SANY SY465C SY465C2M2H EXCAVATOR parts catalog 41
IC |
INDEX |
PART NUMBER |
QTY |
PART NAME |
4-31-1 |
1 |
13239656 |
1 |
Bucket body(2.9) |
4-31-2 |
2 |
60142873 |
6 |
Tooth, bucket |
4-31-3 |
3 |
60142875 |
6 |
Pin |
4-31-4 |
4 |
12827269 |
2 |
Lateral ToothSY465C1M2K.3.4-2D |
4-31-5 |
5 |
A210110000424 |
10 |
Bolt |
4-31-6 |
6 |
A210402000048 |
10 |
Washer |
4-31-7 |
7 |
A210307000078 |
10 |
Nut |
4-31-8 |
8 |
60142874 |
6 |
Spring, snap |
Chapter 5
Vehicle body harness
IC |
INDEX |
PART NUMBER |
QTY |
PART NAME |
5-3-1 |
1 |
60023703 |
1 |
Horn |
5-3-2 |
2 |
60090606 |
1 |
Antenna |
5-3-3 |
3 |
12794133 |
1 |
Harness, control switch |
5-3-4 |
4 |
60205002 |
1 |
Radio |
5-3-5 |
5 |
12794112 |
1 |
Harness, cab |
5-3-6 |
6 |
60053220 |
2 |
Lamp, indicator, LED, red |
5-3-7 |
7 |
60053221 |
3 |
Lamp, indicator, LED, yellow |
5-3-8 |
8 |
60117463 |
1 |
Switch, fuel control |
5-3-9 |
9 |
A241200001217 |
1 |
Key switch |
5-3-10 |
10 |
60143662 |
3 |
Lamp, work |
5-3-11 |
11 |
13403178 |
1 |
Sany Encourage Control Display |
5-3-12 |
12 |
B241000000003 |
1 |
Protective sleeve GP, plug, two- |
5-3-13 |
13 |
B241000000018 |
1 |
Socket, rectangle, 2-core |
5-3-14 |
14 |
B241000000005 |
1 |
3 Core Rectangular Socket |
5-3-15 |
15 |
A249900001139 |
2 |
Lock, secondary pole, 2-wire, pin |
5-3-16 |
16 |
23003355 |
4 |
lock, secondary pole, 2-line |
5-3-17 |
17 |
B249900000288 |
3 |
Pin |
5-3-18 |
18 |
B229900001093 |
5 |
Socket |
5-3-19 |
19 |
60060300 |
1 |
Extension, antenna |
IC |
INDEX |
PART NUMBER |
QTY |
PART NAME |
5-5-1 |
1 |
11953235 |
1 |
Shutdown switch, oil feed pump |
5-5-2 |
2 |
11953213 |
1 |
Switch, start, oil feed pump |
5-5-3 |
3 |
Modification or other |
2 |
Bolt M8×35GB5783 |
5-5-4 |
4 |
Modification or other |
2 |
Washer 8GB97.1 |
5-5-5 |
5 |
B241000000022 |
1 |
Socket, two-wire |
5-5-6 |
6 |
11768685 |
1 |
Frame, fixing, wire clip |
5-5-7 |
7 |
12186457 |
1 |
Plate, holding, wire clips |
5-5-8 |
8 |
60086356 |
6 |
Clamp, harness |
5-5-9 |
9 |
12864408 |
1 |
Sany Encourage Hydraulic Control |
5-5-10 |
10 |
12791157 |
1 |
Controller pinboard |
5-5-11 |
11 |
12791158 |
2 |
Controller pinboard |
5-5-12 |
12 |
60012780 |
1 |
Line, power |
5-5-13 |
13 |
60012797 |
1 |
Wire, power supply |
5-5-14 |
14 |
60047755 |
1 |
Box, electrical control |
5-5-15 |
15 |
12794174 |
1 |
Harness, electrical control cabinet |
5-5-16 |
16 |
B240700000250 |
10 |
Relay, auxiliary |
5-5-17 |
17 |
60013322 |
2 |
Connector GP, anode, battery, A- |
5-5-18 |
18 |
60013321 |
2 |
Connector GP, cathode, battery, A |
5-5-19 |
19 |
60012803 |
1 |
Wire, power supply |
5-5-20 |
20 |
60117678 |
2 |
Battery |
IC |
INDEX |
PART NUMBER |
QTY |
PART NAME |
5-7-21 |
21 |
60149605 |
4 |
Clamp, harness |
5-7-22 |
22 |
12794134 |
1 |
Body wire harness |
5-7-23 |
23 |
60190200 |
1 |
Wire, power supply |
5-7-24 |
24 |
60086353 |
11 |
Clamp, harness |
5-7-25 |
25 |
60083322 |
6 |
Clip, wire |
IC |
INDEX |
PART NUMBER |
QTY |
PART NAME |
5-9-1 |
1 |
60041902 |
3 |
Fixed Metal Connector Accessories |
5-9-2 |
2 |
60143661 |
2 |
Lamp, working |
5-9-3 |
3 |
60202066 |
1 |
Electric horn |
5-9-4 |
4 |
60202067 |
1 |
Electric horn |
5-9-5 |
5 |
60149606 |
6 |
Clamp, harness |
5-9-6 |
6 |
60086357 |
2 |
Clamp, harness |
5-9-7 |
7 |
A230200000021 |
4 |
Tape, electric, PVC |
5-9-8 |
8 |
60042166 |
5 |
Retainer, binding tape |
5-9-9 |
9 |
A210111000199 |
10 |
Bolt M12×20GB5783 10.9 |
5-9-10 |
10 |
60086354 |
12 |
Clamp, harness |
5-9-11 |
11 |
60086355 |
1 |
Clamp, harness |
