序号

No.

零
件
代
号

Part No.

名
称

Part Name

数量

Q’ty

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

Z30.14.8-18

Z30.14.8-19

Z50E.34.1.2

B-Q020710-00035

Z50E.14.1.3

Z50E.14.1-3

Z50E.14.1-2

Z50E.14.1-1

B-Q020710-00090

W-15-00168

Z50B.14.21-4

Z50B.14.21-5

B-G00097B-00023

W-15-00064

B-Q020710-00023

B-G057830-00137

B-G000930-00017

Z30.14.8-7

B-Q020710-00030

Z50E.14N.1-1

Z30.14.8-5

B-Q020710-00027

Z30.14.8.3

Z50B.14.21-3

Z30.14.8-3

B-G061720-00002

B-Q020710-00014

Z50B.14.21-4

Z30.14.8-2

Z30.14.8-1

B-G000910-00020

B-G061780-00002

Z50E.34.1.1

螺塞                    Plug

标牌                    Name plate

油滤器罩                Oil filter cap

O形圈 230×5.7            O-ring

滤芯                    Filter core

弹簧                    Spring

弹簧压盖             Spring pressure cover

弹簧卡圈                Snap ring

O形圈 70×3.1            O-ring

液位计总成 YWZ-127        Oil gauge

盖板                    Cover plate

螺塞                    Plug

垫圈 8 ZnD                Washer

液压空气滤清器 QUQ2.5-A    Air filter

O形圈 16×2.4            O-ring

螺栓 M8×16 ZnD        Bolt

垫圈 8                    Washer

滤油器盖                Cover

O形圈 200×5.7            O-ring

弹簧                    Spring

支架                    Support

O形圈 185×5.7            O-ring

磁铁芯                    Magnet core

拉杆                    Drag rod

铜垫                    Copper washer

螺母 M12 ZnD            Nut

O形圈 130×5.7            O-ring

滤网总成             Oil screen assy

弹簧                    Spring

弹簧压盖         Spring pressure cover

销 2×20                 Cotter pin

螺母 M10 ZnD            Nut

箱体                    Tank body

1

1

1

1

1

1

1

1

1

1

2

1

8

1

1

20

12

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

序号

No.

零件代号

Part No.

名 称

Part Name

数量

Q’ty

1

Z50E.16Q.1.1

驾驶室骨架

Cab

1

2

Z50E.16F.4-2

前玻璃

Glass front

1

3

Z50E.16Q.1.2

盖板

Condenser cover

1

4

Z30.16.4F.2

小门

Door R.H

1

5

Z50E.16F.4-8

螺塞

Plug

4

6

B-J010020-00004

垫圈 16

Washer

4

7

B-G008250-00005

螺钉 M16 ZnD

Bolt

1

8

Z30.16.4E-12

玻璃（后）

Glass

1

9

Z30.16.4E-11

密封嵌条（后）

Seal tripe rear

1

10

Z30.16.4E.2

左门

Door L.H

1

11

Z50E.16F.4-5

前密封嵌条

Seal tripe front

1

12

Z50E.16F.4-4

侧玻璃

Glass side

2

13

Z50E.16F.4-6

板

Plate

8

14

B-G057830-00139

螺栓 M8×20 ZnD

Bolt

16

15

B-G00097B-00023

垫圈 8 ZnD

Washer

16

16

Z50E.16Q.3

顶板

Plate

1

17

Z40E.16F.6

塑料扣

Plastic button

15

序号

No.

零件代号

Part No.

名 称

Part Name

数量

Q’ty

1

B-G057830-00037

螺栓 M12×35 ZnD

Bolt

16

2

B-G00097B-00004

垫圈 12 ZnD

Washer

28

3

B-G000930-00003

垫圈 12

Washer

28

4

Z50F.16.3

支架

Support

1

5

Z50F.16.4

仪表盒

Instrument box

1

6

Z50B.16.5

右盖

Right cover

1

7

Z30.16-2

垫板

Plate

1

8

Z40E.16F.15-2

橡胶套

Rubber cushion

1

9

Z30.16-1

方向机卡

Direction retainer

1

10

Z30E.16.1

冷凝器罩壳

Condenser case

1

11

B-G057830-00030

螺栓 M12×25 ZnD

Bolt

12

12

Z50E.16.3

先导操纵箱

Precursor control case

1

13

B-G00097B-00023

垫圈 8 ZnD

Washer

19

14

B-G057830-00139

螺栓 M8×20 ZnD

Bolt

15

15

W-09-00051

座椅 ZT6A

Seat

1

16

B-G061700-00007

螺母 M12 ZnD

Nut

4

17

B-G057830-00137

螺栓 M8×16 ZnD

Bolt

2

18

B-G057830-00165

螺栓 M8×10 ZnD

Bolt

1

19

Z50F.16.2

制动箱

Brake cover

1

20

Z40E.16-4

小盖板

Small plate

2

21

Z50F.16.1

底板架

Lower plate reck

1

22

Z50E.16Q-2

后减震垫

Rear cushion

2

23

B-Q020490-00015

垫圈 24

Washer

4

24

B-G057830-00116

螺栓 M24×65 ZnD

Bolt

4

25

B-G00097B-00006

垫圈 14 ZnD

Washer

8

26

B-G000930-00005

垫圈 14

Washer

8

27

B-G057820-00064

螺栓 M14×55 ZnD

Bolt

8

序号

No.

零件代号

Part No.

名 称

Part Name

数量

Q’ty

28

Z40E.16-1

前减震垫

Front cushion

2

29

Z50B.16.6

左盖

Left cover

1

30

B-G057830-00006

螺栓 M10×25 ZnD

Bolt

3

31

B-G00097B-00002

垫圈 10 ZnD

Washer

3

32

Z30.16-4

转向器支承板

Support plate

1
