SANY SY365C SY365CCI2KH EXCAVATOR parts catalog 20
|
识别码 IC |
序号 INDEX |
零件代码 PART NUMBER |
数量 QTY |
名称 PART NAME |
|
|
2-205-1 |
1 |
12196084 |
2 |
风钩 |
Catch |
|
2-205-2 |
2 |
12670392 |
1 |
左门安装架 |
Left door mounting frame |
|
2-205-3 |
3 |
12677108 |
1 |
门 |
Door |
|
2-205-4 |
4 |
12672960 |
1 |
门 |
Door |
|
2-205-5 |
5 |
A210405000001 |
8 |
垫圈 |
Washer |
|
2-205-6 |
6 |
A210307000001 |
8 |
螺母 |
Nut |
|
2-205-7 |
7 |
A810502019056 |
4 |
定位螺钉 |
Setscrew |
|
识别码 IC |
序号 INDEX |
零件代码 PART NUMBER |
数量 QTY |
名称 PART NAME |
|
|
2-207-1 |
1 |
11843986 |
1 |
蓄电池安装压板 |
Plate, pressure, battery mounting |
|
2-207-2 |
2 |
11844000 |
1 |
挡板 |
Plate, retaining |
|
2-207-3 |
3 |
A210405000007 |
7 |
垫圈 |
Washer |
|
2-207-4 |
4 |
A229900001360 |
2 |
垫圈 |
Washer |
|
2-207-5 |
5 |
60214699 |
2 |
螺栓 |
bolt |
|
2-207-6 |
6 |
A210111000343 |
7 |
螺栓M8×20GB5783 10.9级 |
Bolt |
|
2-207-7 |
7 |
11843966 |
1 |
电瓶箱盖 |
Cover, battery box |
|
2-207-8 |
8 |
11767062 |
1 |
蓄电池胶垫 |
Cushion, battery |
|
2-207-9 |
9 |
11767284 |
2 |
蓄电池胶垫 |
Cushion, battery |
|
2-207-10 |
10 |
A210404000005 |
4 |
垫圈 |
Washer |
|
识别码 IC |
序号 INDEX |
零件代码 PART NUMBER |
数量 QTY |
名称 PART NAME |
|
|
2-209-1 |
1 |
A820606010409 |
2 |
橡胶块 |
Block, rubber |
|
2-209-2 |
2 |
24000633 |
4 |
垫圈8GB97.1 达克锈 |
Washer |
|
2-209-3 |
3 |
A820101213532 |
2 |
防摆座 |
Seat, anti-swing |
|
2-209-4 |
4 |
A210203000008 |
4 |
螺钉 |
Screw |
|
2-209-5 |
5 |
A210111000323 |
4 |
螺栓M8×25GB5783 10.9级 |
Bolt |
|
2-209-6 |
6 |
A810502012228 |
1 |
左上后盖板 |
Cover |
|
识别码 IC |
序号 INDEX |
零件代码 PART NUMBER |
数量 QTY |
名称 PART NAME |
|
|
2-211-1 |
1 |
13052125 |
1 |
机顶罩总成 |
Bonnet Assy. |
|
2-211-2 |
2 |
11961759 |
10 |
扣钉 |
Pintle |
|
2-211-3 |
3 |
A820699001228 |
2 |
侧面海绵 |
Foam |
|
2-211-4 |
4 |
11348911 |
1 |
密封条 |
Strip, sealing |
|
2-211-5 |
5 |
13052121 |
1 |
顶部海绵 |
Top |
|
识别码 IC |
序号 INDEX |
零件代码 PART NUMBER |
数量 QTY |
名称 PART NAME |
|
|
2-213-1 |
1 |
10055956 |
1 |
右上后盖板 |
Cover |
|
2-213-2 |
2 |
A820101342714 |
2 |
支架 |
Bracket |
|
2-213-3 |
3 |
A210111000202 |
6 |
螺栓 |
Bolt |
|
2-213-4 |
4 |
24000639 |
6 |
垫圈12GB97.1 达克锈 |
Washer 12GB97.1 |
|
2-213-5 |
5 |
A820101342715 |
1 |
防摆套 |
Sleeve, anti-swing |
|
2-213-6 |
6 |
A820301021326 |
1 |
前部弹簧 |
spring, torsional |
|
2-213-7 |
7 |
A820301021327 |
1 |
后部弹簧 |
Spring, torsional |
|
识别码 IC |
序号 INDEX |
零件代码 PART NUMBER |
数量 QTY |
名称 PART NAME |
|
|
2-215-1 |
1 |
12669831 |
1 |
右门安装架 |
right door frame |
|
2-215-2 |
2 |
12677408 |
1 |
右门 |
Door, right |
|
2-215-3 |
3 |
12196084 |
1 |
风钩 |
Catch |
|
2-215-4 |
4 |
A210405000001 |
4 |
垫圈 |
Washer |
|
2-215-5 |
5 |
A210307000001 |
4 |
螺母 |
Nut |
|
2-215-6 |
6 |
A810502019056 |
2 |
定位螺钉 |
Setscrew |
