序号 No.

零 件 代 号

Part No.

版本 Ver.

名

称

Part Name

数量 Q’ty

适用车号

Suit Num.

选装 Cho

1

B-G057860-00004

1

螺钉 M10×1×32

Screw

1

5071195-

2

B-G000930-00001

1

垫圈 10

Spring washer

1

5071195-

3

B-G00893A-00013

1

挡圈 72

Snap ring

1

5071195-

4

B-G002760-00015

1

轴承 6207

Bearing

1

5071195-

5

Z50B.2.1-4

1

芯轴

Shaft

1

5071195-

6

Z30.2.3-43

1

齿轮

Gear

1

5071195-

7

Z50B.2.1-3

1

联接套

Connecting sleeve

1

5071195-

8

B-G00893A-00012

1

挡圈 70

Snap ring

1

5071195-

9

B-G09877A-00023

1

油封 FB50x80x12

Oil seal

1

5071195-

10

Z50B.2.1-2

1

垫

Pad

1

5071195-

11

W-01-00007

1

油泵

Pump

1

5071195-

12

B-G009010-00005

1

双头螺栓 M14×55

Stud bolt

2

5071195-

13

B-G000930-00005

1

垫圈 14

Spring washer

2

5071195-

序号 No.

零 件 代 号

Part No.

版本 Ver.

名

Part

称

Name

数量 Q’ty

适用车号

Suit Num.

选装 Cho

1

Z30.2.8-7

1

阀盖

Valve cover

1

5071195-

2

B-J010020-00010

1

垫圈 30

Washer

1

5071195-

3

Z30.2.8-6

1

弹簧

Spring

1

5071195-

4

Z30.2.8-5

1

阀芯

Valve core

1

5071195-

5

Z50E.2.3-1

1

精滤清器上盖

Upper cover

1

5071195-

6

Z30.2.8-3

1

胶垫

Rubber pad

1

5071195-

7

W-15-00057

1

线隙式滤油器 XU-B80X100

Filter

1

5071195-

8

Z30.2.8-2

1

座

Seat

1

5071195-

9

Z30.2.8-1

1

弹簧

Spring

1

5071195-

10

B-Q020710-00111

1

O 形密封圈 105×5.7

O-ring

1

5071195-

11

Z30.2.8-4

1

螺塞

Nut

1

5071195-

12

Z30.2.8.1

1

精滤器体

Filter body

1

5071195-

13

B-J010020-00013

1

垫圈 8

Washer

1

5071195-

14

B-J010000-00013

1

螺塞 M8×1

Plug

1

5071195-
