN ASSEMBLY Z520030621
2
22 LOWER SPACER Z520031200
1
23 PLATE Z520031230
1
24 BUSHING Z530030330
1
25 GASKET Z530030340
2
26 PLATE Z530030350
1
27 LUBRICATING LINE ASSEMBLY Z5A40300900
2
28 OSCILLATING FRAME ASSEMBLYII Z5B40301800
1
29 COVER Z5B40302500
1
30 OSCILLATING FRAME ASSEMBLYI Z5B405001
1
31 BUSHING Z5B405002
1
32 SEAL RING
2
33 END CAP Z5B405004
1
34 LOWER JOINT PIN Z620030141
1
35 PIN MANDREL Z620030360
1
36 UPPER SPACER Z620030370
1
37 WASHER Z640020100
2
38 PLATE Z640030030
1
39 ADJUSTMENT SHIM I Z640030070
10
40 ADJUSTMENT SHIM II Z640030080
8
41 ADJUSTMENT SHIM III Z640030090 4
42 REAR FRAME Z6B403001 1
