Description

S00004889+01 135 STARTER MOTOR

1 D04-145-30A 排气管螺栓 BOLT EXHAUST MANIFOLD 8
2 S00003833 排气管螺栓垫块 EXHAUST PIPE BOLT SPACER 8
3 S00011279 排气管 EXHAUST MANIFOLD 1
4 S00003834 排气管垫片 GASKET, EXHAUST MANIFOLD 4
5 S00012169 排气管隔热罩 HEAT SHIELD, EXHAUST MANIFOLD 1
6 S00012168 排气管隔热罩 HEAT SHIELD, EXHAUST MANIFOLD 1
7 D13-318-02 隔热板螺栓 BOLT 2
8 D13-318-04 隔热板螺栓 BOLT 2
9 B00001724 六角头螺塞 HEXAGON PIPE PLUG 2
10 B00001545 复合式密封垫片 RUBBER COATED HARD WASHER 2
11 S00005855 螺栓 BOLT 2
12 B00001733 六角头螺塞 HEXAGON PIPE PLUG 1
13 B00001555 复合式密封垫片 RUBBER COATED HARD WASHER 1
14 S00011683 进气管盖板 COVER, AIR INTAKE PIPE 1
15 S00005856 螺栓 BOLT 10
16 S00005009 卡箍 CLAMP 1
17 S00005016 进气弯管 AIR INTAKE PIPE ELBOW 1
18 S00004985 O型圈 O-RING 1
19 B00004972 闷头 PLUG 1

1 B00002178 增压器进油铰接螺栓 BOLT 1
2 S00011472 增压器进油管维修组件 TURBOCHARGER OIL INLET PIPE SERVICE GROUP 1
3 B00001818 铜垫圈 COPPER WASHER 2
4 S00003939 接头 CONNECTOR 1
5 S00005682 O型橡胶密封圈 O-RING 1
6 D13-108-50 增压器自锁螺母 TURBOCHARGER SELF-LOCKING NUT 4
7 S00003525 双头螺柱 STUD 4
8 S00009807 增压器维修组件 TURBOCHARGER SERVICE GROUP 1
9 D13-103-52 涡轮出口垫片 GASKET, OUTLET-TURBINE 1
10 S00003835 涡轮进口垫片 GASKET, INLET-TURBINE 1
11 S00011473 增压器回油管维修组件 TURBOCHARGER OIL RETURN PIPE SERVICE GROUP 1
12 S00003929 增压器回油管垫片 TURBOCHARGER OIL RETURN TUBE GASKET 1
13 B00004893 六角法兰面螺栓 BOLT 2
14 D02A-171-80 O形圈 O-RING 2
15 S00000146 膨胀节 EXPANSION CONNECTOR 1
16 B00002003 六角法兰面螺栓 BOLT 4
17 S00012192 排气弯管维修组件 EXHAUST PIPE ELBOW SERVICE GROUP 1
18 B00001138 “双头螺栓
” STUD 5
19 B00000793 “I型六角螺母
” HEXAGON NUT (TYPE 1) 5
20 S00012191 排气弯管支架 BRACKET, EXHAUST PIPE ELBOW 1
21 B00002000 六角法兰面螺栓 BOLT 2
22 S00011235 夹箍 CLAMP 2
23 B00002110 六角法兰面螺栓 BOLT 1
24 B00000790 I型六角螺母 HEXAGON NUT (TYPE 1) 1
25 A745DC-13-001 消声器垫片 GASKET, MUFFLER 1
