SANY SKT90S Wide-Body Dump Truck parts list 05
160602050001A Air filter housing
160699000014A Intake hose
160602030016A Safety filter for air filter
160602020020A Air filter element
160699000015A Air filter cover
“Part No.
A210307000001″ “Description
Nut”
A210405000001 WASHER-HARD
14352761 welded component
14353189 stud
14352780 welded component
60279124 V-type anchor ear
14353190 asbestos pad
14352790 exhaust pipe
A229900005706 U-Bolt
14353123 exhaust pipe
14353188 plate
14353187 frame
A210111000042 Bolt
A210405000003 Washer
A210307000040 Nut
14353126 frame
A210111000038 Bolt
14353020 box
14353121 frame
“Part No.
169900000017A” “Description
Fuel tank”
A210114000009 Bolt
A210113000026 Bolt
A210307000040 Nut
A210314000005 Nut
“Part No.
A210855000066″ “Description
Throat collar”
ODT004984829 Fuel hose
14429699 Sheath
ODT004984831 Fuel hose
A210204000291 Screw
A210405000007 Washer
A210307000016 Nut
A210204000131 Screw
A210204000133 Screw
A210110000009 Bolt
A210307000001 Nut
14429709 Sheath
A229900006641 pipe nip
A210307000017 Nut
A210111000024 Bolt
A210405000011 WASHER-HARD
A210111000120 Bolt
ODT004984830 Fuel hose
A229900002499 Stud ends
ODT004984825 bracket
“Part No.
ODT004687484″ “Description
Cab electrical system”
ODT004687511 Body harness
ODT004687520 Power line assembly
ODT004687529 ingredients
“Part No.
142599000066A” “Description
Combination switch”
141998000074A Combination instrument assembly
140704000151A central controlling screen
142501000185A 3×5 rocker switch assembly
A249900000825 Low Air Pressure Alarm 3832N3-010
140999020009A GPS Terminal-EMEA
“Part No.
ODT004687358″ “Description
harness”
141604000113A Work lamp
140504000119A liquid level sensor
141601020026A Tail lamp unit
B241100000413 Alarm
60229116 Camera
142706000008A Video signal line
14501918 switch
140502000051A pressure transduer
14355269 Battery box
“Part No.
60150757″ “Description
ProximitySwitch”
B241000000004 Plug,Rectangular 3-position
B241000000002 Pin
B290000001123 Waterproof plug
“Part No.
60125384″ “Description
Switch”
A210111000211 Bolt
A210111000055 Bolt
A210111000053 Bolt
60190637 Battery
60013322 Terminal Assembly,Battery,Positive
60013321 Terminal Assembly,Battery,Negative
142904000003A distribution case
139999000132A Battery box assembly
“Part No.
14355252″ “Description
anode to switch wiring”
14355253 Switch to battery management unit
14355254 Battery management unit to starter wiring
14355255 Starter to engine ground wiring
14355256 Engine ground to battery cathode wiring
14355258 Engine to battery management unit wiring
14355259 Anode to cathode wiring
“Part No.
ODT005032342″ “Description
Stone pallet assembly”
A210307000035 Nut
A229900001360 Washer
A210110000307 Bolt
ODT005033381 Stone pallet assembly
14472659 Backup plate
A210110000360 Bolt M18×90GB5782 Grade 10.9
“Part No.
ODT005032266″ “Description
Mounting beam”
21006386 Pin-8
14472795 Adjustable gap piece
14472796 Adjustable gap piece
14472793 Carved stone
ODT004626142 Adjustable gap piece
“Part No.
ODT005032929″ “Description
Mounting beam”
21006386 Pin-8
14472795 Adjustable gap piece
14472796 Adjustable gap piece
14472790 Carved stone
ODT004626142 Adjustable gap piece
