序号

零 件 代 号

版本

名

称

数量

适用车号

是否配件

选装

No.

Part No.

Ver.

Part

Name

Q’ty

Suit Num.

Spare Parts

Cho

1

W- 18-00225

1

手制动控制总成

WJ11-50- 138

Emergency Brake

Operator

1

957H0556-

957H0556-

2

B-G057830-00143

1

螺栓 M8×25ZnD

Bolt

4

957H0556-

3

B-G000930-00017

1

垫圈 8

Washer

4

957H0556-

4

B-G00097B-00023

1

垫圈 8ZnD

Washer

4

957H0556-

5

Z-95M- 110-00001

1

软轴支架 956M. 11- 1

Flexible shaft support

1

957H0556-

6

B-G057810-00020

1

螺栓 M12×30 ZnD

Bolt

2

957H0556-

7

B-G000930-00003

1

垫圈 12

Washer

2

957H0556-

8

Z- 130- 11B-00053

1

制动曲柄 Z30. 11B.2.3

Brake crank

1

957H0556-

9

Z- 130- 11B-00037

1

销轴 Z30. 11B.2-4

Shaft

1

957H0556-

10

B-G061840-00001

1

螺母 M10

Nut

2

957H0556-

11

Z- 130- 11B-00054

1

支座 Z30. 11B.2.3- 1

Pedestal

1

957H0556-

12

Z- 130- 11B-00051

1

支座 Z30. 11B.2- 10

Pedestal

1

957H0556-

13

Z- 130- 11B-00052

1

主夹钳 Z30. 11B.2-2

Main clamp

1

957H0556-

14

Z- 130- 11B-00039

1

弹簧拉销 Z30. 11B.2-6

Spring pin

1

957H0556-

15

Z- 15B- 110-00028

1

主磨擦块 Z50B. 11.3.2

Main friction block

1

957H0556-

16

Z- 15B- 110-00025

1

支座 Z50B. 11-7

Pedestal

1

957H0556-

17

Z- 15B- 110-00027

1

副磨擦片 Z50B. 11.3. 1

Second friction plate

1

957H0556-

18

Z- 130- 11B-00042

1

副夹钳 Z30. 11B.2- 1

Second clamp

1

957H0556-

19

Z- 130- 11B-00047

1

拉杆螺栓 Z30. 11B.2-9

Linkage bolt

1

957H0556-

20

B-G057830-00050

1

螺栓 M12×65ZnD

Bolt

1

957H0556-

21

Z- 15B- 110-00007

1

夹钳支架 Z50B. 11- 1

Clamp support

1

957H0556-

22

Z- 15B- 110-00024

1

调整垫片 Z50B. 11-6

Adjusting gasket

1 组

957H0556-

23

Z- 15B- 110-00015

1

垫块 Z50B. 11-2

Packing block

1

957H0556-

24

B-G057820-00173

1

螺栓 M14×40- 10.9ZnD

Bolt

5

957H0556-

25

B-Q020490-00004

1

垫圈 14

Washer

5

957H0556-

26

Z- 130- 11B-00036

1

复位弹簧 Z30. 11B.2-3

Retraction spring

1

957H0556-

27

Z- 130- 11B-00040

1

止动垫 Z30. 11B.2-7

Stop gasket

1

957H0556-

28

Z- 130- 11B-00041

1

螺栓 Z30. 11B.2-8

Bolt

1

957H0556-

29

Z- 130- 11B-00038

1

拉簧 Z30. 11B.2-5

Tension spring

1

957H0556-

30

B-G00861A-00001

1

垫圈 5

Washer

2

957H0556-

31

B-G061700-00031

1

螺母 M5

Nut

2

957H0556-

32

B-G001190-00013

1

销 4×22

Pin

1

957H0556-

33

B-G000910-00002

1

开口销 1.6×10

Cotter pin

1

957H0556-

34

Z- 15B- 110-00016

1

制动盘 Z50B. 11-4

Brake disc

1

957H0556-

35

B-G000930-00006

1

垫圈 16

Washer

4

957H0556-

36

B-G057830-00070

1

螺栓 M16×35 ZnD

Bolt

4

957H0556-

序号 No.

零件代号

Part No.

版本 Ver.

名称

Part Name

数量 Q’ty

适用车号 Suit Num.

是否配件 Spare Parts

选装 Cho

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

Z-95M- 120-00001 B-G00097A-00004 B-G057830-00027 Z-96T- 120-00048 Z- 15G- 12D-00001 B-Q01201C-00008 B-Q01201E-00003 B-G057830-00065 Z-96T- 120-00220

Z-96T- 120-00223

Z-96T- 120-00045

B-Q01201E-00001

B-G057830-00028

Z-96T- 120-00231

B-J07940A-00001

2

1

1

2

2

1

1

1

1

1

1

1

1

1

1

前车架 956M. 12. 1

垫圈 12ZnD

螺栓 M12×20- 10.9ZnD

前盖板 956T. 12. 11

下铰销 Z50G. 12D.3

垫片 97×150

垫圈 16

螺栓 M16x25- 10.9ZnD 举升油缸销轴 956T. 12.6 翻斗油缸销轴 956T. 12.7 转向油缸销轴 956T. 12. 10

垫圈 12

螺栓 M12×20ZnD

液压油管保护套 956T. 12-8 油杯 M10×1

Front Frame

Washer

Bolt

Front End Plate

Shaft

Washer

Washer

Bolt

Shaft

Shaft

Shaft

Washer

Bolt

Sleeve

Grease Fitting

1

4

4

1

2

24

7

7

2

1

2

2

2

2

2

957H0556- 957H0556- 957H0556- 957H0556- 957H0556- 957H0556- 957H0556- 957H0556- 957H0556- 957H0556-

957H0556-

957H0556-

957H0556-

957H0556- 957H0556-

序号 No.

零件代号

Part No.

版本 Ver.

名称

Part Name

数量 Q’ty

适用车号 Suit Num.

是否配件 Spare Parts

选装 Cho

1

Z-95M- 120-00001

2

前车架 956M. 12. 1 Front Frame

1

957H0556-

2

Z-96T- 120-00207

2

大臂销轴黄油管 956T. 12.5.1 管夹 TJBC- Φ 10

Butter Tube

2

957H0556-

3

W- 10-00038

1

Clamp

左转向油缸黄油管 956T. 12.5.4

8

957H0556-

4

Z-96T- 120-00212

2

Butter Tube

右转向油缸黄油管 956T. 12.5.5

1

957H0556-

5

Z-96T- 120-00214

2

Butter Tube

翻斗油缸黄油管 956T. 12.5.3

1

957H0556-

6

Z-96T- 120-00210

2

Butter Tube

1

957H0556-

7

W- 15-01442

1

螺帽 1110237

Nut

7

957H0556-

8

Z-96T- 120-00245

2

接头 956T. 12.5-9 JointBody

5

957H0556-

9

B-J07940A-00001

B-G00097A-00002

1

油杯 M10×1

垫圈 10ZnD

Grease Fitting

5

957H0556-

10

1

Washer

4

957H0556-

11

Z-96T- 120-00219

B-G00097B-00021

1

铰接螺栓 956T. 12.5-8 垫圈 6

Bolt

3

957H0556-

12

B-G057830-00126

1

Washer

螺栓 M6×10ZnD

8

957H0556-

13

W- 12-00797

1

Bolt

组合垫圈-310

8

957H0556-

14

1

Washer

7

957H0556-

15

Z-96T- 120-00282

1

直角接头 956T. 12.5- 10 JointBody

2

957H0556-
