序号

No.

零
件
代
号

Part No.

版本

Ver.

名
称

Part Name

数量

Q’ty

适用车号

Suit Num.

选装

Cho

1

Z30.4.12-12

1

固定螺钉

Screw

5

50512614-

2

B-Q020710-00042

1

O形密封圈25×2.4

O-ring

6

3

Z30.4.12-11

1

弹簧座

Spring seat

5

4

Z30.4.12-10

1

弹簧

Spring

5

5

Z30.4.12-8

1

单向阀

One-way valve

5

6

Z30.4.12-9

1

单向阀套

Valve bushing

5

7

B-Q020710-00024

1

O形密封圈16×2.4

O-ring

11

8

B-Q020710-00001

1

挡圈A16×12

Snapring

11

9

Z30.4.12-7

1

液动阀套

Valve bushing

3

10

Z30.4.12-6

1

阀芯

Valve core

3

11

Z30.4.12-13

1

液流阀阀罩

Valve hood

1

12

B-Q020710-00056

1

O形密封圈35×3.5

O-ring

1

13

Z30.4.12-3

1

液流阀阀套

Valve bushing

1

14

B-Q020710-00047

1

O形密封圈30×3.1

O-ring

1

15

Z30.4.12-2

1

弹簧

Spring

1

16

Z30.4.12-4

1

液流阀阀芯

Valve core

1

17

Z30.4.12-1

1

阀体

Valve body

1

18

W-10-00008

1

螺钉Z1/8″×12

Screw

2

19

Z30.4.12-14

1

阀套

Valve sleeve

1

20

B-Q020710-00033

1

O形密封圈22×2.4

O-ring

2

21

Z30.4.12-15

1

阀芯

Valve core

1

22

Z30.4.12-5

1

固定螺钉

Screw

1

23

B-Q020710-00029

1

O形密封圈20×2.4

O-ring

6

24

Z30.4.12-16

1

弹簧

Spring

1

序号

No.

零
件
代
号

Part No.

版本

Ver.

名
称

Part Name

数量

Q’ty

适用车号

Suit Num.

选装

Cho

1

B-G057820-00003

1

螺栓M10×110 ZnD

Bolt

3

50512614-

2

B-G000930-00001

1

垫圈10

Washer

3

3

B-G00097B-00002

1

垫圈10ZnD

Washer

3

4

Z30.4.12A

1

分配阀总成

Distributing valve ass’y

1

5

Z30.4.13

1

档位阀总成

Clutch valve ass’y

1

6

B-J010000-00003

1

螺塞M16×1.5

Plug

1

7

B-J010020-00004

1

垫圈16

Washer

11

8

Z50B.4.8B-1

1

接头

Joint

10

9

B-Q020710-00008

1

O形圈11×1.9

O-ring

11

10

B-Q020750-00098

1

胶管接头8Ⅰ－500

Joint

1

11

B-Q020750-00103

1

胶管接头8Ⅰ－600

Joint

2

12

B-Q020750-00096

1

胶管接头8Ⅰ－470

Joint

1

13

B-Q020750-00095

1

胶管接头8Ⅰ－400

Joint

1

14

Z30E.4.13-1

1

底板

Bottom plate

1

15

B-G000930-00017

1

垫圈8

Washer

4

16

B-G057820-00162

1

螺栓M8×50 ZnD

Bolt

4

17

B-J020990-00001

1

接管10

Joint pipe

1

18

B-J009810-00002

1

螺母M16×1.5

Nut

1

19

Z50B.4.12.1-1

1

铜管

Copper pipe

1

序号

No.

零
件
代
号

Part No.

版本

Ver.

名
称

Part Name

数量

Q’ty

适用车号

Suit Num.

选装

Cho

1

B-G00893A-00004

1

孔用弹簧挡圈30

Snap ring

3

50512614-

2

B-G09877A-00019

1

骨架式橡胶油封FB18×30×10

Oil seal

3

3

Z30.4.13-5

1

操纵压力表接头

Joint

1

4

B-J010020-00005

1

垫圈18

Washer

2

5

Z30.4.13-1

1

档位阀体

Valve body

1

6

B-Q020710-00033

1

O形密封圈20×2.4

O-ring

6

7

B-J010000-00005

1

螺塞M18×1.5

Plug

1

8

Z30.4.13-4

1

制动制载阀杆

Valve stem

1

9

B-Q020710-00047

1

O形密封圈30×3.1

O-ring

1

10

Z30.4.13-12

1

柱塞套

Plunger sleeve

1

11

Z30.4.13-13

1

柱塞

Plunger

1

12

B-Q020710-00008

1

O形密封圈11×1.9

O-ring

3

13

Z30.4.13-10

1

垫圈

Washer

2

14

Z30.4.13-15

1

活动杆导套

Guide bushing

1

15

Z30.4.13-9

1

制动杆始复弹簧

Spring

1

16

Z30.4.13-8

1

限位套

Limit sleeve

1

17

Z30.4.13-16

1

活塞杆回位弹簧

Retraction spring

1

18

Z30.4.13-11

1

螺钉

Screw

1

19

Z30.4.13-14

1

活塞杆

Piston rod

1

20

Z30.4.13-17

1

橡皮碗

Rubber cup

1

21

Z30.4.13-18

1

进气联接盖

Cover

1

22

Z30.4.13-7

1

制动杆联接套

Sleeve

1

23

Z30.4.13-19

1

方向杆档位体

Sleeve

1

24

Z30.4.13-6

1

垫圈

Washer

3

25

Z30.4.13-23

1

档位杆体

Sleeve

1

26

Z30.4.13-22

1

挡圈

Snap ring

2

27

Z30.4.13-21

1

钢球限位锥体

Limit cone

2

28

Z30.4.13-20

1

档位弹簧

Spring

2

29

B-G000790-00001

1

内六角圆柱端紧定螺钉M10×12

Screw

1

30

B-G003080-00002

1

钢球8

Ball

8

31

Z30.4.13-2

1

档位阀杆

Valve stem

1

32

Z30.4.13-3

1

方向阀杆

Valve stem

1
