252911952 P7260-100/10WORKING PUMP ASSY

252116836 WORKING HYDRAULIC SYSTEM (1)

No. PART NUMBER QTY NAME    NOTE    PAGE

1 804011395    1    GEAR PUMP    442

2 252909510    1    HYDRAULIC PUMP INSTALLATION ASSY    444

3 803103341    1    SPLICE

1

804011395 GEAR PUMP

252911952 P7260-100/10WORKING PUMP ASSY

No. PART NUMBER QTY NAME    NOTE    PAGE

1 860538217    1    RELIEF VALVE

5

4

2    3

1

252909510 HYDRAULIC PUMP INSTALLATION ASSY

251808358 STEERING PUMP ASSY

No. PART NUMBER QTY NAME    NOTE    PAGE

1 252100847    1    ID SEAL

2 805338261    4    WASHER 12    GB/T93-1987

3 805300020    4    WASHER 12    GB/T97.1-2002

4 805002233    4    SCREW M12×35    GB/T899-1988

5 805238367    4    NUT 12    GB/T6170-2000

252911974 WORKING PUMP OIL SUCTION STEEL PIPE ASSY

252116836 WORKING HYDRAULIC SYSTEM (1)

No. PART NUMBER QTY NAME    NOTE    PAGE

1 803401133    1    ORING47.22×3.53    225N552-90

2 252911951    1    PUMP OIL SUCTION STEEL PIPE

3 805048024    4    BOLT M12×80(DACROMET)    GB/T16674.1-2004

2

251808358 STEERING PUMP ASSY

252116836 WORKING HYDRAULIC SYSTEM (1)

No. PART NUMBER QTY NAME    NOTE    PAGE

1 252909510    1    HYDRAULIC PUMP INSTALLATION ASSY    450

2 803004104    1    STEERING PUMP

5

4

2    3

1
