序号

零 件 代 号

版本

名 称

数量

适用车号

选装

No.

Part No.

Ver.

Part Name

Q’ty

Suit Num.

Cho

1

1

三角带13×1245 (T0860026) strap

1

2

W-08-00029

1

空调器总成|BKG-08A/6BT5.9 Air-condition

1

3

1

SD5H14 压缩机(T0500009) compressor

1

4

1

低压软管(T0320007) tube

1

5

B-Q020020-00004

1

尼龙箍 90

hoop

8

6

1

高压软管(T0320008) tube

1

7

1

贮液器组件(T0520048) oil storage

1

8

B-G057830-00128

1

螺栓 M6×12ZnD Bolt

2

9

B-G000930-00015

1

垫圈 6

Washer

2

10

B-G00097B-00021

1

垫圈 6ZnD

Washer

2

11

1

风管φ50×870 (T0160002) pipeline

2

12

B-J088700-00017

1

喉箍 d60

Clamp

22

13

1

蒸发器总成(T0100042) evaporator

1

14

B-G057830-00030

1

螺栓 M12X25ZnD Bolt

4

15

B-G000930-00003

1

垫圈 12

Washer

6

16

B-G00097B-00004

1

垫圈 12ZnD

Washer

6

17

1

冷凝器总成(T0200001) condensation

1

18

B-G057830-00010

1

螺栓 M10X30ZnD Bolt

4

19

B-G000930-00001

1

垫圈 10

Washer

7

20

B-G00097B-00002

1

垫圈 10ZnD

Washer

7

21

B-G057830-00018

1

螺栓 M10×50ZnD Bolt

1

22

B-G061700-00003

1

螺母 M10ZnD

Nut

3

23

Z30E.19-8

1

调整垫

Washer

1

24

B-G057830-00015

1

螺栓 M10×40ZnD Bolt

2

25

B-G057830-00037

1

螺栓 M12×35ZnD Bolt

2

26

Z30E.19.2

1

压缩机支架

bracket

1

27

Z30E.19-9

1

板

board

1

28

Z50B.21-5

1

接头

tie-in

2

29

W-15-00051

1

球阀 1/2″|Q11F-16T Ball valve

2

30

B-Q020710-00021

1

O 形圈 16×2.4

O-ring

2

31

Z30.20.4

1

接管

take-over

2

32

Z30.20-4

1

接头

tie-in

1

33

Z30E.19-3

1

接头

tie-in

1

34

1

高压软管(T0320009) tube

2

35

1

风管φ50×500 (T0160005) pipeline

4

36

B-J088700-00012

1

喉箍 d25

Clamp

4

37

Z30E.19-5

1

出水管φ16×2200 Hose

1

38

Z30E.19-4

1

进水管φ16×1900 Hose

1

39

Z30.16.4-16

1

出线圈

Outlet loop

4

40

Z50E.21F-1

1

支撑

pipe clip

5

41

B-G057830-00137

1

螺栓 M8X16ZnD

Bolt

10

42

B-G000930-00017

1

垫圈 8

Washer

10

43

B-G00097B-00023

1

垫圈 8ZnD

Washer

10

44

1

风管φ50×650 (T0160009) pipeline

3

45

1

风管φ50×750 (T0160007) pipeline

1

46

1

风管φ50×100 (T0160006) pipeline

1

47

Z40E.21F-1

1

三通

tube

1
