11438911 Hose
A229900002960 Hose Hoop
A210111000039 Bolt
A210401000002 Washer
A210405000001 Washer
14248054 radiator right support
A210307000001 Nut
14007870 Connecting hose of intercooler
A229900003759 Clamp, T-bolt
14226668 Supercharger outlet tube
14226660 Radiator inlet air pipe
A229900006067 T-clamp
14248051 Fixed support of steel tube
A210111000089 Bolt
14226648 Engine water-intake cooling rubber pipe
A229900002031 Clamp
PDJ004882177 Radiator assembly bracket
A210111000202 Bolt
A210491000121 Washer
14248052 Wind board,down
13233039 Strip, Seal, Side
PDJ004882366 Radiator left assembly bracket
A210110000011 bolt M12×60GB5782 Grade 10.9
A820202003593 Washer
A820606030583 Pad, buffer
A820299001948 Bushing
23000678 Plug, Screw
14226656 Radiator inlet air pipe
15 -16 -17 19
“Part No.
14226653″ “Description
Engine air intake steel tube”
14226651 Engine Intake Rubber Hose
14226603 Water outlet rubber tube of engine
“Part No.
A229900001347″ “Description
Clamp, Hose”
B230103008509 Rubber hose
B210780000344 Connector, Pipe
B230103004459 Rubber Hose
“Part No.
60035663″ “Description
Rubber Hose”
60202488 Nut
A229900006820 Clamp, tube, double
A229900003846 Clamp
A210111000088 Bolt
A210405000007 Washer
A210401000017 Washer
12 13
“Part No.
14077880″ “Description
Left front outrigger”
11431253 Plate
A820301020680 Bolt
A210444000002 Washer
A210491000144 Washer
A210111000216 Bolt
“Part No.
14077879″ “Description
Right front outrigger”
21003719 Pad, Damping
60230081 Nut
“Part No.
14049225″ “Description
Left Baffle”
A210111000323 Bolt
14049467 Left Protective Plate
“Part No.
PDJ004751959″ “Description
Rear hood weld”
60015644 Hinge
14049647 Right Guard Board Weldment
14007922 Meshed Plate Weldment
“18
19″
“Part No.
13229145″ “Description
Plate”
14311522 ringt baffle welding part
14311613 left baffle welding part
14248910 upper baffle
12739371 Strip, Seal
14008657 Cover plate
A222200000058 Accessory, Latch, Cover
21015836 Screw
A210307000015 Nut
A210401000015 Washer
A210405000005 Washer
A210111000202 Bolt
A210404000004 Washer
A210401000002 Washer
“Part No.
A210891000007″ “Description
Hinge”
13949305 Door Rod Welding
A210401000017 Washer
14008519 Right Door Weldment
11092222 Pad, rubber, damping
A210204000116 Screw
14049191 Latch Plate
14049647 Right Guard Board Weldment
A210307000017 Nut
A210111000026 Bolt
A210111000197 Bolt
A210404000003 Washer
A210307000012 Nut
A210405000007 Washer
A210111000293 Bolt
“Part No.
14145220″ “Description
Front panel”
B241100000292 Lamp, Working
60000460 Tail lamp combination
“Part No.
14050269″ “Description
Harness AS”
A249900000826 Alarm, Backup
60206741 Fuel Sensor
“Part No.
A210401000015″ “Description
Washer”
A210405000005 Washer
A210111000070 Bolt
14007062 Right Panel
14007499 System Power
60034160 Headlamp, Combination, Left
60034159 Headlamp, Combination, Right
60041902 90 Degree Metal Mounting Bracket
A210405000011 Washer
A210401000017 Washer
“Part No.
A210111000240″ “Description
Bolt”
60119462 Band, dual loop, black
60200725 Fastening clamp
60200724 Clamp
60200719 Fastening clamp
60200722 Fastening clamp
60200723 Fastening clamp
60053511 Throttle Pedal, Electronic
60246671 Electric horn
A230200000170 Clip
“Part No.
A241200000765″ “Description
Rocker Switch”
A241200000762 Rocker Switch
A249900000514 Frame, Single, Middle
A249900000513 Frame, Single, Side
A241200000764 Rocker Switch
“Part No.
60002545″ “Description
Rocker Switch”
A241200000767 Switch
A241200000760 Rocker Switch
A241200000766 Rocker Switch
60134345 Lamp, indicator
“Part No.
60134345″ “Description
Lamp, indicator”
60134344 Lamp, indicator
14196274 Upper cover plate
14048286 Sycd Fixing Board
A810201206090 Communicate display
“Part No.
14007217″ “Description
Front frame harness”
14050254 Front console harness
14050253 Electrical control cabinet harness
“Part No.
14050255″ “Description
Right frame harness”
14007212 Tail Lamp Harness
14007226 Power cord
“Part No.
B241200000030″ “Description
Ignition switch”
A249900000513 Frame, Single, Side
A241200001116 Rocker Switch
60105071 Lighter, Cigarette
A249900000514 Frame, Single, Middle
A249900000518 Cover Plate
B240200000055 Knob switch
B240200000069 Knob switch
“Part No.
13635104″ “Description
Film, Centralized Control Box”
60078360 ECM
“Part No.
A210210000008″ “Description
Screw”
A210401000016 Washer
A210405000006 Washer
60287085 Relay
B240700000007 Protective Sleeve, Socket, Relay
“Part No.
60090673″ “Description
Fuse 5A”
60090672 Fuse 30A
60090674 Fuse 60A
“Part No.
60090670″ “Description
Fuse 10A”
60151533 Fuse 15A
60090671 Fuse 20A
“Part No.
60090694″ “Description
Relay”
60090666 Flasher
60090695 Relay
“Part No.
A210111000018″ “Description
Bolt”
A210401000001 Washer
A210405000011 Washer
A210111000089 Bolt
A210401000017 Washer
A210405000007 Washer
“Part No.
A290000002193″ “Description
Cover, Lock, Fuel Tank”
A210211000012 Screw
60022607 Stainer
13946258 Fuel Filler Weldment
“Part No.
A210111000089″ “Description
Bolt”
A210401000017 Washer
A210405000007 Washer
13495466 Plate
A210111000018 Bolt
A210405000011 Washer
A210401000001 Washer
A210609000294 O-ring
A210609000007 O-ring
“Part No.
14049855″ “Description
Weldment of fuel tank”
14114718 Mounting Base, Fuel Tank
24003229 Bolt
A210491000132 Washer
B210399000008 Screw Plug
B210399000002 Plug, Screw
“Part No.
61000257″ “Description
Rear axle”
A210307000007 Nut
A210110000239 Bolt
A210491000122 Washer
A210804000002 Adaptor, Grease
A229900003845 Clamp
PDJ004814390 Steel tube
“Part No.
B210780000098″ “Description
Connector, Pipe”
PDJ004810619 Steel tube
PDJ004810629 Steel tube
PDJ004810655 Steel tube
PDJ004813706 Steel tube
B210780000015 Fitting, Tee
PDJ004813674 Steel tube
B210780000117 Fitting, Tee
B210780001748 Pressure Tap
PDJ004810666 Steel tube
PDJ004813487 Steel tube
PDJ004813492 Steel tube
B210780000636 Fitting, Elbow
PDJ004813643 Steel tube
PDJ004810576 Steel tube
PDJ004810598 Steel tube
PDJ004810564 Steel tube
“Part No.
14057080″ “Description
Double-variable assembly”
21016826 Clamp, Tube, Single
60284037 Rubber hose
60281848 Rubber hose
A229900002892 Fitting, Adapter
60053788 Shaft, Drive, Main
14116250 Working pump oil intake steel tube
21050783 Fitting, Elbow
21032660 Hose Assembly
A210111000091 Bolt
60200724 Clamp
A210307000012 Nut
A210401000017 Washer
A210404000005 Washer
“Part No.
60349035″ “Description
Hydraulic Transmission Box”
A210111000026 Bolt
A210491000120 Washer
13890492 Left Mounting Seat
13890496 Right Mounting Seat
A210307000007 Nut
A210491000122 Washer
60271966 Damper
13645234 Washer
A210110000260 Bolt
A210111000221 Bolt
A210491000132 Washer
“Part No.
A210111000221″ “Description
Bolt”
A210491000132 Washer
PDJ004652362 Bracket
14042556 Oil filling pipe component
A210609000045 O-ring
A210405000007 Washer
A210401000017 Washer
A210111000090 Bolt
60356667 Pressure Switch
14240713 TM Connector
A210434000007 Washer
B240600000005 Temperature Sensor
A210111000289 Bolt
“Part No.
A210111000092″ “Description
Bolt”
61025846 Condenser
14520793 Condenser mounting seat
13852940 Air, blowing, port, of, port, Machinery
60200724 Clamp
14431048 Seat mounting plate
61025845 HVAC
14520238 Seat mounting assembly
141502000099A A/C accessory case
A210111000088 Bolt
A210307000012 Nut
21005351 Bolt
A210405000011 Washer
A210111000080 Bolt
A210401000016 Washer
A210404000009 Washer
A229900003852 Clamp
A210401000017 Washer
A210404000005 Washer
14056750 A/C Pipeline Bracket
A210204000132 Screw
A210307000016 Nut
14012773 Connector
13922144 Pressure Plate
13967040 A/C Clamp
A210110000306 Bolt
A210855000066 Throat collar
“21
22
23
24
57
56
55
54
50
16
17
B view”
“Part No.
A210405000006″ “Description
Washer”
A210111000079 Bolt
A210855000021 Throat collar
A810505030029 Connector
14430901 Evaporator mounting plate
A210111000018 Bolt
A210491000120 Washer
A210307000017 Nut
A210111000090 Bolt
A210405000007 Washer
B249900000288 Pin
B229900002528 Plug
A249900001139 Lock, 2-Position Receptacle
B241200000590 Sleeve, Protective, Socket, 2-Wire
A210491000132 Washer
