Description

761G-04-073A+A PS07107 washer

B00002956 双头螺柱 STUD – GB/T901-M10*120-8.8-Y 4
S00012852 进气管垫片 GASKET, AIR INTAKE PIPE 1
S00009160 电控线束支架 BRACKET, HARNESS ELECTRICAL-CONTROL 2
B00000833 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD – GB/T6177-M10-Y 4
B00002139 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M8*30 2
S00016638 天然气混合器支架 BRACKET, NATURAL GAS MIXER 1
B00001997 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M10*20-10.9 1
B00002132 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M8*16 7
S00021320 天然气混合器芯子 NATURAL GAS CORE, MIXER 1
S00019026 夹箍 CLAMP 1
S00016641 天然气废气门控制阀支架 NATURAL GAS BRACKET, EXHAUST VALVE CONTROL 1
T88-034-03 废气门控制阀部件 WASTE GATE VALVE 1
B00002129 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M8*10 2
B00002104 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M5*16 2
B00000787 I型六角螺母 HEXAGON NUTS, STYLE 1 – GB/T6170-M5-Y 14
T88-269-50 螺母 NUT 1
S00015041 排气放气阀接头 JOINT, WASTE GATE 1
S00012918 废气控制阀出气管 AIR OUTLET PIPE, WASTE GATE CONTROL 1
B00001994 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M10*16 1
S00016405 橡胶管 PIPE 2
T24A-324-04 夹箍 CLAMP 5
S00009321 火花塞部件 SPARK PLUG ASSY 6
S00021768 高压点火线部件 IGNITION COIL ASSY, HIGH VOLTAGE 6
S00014670 点火线圈支架 BRACKET, IGNITION COIL 1
T89-112-01 垫块 SPACER 12
T89-009-04 点火线圈部件 COIL ASSY, IGNITION 6
B00000597 六角头螺栓 HEXAGON HEAD BOLT – GB/T5783-M5*35-10.9 12
S00009579 进气接管 ADAPTER, AIR INTAKE PIPE 1
B00002134 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M8*20 2
S00008701 低压截止阀 CHECK VALVE, LOW PRESSURE 1
S00025229 FMV进气管部件 JOINT, NATURAL GAS INLET-FMV (FUEL METERING VALVE) 1
S00015408 FMV进气管部件 JOINT, NATURAL GAS INLET-FMV (FUEL METERING VALVE) 1
B00000896 内六角圆柱头螺钉 HEXAGON SOCKET HEAD CAP SCREW – GB/T70.1-M6*10 2
T12-110-01 防喘振阀接头 JIONT 1
S00022407 FMV进气管部件 JOINT, NATURAL GAS INLET-FMV (FUEL METERING VALVE) 1
B00001999 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M10*25 1
S00014113 FMV支架 BRACKET, FMV (FUEL METERING VALVE) 1
S00013007 燃气计量阀部件 METERING VALVE, NATURAL GAS 1
T88-255-01 FMV安装螺栓 BOLT, FMV (FUEL METERING VALVE) 3
B00000843 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD – GB/T6177-M6-Y 3
T88-085-01 低压燃气滤清器 FUEL FILTER , LOW PRESSURE 1
B00004660 O形橡胶密封圈 O-RING SEAL – GB/T3452.1-18*1.8 5
B00001545 复合式密封硬垫圈 RUBBER COATED HARD WASHER – Q/SC1294-10 1
T88-028-50 MAP/T传感器 SENSOR, MAP/T 2
B00002114 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE-SMALL SERIES – Q/SC622-M6*16 2
S00011183 进气加热法兰垫片 AIR INTAKE HEATER FLANGE GASKET 1
S00015266 线束支架 WIRING HARNESS BRACKET 1
B00002117 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE – Q/SC622-M6*16-ZN.D 3
B00002145 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE – Q/SC622-M8*40 2
B00001549 复合式密封硬垫圈 RUBBER COATED HARD WASHER – Q/SC1294-18 1
B00001728 六角头螺塞 PLUG – Q/SC587.1-M18*1.5 1
B00002003 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE – Q/SC622-M10*30-ZN.D 4
B00002131 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE – Q/SC622-M8*12-ZN.D 1
D00-138-03 卡箍 CLAMP 1
T88-290-01 橡胶管 ELBOW 1
B00000844 六角法兰面螺母 HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD – GB/T6177-M6-ZN.D 2
T88-243-04 夹箍 CLAMP 1
B00001995 六角法兰面螺栓 HEXAGON BOLTS WITH FLANGE – Q/SC622-M10*16-ZN.D 2
S00019126 电子节气门 ELECTRONIC THROTTLE 1
S00019933 天然气混合器进气管 NATURAL GAS INLET PIPE, MIXER 1
S00019375 进气弯管 AIR INTAKE PIPE ELBOW 1
S00006001 接头 CONNECTOR 5
S00007094 压力调节阀 PRESSURE REGULATING VALVE 1
